User's Manual
Car Video Recorder
DrivePro™ 50
(Version 1.0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DrivePro 50 and is the answer not in the manual?

Questions and answers

Related Manuals for Transcend DrivePro 50

Summary of Contents for Transcend DrivePro 50

  • Page 1 User’s Manual Car Video Recorder DrivePro™ 50 (Version 1.0)

  • Page 2: Table Of Contents

    Table of Contents Introduction..........................2 System Requirements......................2 Safety Precautions........................3 3-1 General Use........................3 3-2 Mounting Location......................3 3-3 Backing up Data........................3 Getting Started...........................4 4-1 Function Buttons.........................4 4-2 LED Indicators........................5 4-3 Inserting a microSD Memory Card.................. 5 4-4 Mounting the DrivePro™....................6 4-5 Connecting to Power......................7 Recording Videos........................

  • Page 3: Introduction

    1. Introduction Transcend’s DrivePro™ 50 is a compact car video recorder that is specifically designed to capture real time videos of events happening outside your vehicle. Featuring a large ƒ/1.8 aperture and high-quality camera lens, the DrivePro™ 50 can capture all details of an incident, including license plates, during either daytime or nighttime.

  • Page 4: Safety Precautions

     Avoid splashing water or any other liquids on the DrivePro™ and accessories.  Do not use the DrivePro™ in an environment with strong magnetic fields or excessive vibration.  Only use the car adapter provided by Transcend. Other car adapters may not compatible with the DrivePro™.

  • Page 5: Getting Started

    4. Getting Started 4-1 Function Buttons Top View Bracket Socket Front & Back View Built-in Buzzer Built-in Microphone Lens Reset Button LED Indicator Side View mini USB Slot microSD Card Slot Power / Emergency Button...

  • Page 6: Led Indicators

    4-2 LED Indicators Recording Status Definition Solid Stop recording* ● Flashing Recording Flashing quickly Emergency recording** Connected to computer Status Definition Solid Connected to computer ● Flashing Transferring data *The DrivePro™ will stop recording when a card error occurs or when you tap data / settings using the DrivePro™...

  • Page 7: Mounting The Drivepro

    WARNING: Do not remove the memory card during shutdown to avoid damages to the memory card and loss of recorded videos. 4-4 Mounting the DrivePro™ 1. Insert the mount bracket into the top of the DrivePro™, and slide sideways until you hear a click. 2.

  • Page 8: Connecting To Power

    5. After the DrivePro™ is in the best position, turn the adjustment knob clockwise to make sure that the DrivePro™ is securely locked in place. 4-5 Connecting to Power Note: Insert a microSD memory card before connecting the DrivePro™ to your car’s lighter socket.

  • Page 9: Recording Videos

    1. Connect the small end of the car adapter to the USB connector of the DrivePro™. 2. Plug the other end of the car adapter in your car’s lighter socket. 3. After the car engine is switched on, the DrivePro™ will automatically turn on and start recording.

  • Page 10: Using The Drivepro™ New App

    Note: The earliest emergency file saved will be overwritten by the latest emergency file recorded once the 30% storage space is full. 6. Using the DrivePro™ New App Developed for iOS and Android devices, the free DrivePro™ New App allows you to wirelessly adjust the settings of the camera and to live-stream video on your smart device.
  • Page 11 3. Select the “DrivePro™50” Wi-Fi link (default password is 12345678). 4. Tap the DrivePro™ New icon on the home screen of your device to use the App. Note: The camera stops recording when you tap using the App, the front LED turns solid blue.

  • Page 12: Playing Videos

    6-3 Playing Videos To play videos, tap Select to play the videos recorded in normal or emergency mode.

  • Page 13: Android

    Select the desired file to play the video. Android To play videos, tap...
  • Page 14 Select to play the videos recorded in normal or emergency mode. Select the desired file to play the video.

  • Page 15: Downloading Videos To Your Smart Device

    Note: The camera stops recording when you tap using the App, the front LED turns solid blue. The camera will resume recording when you quit. 6-4 Downloading Videos to your Smart Device...
  • Page 16 Select to download the videos recorded in normal or emergency mode. to download or delete the video.

  • Page 17: Settings

    6-5 Settings to enter the Settings menu. In the Settings menu, you can adjust the settings of video, device, Wi-Fi and System. Menu options Resolution: Set the resolution/quality for video recording. Available options: 1080P / 720P Exposure Value: Adjust exposure composition value to lighten or darken the preview screen.

