Town & Country Fireplaces TCWS54ST Installation And Operating Instructions Manual

Power vented see thru fireplace
Hide thumbs Also See for TCWS54ST:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction and Installation Manual, Installation Instructions and Operating Manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the fire department.
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or
any other appliance.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certified kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
220313-68
TCWS.54CSTE
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL
TCWS54ST
SERIES C
POWER VENTED
SEE THRU FIREPLACE
TCWS.54CSTE
SERIAL #
5056.425218

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCWS54ST and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TCWS54ST

Summary of Contents for Town & Country Fireplaces TCWS54ST

  • Page 1 This appliance is not convertible for use with other gases, unless a certified kit is used. MODEL This appliance is suitable for installation in a TCWS54ST bedroom or bed sitting room. SERIES C POWER VENTED SEE THRU FIREPLACE 220313-68 TCWS.54CSTE...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents Table of Contents ................2 Table of Contents ................3 Certifications ................... 3 Caution ................... 4 Safety ..................... 4 Important Note for the Commonwealth of Massachusetts: ..... 5 Fireplace Dimensions ..............6 Minimum Clearances to Combustible Material ....... 6 Installation Requirements ...............

  • Page 3: Table Of Contents

    Table of Contents Lighting Instructions ..............52 First Fire ..................52 Maestro Control System Remote Control Initial Setup ....53 Maestro Control System - Operation ..........54 Maintenance ................. 57 Replacement Parts - TCWS.54CSTE ........... 58 Replacement Parts - Tranquility Burner ........59 Replacement Parts - Black Diamond Burner ........

  • Page 4: Caution

    Caution FOR YOUR SAFETY - Do not install or operate your Town & Country fireplace without first reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Town & Country Fireplaces Warranty and may prove hazardous.

  • Page 5: Important Note For The Commonwealth Of Massachusetts

    Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied.

  • Page 6: Fireplace Dimensions

    Fireplace Dimensions Fig. #1 70 3/4” 16 9/16” 35 5/8” 41 1/4” 19 7/8” 18” 10” 30 1/16” 53 3/4” Minimum Clearances to Combustible Material Fig. #2 NON-COMBUSTIBLE ZONE. COMBUSTIBLE FRAMING AND STEEL FRAMING DO NOT INSTALL ANY COMBUSTIBLE MATE- FINISH WALL ABOVE STANDOFFS RIAL, ELECTRICAL WIRING OR GAS PLUMBING IN THIS AREA.

  • Page 7: Installation Requirements

    Installation Requirements The Town & Country Fireplace installation and venting must conform to the local codes or, in the absence of local codes, current CSA B149.1 installation code (in Canada) or the current National Fuel Gas Code, ANSI Z223.1/NFPA 54 (in the USA). Only qualified (licensed or trained) personnel should install this product.

  • Page 8: Standoffs

    Standoffs The framing kits, once assembled Fig. #6 and attached, are used as the top and side standoffs (see page 10 & 11.) HANDLE CONTROL Locating The Fireplace In planning the installation for the fireplace, it is necessary to determine where the unit is to be installed, location of vent system and where gas supply piping may be plumbed.

  • Page 9: Framing And Finishing

    Framing and Finishing Note: The fireplace should be in place Chase Insulation: non-combustible material. Assemble the When installing this and venting installed before framing in framing kit as per the instructions on pages fireplace against a non-insulated exterior or building an enclosure around the unit. 10 –...
  • Page 10 Fig. #9 Fig. #9A NON-COMBUSTIBLE BOARD DETAIL USE FULL SHEETS OF CALCIUM SILICATE BOARD AND FULL LENGTH METAL STUDS TO FINISH AND FRAME AROUND THE UNIT. CALCIUM SILICATE BOARD IS A HIGH GRADE MATERIAL WITH CEMENT, QUARTZ AND NATURAL MINERALS AS THE MAIN RAW NON-COMBUSTIBLE MATERIALS.

