Avaya Distributed Office i120
Contact Centers
Mobility
Installation Quick Start
Services
03-602289
Issue 1
May 2007
This document contains the information that you need to start using
your Avaya Distributed Office in the shortest possible time.
1.What to check
2.Mount
3.Ground
4.Connect
5.Power up
6.Configure.
Congratulations!
information on how to leverage the system, see the Avaya Distributed
Office Document Map.
before you install your Avaya Distributed Office.
your Avaya Distributed Office.
your Avaya Distributed Office.
your Avaya Distributed Office to your telephones,
computers, and network. See the Installation Poster.
Connect your computer to the Services port on the AM110, using
an Ethernet cable.
your Avaya Distributed Office.
- The PWR LED and the CPU LED on the front panel illuminate to
indicate that the installation is successful.
Point your Web browser to https://192.11.13.6.
You are now ready to use your i120. For more
Advertisement
Related Manuals for Avaya i20
Summary of Contents for Avaya i20
- Page 1 - The PWR LED and the CPU LED on the front panel illuminate to indicate that the installation is successful. 6.Configure. Point your Web browser to https://192.11.13.6. Congratulations! You are now ready to use your i120. For more information on how to leverage the system, see the Avaya Distributed Office Document Map.
- Page 2 Check Unpack Safety The Avaya Distributed Office i120 is shipped with the following items. If any items are missing or damaged, Before you start the installation, refer to the following contact your supplier. Retain the packaging in case safety information you need to ship the i120.
- Page 3 03-602028. guide cables to the side of the i120. These cutouts provide easier access to the front panel and help you • Unleash the Full Potential of Avaya Distributed manage the placement of the cables. Office, 03-602022. • Documentation Map for Avaya Distributed Office,...
- Page 4 5. Insert two additional mounting screws on each side. 1. Attach the mounting brackets to the i120. Use three of the supplied screws for each bracket. Front mount position L IN L IN IC E S /W C on...
- Page 5 For installations in Finland and Norway, the operation of the i120: the ground conductor that is Avaya i120 relies on two ground connections (mains plug part of the AC power cord and the field-installed green/ with an earth contact and a Supplementary Ground yellow conductor referred to as the Supplementary Conductor).
- Page 6 (ESD). Connect Connect your Avaya Distributed Office to your Local electrical installation codes must be followed telephone, computers, and network. Refer to the when installing the i120. enclosed Installation Poster for information.
- Page 7 Power up Configure 1. If you received a disk-on-key, insert the disk-on-key Point your Web browser to https://192.11.13.6. into the USB port on the front of the i120. Note: The proxy settings, if any, need to be disabled. • The Distributed Office Local Manager application starts.
- Page 8 • The Navigation Pane on the left side of all screens Initial Setup Assistant Home Screen. contains a list of links to the screens for managed The Initial Setup Assistant applies to Distributed objects. Office i120 solutions that require complete •...
- Page 10 Legal disclaimer For full legal page information, please see the documents, Avaya Support Notices for Software Documentation, 03-600758, and Avaya Support Notices for Hardware Documentation, 03-600759. These documents can be accessed on the documentation CD and on the Web site, http://www.avaya.com/support.
