Host Input/Output Connections
USB Input
Link Output
5V DC Power
Client Input/Output Connections
USB Outputs (500 mA max current)
Link Input
5V DC Power
USB Performance
Maximum Distance
USB Device Support
USB Hub Support
USB Host Support
Maximum USB Devices Supported
Chassis and Environmental
Enclosure Material
Enclosure Dimensions (H x W x D)
Shipping Weight
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Power and Regulatory
Power Supply Input
Power Supply Output
Power Consumption
ESD Protection
Product Regulatory
Power Supply Regulatory
Other
Warranty
Diagnostic Indicators (Host Side)
Diagnostic Indicators (Client Side)
Included Accessories
Distances and picture quality may be affected by cable grade, cable quality, source and
destination equipment, RF and electrical interference, and cable patches.
Technical Specifications
One (1) USB Type B Receptacle
One (1) 8P8C Connector (RJ45 style)
One (1) Barrel (5.5 mm OD; 1.7 mm ID)
Four (1) USB Type A Receptacles
One (1) 8P8C Connector (RJ45 style)
One (1) Barrel (5.5 mm OD; 1.7 mm ID)
100 m (328 ft) over Category 5e or greater cable
High-speed devices (USB 2.0) - up to 480 Mbps
Full-speed devices (USB 2.0 & 1.1) - up to 12 Mbps
Low-speed devices (USB 2.0 & 1.1) - up to 1.5 Mbps
Any single chain can include up to 4 USB hubs plus one DIGI-USB2-4P.
xHCI (USB 3.0) at USB 2.0 speed, EHCI (USB 2.0) and OHCI/UHCI (USB 1.1)
Up to 15 USB devices or 4 USB hubs with 11 USB devices.
Anodized Aluminum
26 mm x 100 mm x 76 mm (1.02 in x 3.94 in x 2.99 in)
0.9 kg (2.0 lbs)
0° to +50° C (+32° to +122° F)
10% to 90%, Non-condensing
-20° to +70° C (+14° to +158° F)
10% to 85%, Non-condensing
100V-240VAC / 50-60 Hz / 0.6A
5VDC / 3.0A
15 watts (max)
±15 kV
FCC, CE, IC, RoHS
UL, CUL, CE, PSE, GS, RoHS
2 years
Power, Host, Link, Activity
Power, Host, Link, Activity, USB Port Status
Wall Mount Power Supply, USB Type A to USB Type B cable, Installation
Guide