  • Page 11: Steel Stud Framing Kit

    Steel Stud Framing Kit TCWS.54STFRKIT Each Kit Contains: Item Part # Description Qty. 5049.9912 SCREW, WAFER #8 x 1/2 8493.4 STUD, SIDES 54” L 8493.2 STUD, OUTER SIDES 54” L 8493 STUD, UPPER/LOWER 38 1/16” L 8493.6 INNER CROSS BRACE 56 7/8”...
  • Page 12 NOTE: Sheet metal parts have sharp edges, use caution when handling. 1. Frame Assembly • Place 2 of #4 together as a top. • Place 1 of #6 into the joint with the long edge facing up. Align the 3 holes and screw together with wafer screw #1. •...
  • Page 13 2. Attach the Assembled Frame to the Fig. #13 Unit • Align the assembled frame to the unit framing brackets. (Fig #13) Attach at the fastening points through the access holes in the outer side studs (3). 3. Secure to Existing Framing • Bend out the tabs 90 degrees before inserting the unit into its framed housing (Fig.

  • Page 14: Adjustable Lintel

    Adjustable Lintel The adjustable lintel assembly has two Fig. #16 orientations for desired finishing. The flanged edge and the hemmed edge. The lintel comes factory installed with the flange edge out . If the desired edge is different from the factory setting, use the following steps to change it(Fig.#16).

  • Page 15: Maestro Control

    Fig. #16 Maestro Control Plumbing and Electrical The gas control system is located beneath the fireplace, below an access panel in the firebox bottom and the secondary floor (if installed). The fireplace is operated via a wall switch and a hand held remote control unit. The wall control is connected to the fireplace by a 25 ft.
  • Page 16 9. Route the communication cable as required to the wall control electrical box. Fig. #20 10. Attach the communication cable to the wall control. (Fig. #20) 11. Fasten the wall switch to the electrical box. 12. Fasten the faceplate to switch 13.
  • Page 17 Pre-Purge Mode Fig. #24 For use with a power vent only. Follow these instructions to activate the power vent pre-purge feature. This feature must be activated for the safe operation of an appliance equipped with a power vent. Switching to the power vent pre-purge mode: To turn feature ON and OFF, press and hold the STANDING PILOT button on the...

  • Page 18: Gas Supply

    Gas Supply Servicing of the appliance can be performed from inside the unit and through the access panel located in the firebox bottom. Caution: The gas line should be installed by a qualified service person in accordance with all building codes. This section is intended as a guide for qualified technicians installing this GAS VALVE INLET appliance.

  • Page 19: Venting

    Venting NOTE: Optional Power Vents (TCVT.PVOB2,TVCT.PVOC1,TCVTPOVC2, TCVT.PVOC3) require different venting. Please refer to Power Vent manuals pages 20 and 31. Various combinations of vent runs may be used. For optimum performance and flame appearance, keep the vent length to a minimum and limit the number of elbows. Connections between each vent system component must be tightly joined, secured with sheet metal screws and sealed with high temperature self adhesive tape.

  • Page 20: Tcvt.pvoc Power Vent Installation

    TCVT.PVOC Power Vent Installation Power Vent Installation Power Vent Installation PAINT: Locate the fireplace as per the main instructions supplied. The vent terminal comes pre-painted Make the following modifications to add the components used with the Flush with Thurmalox 230 Series paint by Mount Power Vent Kits.

  • Page 21: Venting Length

    Venting Length Venting Length TCWS.54CSTE POWER VENT 0 - 6’ 6’- 25’ 25’-110’ TCVT.PVOC1 TCVT.PVOC2 TCVT.PVOC3 TCWS.54CSTE 220313-68...

  • Page 22: Minimum Vent Length Chart

    Minimum Vent Length Chart Fig. #2 Minimum Rise Pipe Min. From Floor to Flue Center Length Pipe Length TCWS54 CSTE 49” 0” 3 feet 61” 12” 2 feet 73” 24” 1 foot This power vent kit is used with MODEL:TCWS.54CSTE Vent Terminal Minimum Clearances Fig.