  • Page 18: Transferring Files To A Computer

    After the upgrade is complete, the DrivePro™ will restart automatically. 2. If the DrivePro™ cannot be turned on due to firmware upgrade failure, please contact Transcend customer service for technical support. 7. Transferring Files to a Computer To transfer files between the DrivePro™’s memory card and your computer: Option 1: Take the microSD memory card out of the DrivePro™, and insert to a compatible card...
  • Page 19 3. Plug the large end of the cable into an available USB port on your desktop or laptop. Note: DrivePro™ package does not contain any USB cable. ® Windows 7 / 8 / 8.1 / 10 No drivers are required for connecting the DrivePro™ to your desktop or laptop. Windows® Operating Systems have built-in drivers to support your DrivePro™.

  • Page 20: Drivepro™ Toolbox Software

    The DrivePro™ Toolbox, developed for Windows, features a user-friendly interface that allows you to select and play videos recorded on your DrivePro™ without the need to install separate codecs. Download the installation files from: http://www.transcend-info.com/downloads Install DrivePro™ Toolbox software on your desktop or laptop. The useful features include: Video Sorting Easily sort videos by filename, recording date or group.

  • Page 21: Package Contents

    9. Package Contents DrivePro™ Car Video Recorder Adhesive Mount or Suction Mount Car Adapter 16GB microSD Memory Card Quick Start Guide Warranty Card...

  • Page 22: Specifications

    Specifications Connect Interface: USB 2.0 MLC-based microSD, 8GB / 16GB / 32GB / 64GB Storage Capacity: (Class 10 or above) 55mm(L) × 58mm(W) × 31.15mm(H) Dimensions: 2.17” (L) x 2.28” (W) x 1.22” (H) Weight: 1.73 oz Power Supply for Car Input DC10V~30V / 1A (Max.) Lighter Adapter Output DC5V / 1A...
  • Page 23 Using TLC-based memory cards on your car video recorder might result in unstable performance. 2. Besides the bundled microSD card, we recommend Transcend’s High Endurance Note microSD card as an additional purchase to reach the most stable recording performance. Please...

  • Page 24: Frequently Asked Questions

    DrivePro™ for repair. If you cannot find any ideal solution to your question below, please consult your dealer, service center, or local Transcend branch office for further help. You can also visit Transcend website for FAQ and Technical Support services. For any Hardware issues, please refer to the DrivePro™...

  • Page 25: Recycling And Environmental Protection

    12. Recycling and Environmental Protection Recycling the Product (WEEE): Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. When you see the crossed-out wheel bin symbol attached to a product, it means that the product is covered by the European Directive 2002/96/EC: Never dispose of your product with other household waste.

  • Page 26: Federal Communications Commission (Fcc) Statement

    13. Federal Communications Commission (FCC) Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received including interference that may cause undesired operation. This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.

  • Page 27: Two-Year Limited Warranty

    Transcend Warranty Policy. Proof of the original purchase date is required for warranty service. Transcend will inspect the product and in its sole discretion repair or replace it with a refurbished product or functional equivalent. Under special circumstances, Transcend may refund or credit the current value of the product at the time the warranty claim is made.

  • Page 28: Gnu General Public License (Gpl) Disclosure

    16. End-User License Agreement (EULA) Software license terms and conditions 1. Generally. Transcend Information, Inc. ("Transcend") is willing to grant the following license to install or use the software and/or firmware (“Licensed Software”) pursuant to this End-User License Agreement (“Agreement”), whether provided separately or associated with a Transcend product (“Product”), to the original purchaser of the Product upon or with which the Licensed Software was installed or associated as of the time of purchase ("Customer") only if Customer accepts all of the terms and conditions of this Agreement.
  • Page 29 Licensed Software; (e) remove, alter or obscure any copyright notice or other proprietary rights notice on the Licensed Software or Product; or (f) circumvent or attempt to circumvent any methods employed by Transcend to control access to the components, features or functions of the Product or Licensed Software.
  • Page 30 (d) A waiver by either party of any term or condition of this Agreement or any breach thereof, in any one instance, will not waive such term or condition or any subsequent breach thereof. (e) Transcend may assign its rights under this Agreement without condition. (f) This Agreement will be binding upon and will inure...