  • Page 23: Horizontal (Side Wall) Venting

    Horizontal (Side Wall) Venting CAUTION: This terminal is designed to be flush, This kit uses either Simpson Duravent GS direct vent pipe, Secure Vent or protruding to the finished outside wall. Under circumstances direct vent pipe, Selkirk Direct-temp vent pipe or ICC Exceldirect vent pipe should this terminal be recessed with a 5”...
  • Page 24 Fig. #5 CAUTION: The rise and run combination and the number of elbows must not exceed specifications in Fig #1 and Fig #2. Fig. #7 INNER WALL PLATE 14 7/8” 7 7/8” SEAL WITH SILICONE ON ALL FOUR SIDES 14 5/8” NOTCH AT THE TOP Fig.
  • Page 25 7. For wall thicknesses greater than 8” and up to a maximum of 16 1/2” , Fig. #9 attach the inner wall plate to the wall sleeve assembly, using the four screws privided (Fig #8). Then slide this assembly over the terminal with the notch at the top (Fig #9 &...

  • Page 26: Control System Connection

    Control System Connection ACCESS PANEL The gas control system is located beneath the fireplace, below an access panel in the firebox bottom and the secondary floor (if installed). The fireplace is operated via a wall switch and a hand held remote control unit. The wall control is connected to the fireplace by a 25 ft.

  • Page 27: Fan Wiring

    Fan Wiring The Flush Mount Power Vent assembly has an electrical connector block mounted internally. The external wiring from the main voltage/control module should be connected to this block. Follow the steps below to access this block. 1. Remove the 2 top and 2 bottom screws securing the end cap only.

  • Page 28: Terminal Dimensions

    Dimensions 13 7/8” 1 5/16” PAINT: 6 11/16” The vent terminal comes pre-painted with Thurmalox 230 Series paint by 16 7/8” Dampney Co., but can be painted to match your wall finish color using high temperature paint that can 7 7/8” withstand temperatures of at least 250 degrees fahrenheit or 120 degrees Celcius.

  • Page 29: Venting Components

    Venting Components SIMPSON DURAVENT COMPONENTS SECURE VENT COMPONENTS Number Description Number Description 1208 6” Pipe Length SV5L6 6” Pipe Length 1207 9” Pipe Length SV5L12 12” Pipe Length 1206 12” Pipe Length SV5L24 24” Pipe Length 1204 24” Pipe Length SV5L36 36”...

  • Page 30: Wiring Diagram

    Wiring Diagram NOTE THIS WIRING DIAGRAM IS FOR TCVT.PVOC AND TCVT.PVOB2 POWER VENT MODELS TCWS.54CSTE 220313-68...

  • Page 31: Tcvt.pvob2 Power Vent Installation

    TCVT.PVOB2 Power Vent Installation NOTE THIS POWER VENT IS FOR VERTICAL Locate the fireplace as per the main instructions supplied. Make the following modifications to add the components used with the Power Vent (THROUGH ROOF) kits. This kit can only be used in conjunction with the “B” & “C” series versions of TERMINATION ONLY Town and Country Fireplaces.

  • Page 32: Vertical(Through Roof) Installation

    Vertical (Through Roof) Venting Vertical installations must use the optional TCVT.PVVCA vertical adaptor box in conjunction with this kit. The vertical adaptor box can only be installed on a flat surface. Sloped surfaces require the construction of a chase which provides the minimum interior, square opening of 11”...

  • Page 33: Vertical (Through Roof) Venting

    Vertical (Through Roof) Venting Fig. #53 Part F Vertical Rain Cap TCVT.8074 MUST ALIGN #8 x 1/2" S.S. (16 Required) Power Vent TCVT.PVOB2 NOTE: Holes to secure rain cap are not predrilled Part D Junction Box Cover Part E Exhaust Shield - DISCARD - Part C Drip Shield...

  • Page 34: Vent Pipe Sealant

    Vent Pipe Sealant Fig. #54 APPROVED “HIGH TEMP.” VENT PIPE SELF-ADHESIVE TAPE (SUPPLIED) All outer joints of the vent pipe must be sealed with the approved "High Temperature" self- adhesive aluminium tape provided. Wrap the tape completely around the joint and press firmly in place.

  • Page 35: Optional Tranquility Burner

    Optional Tranquility Burner Contents of Package: 3.4 LBS SAND HARDWARE PACK PILOT ROCK BURNER ASSEMBLIES BURNER TRAY ASSEMBLY PEBBLE SETS SECONDARY FLOOR HALVES WITHOUT LIGHTS TRAY LEGS TCWS.54CSTE 220313-68...
  • Page 36 Installation: ATTACH HERE AND ON OPPOSITE SIDE If converting to propane see conversion in- Fig #55 structions on page #44 before proceeding. Install one side of the secondary floor as shown. Repeat with the other side but do not put in the two center screws until you put the center tray leg in place (Fig.
  • Page 37 Fig #58 NOTE: check air shutter for correct fuel setting before proceeding further. Both burners are the same. Fully closed for natural gas. 13/64 (0.2)” open for LP. Install burners as shown in Fig. #58. Be sure to engage the venturis onto the orifices in the manifold and rest burners together on the center tray leg.
  • Page 38 Install burner tray as shown in Fig. #61 Fig #61 using 8 screws. Secure tray around pilot first then the other 6 screws. SECURE PILOT HERE FIRST Fig #62 Place sand into the burner tray and brush smooth. Use caution not to get sand near the burner ports (Fig.
  • Page 39 Each rock has a slot in it’s base and Fig #67 Fig #63 is marked with a letter and an arrow. (Fig. #63) Place each rock as per the following Fig #64 Fig #68 photographs, start from the right hand side of the burner and ensure that the arrow on each rock points towards the same side of the fireplace (Fig.
  • Page 40 11. Place the fifth set of rocks randomly Fig #73 Fig #71 around the burners in the sand as desired. 12. Place the pilot rock over the pilot with the opening facing the center of the burner . Fig #72 Fig #74 Fig.

  • Page 41: Propane Conversion

    MINIMUM RATE SCREW (5005.16) convert as follows using the compo- Kit # TCWS.54STLP for use with model: Pour nents supplied with the burner: utilise avec du modèle: TCWS54ST Date: ______________________ By / Par: ___________________ This appliance was converted LP GAS/...
  • Page 42 6. Slide the pilot adjustment band over and Fig #83 Fig #84 ensure that the hole in the orifice band is showing. Fig. #83 shows NG position Fig. #84 shows LP position. LP POSITION NG POSITION Fig #85 Fig #18 Remove the secondary floor on the control compartment side and remove the access panel, 9 screws, and set...
  • Page 43 13. Check all connections for leaks. ADD DATE Fig #90 ADD NAME Kit # TCWS.54STLP for use with model: Pour utilise avec du modèle: TCWS54ST Date: ______________________ By / Par: ___________________ This appliance was converted LP GAS/ to PROPANE GAS with...

  • Page 44: Optional Black Diamond Burner

    Optional Black Diamond Burner Contents of Package: IMPORTANT: THESE INSTRUCTIONS ARE TO REMAIN WITH THE HOMEOWNER These instructions are supplementary to the Installation and Operating Instructions supplied with the fi replace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions.
  • Page 45 Installation: If conver ting to propane see Fig #91 PILOT HOLE conversion instructions on page #43 before proceeding. Install the secondary floor on the side away from the gas connections first. 2. Insert the wires leading from the secondary floor half through one of the grommets in the bulkhead plate.
  • Page 46 Remove the panel retainer clips from Fig #94 both sides of the upper firebox(Fig. #94). PANEL RETAINER CLIP. Fig #95 Insert both side panels. (Fig. #95) NOTE: PROCEED TO AND FOLLOW IN- STRUCTIONS IN “GAS PRESSURE CHECK” SECTION ON PAGE 51 BEFORE INSTALLING BURNER TRAY AND MEDIA.
  • Page 47 11. Place the two porcelain strips, supplied Fig #97 with the panel set, into the fireplace as shown in Fig. #97 with the narrow edge facing the center of the fireplace. 12. Spread the glass media evenly over the entire mesh tray, leaving the small protrusion above the pilot clear of glass.

  • Page 48: Gas Pressure Check

    Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from the supply pressure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. If installed, remove all media and the Fig #99 burner tray.

  • Page 49: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel. For LP see Pg.44. Some adjustment may be nec- essary to obtain desired flame and to eliminate carbon deposits. Evaluate flame appearance after the fireplace has reached operating temperature.

  • Page 50: Firebox Panels Installation

    Firebox Panels Installation Fig. #102 RETAINING CLIP Remove side panel securing tabs for both sides in upper firebox. (Fig. #102) Fig. #103 Place bottom of side panel in first then tip up into vertical position (Fig. #103). Attach the side panel securing tabs previously removed. Repeat steps 2 & 3 with other side panel.(Fig.

  • Page 51: Finishing Touch Trim Kit Instructions

    Finishing Touch Trim Kit Instructions Place two smaller magnets on back of each side rail. Place two larger magnets on back of the top and bottom rails. Attach the side rails. Even the ends up with the door frame. Attach the top and bottom rails and adjust so mitres are even at the corners. Place TC magnetic logo in bottom right corner.

  • Page 52: Lighting Instructions

    Voir les instructions d'installation et d'utilisation qui accompagnent l'appareil. 180612 5051.175 5-TCWS54ST First Fire When lit for the first time, the fireplace will emit a slight odour for a couple of hours. This is due to the curing of paints, sealants and lubricants used in the manufacturing process.

  • Page 53: Maestro Control System Remote Control Initial Setup

    Maestro Control System Remote Control Initial Setup This fireplace is supplied with a wall control Fig. #106 Fig. #107 and hand held remote control. Please note only genuine Town & Country Fireplace wall controls and hand held remote controls can be used on this fireplace.

  • Page 54: Maestro Control System - Operation

    Childproof Lock Fig. #109 An additional feature of this remote control is the childproof lock. To activate this system press and hold the timer and thermostat buttons for approx. 5 seconds until the “lock” symbol ap- pears on the remote display. (Fig. #109) The remote control hand set buttons are now locked and the lock symbol will reappear every time a button is pressed on the remote control until the timer and thermostat buttons are pressed and held again.
  • Page 55 Program Mode Fig. #111 Fig. #113 (To preset up to two on and off periods per day) The program mode has two settings for weekdays and two for weekends. The hand held remote comes with the following pre programmed settings: Weekday Program (Monday through Friday) Program one (P1) turns ON at 7:00am and...
  • Page 56 Thermostatic Mode Fig. #115 Fig. #117 THERMOSTATIC MODE THERMOSTATIC BUTTON (Only for use where permitted) BUTTON (Operates the fireplace within a set tem- perature range) The fireplace is shipped with thermostatic mode function deactivated. If this function is permitted for use in your area it can be acti- vated by depressing the recessed button on the back of the hand held remote.

  • Page 57: Maintenance

    APPENDIX Maintenance CAUTION: Turn off gas and electrical power supply (if applicable) and allow ample time for unit to cool before servicing appliance. It is recommended that the fireplace and its venting should be inspected at least once a year by a qualified service person. Glass Panel: Warning: Do not operate fireplace with glass panel removed, cracked or broken.

  • Page 58: Replacement Parts - Tcws.54Cste

    Replacement Parts - TCWS.54CSTE (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. TCWS BODY ASSEMBLY ......TCWS.54CSTE FINISHING TOUCH TRIM KIT..TCRP.54WSTRIMKIT GLASS ASSEMBLY (c/w gasket) ..GLAS.2062ASSY ORIFICE (2pcs) ........5021.332A FRAMING KIT........TCWS.54STFRKIT MAIN GAS SUPPLY TUBE (1pcs) ..5019.223 PANEL SETS BLACK PORCELAIN ......TCPN.54STBK BROWN PORCELAIN .......TCPN.54STCB...

  • Page 59: Replacement Parts - Tranquility Burner

    Replacement Parts - Tranquility Burner (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM ..DESCRIPTION ..........PART NO. #1..TRANQUILITY BURNER KIT..TCWS.54NGST04C #2..PEBBLE ASSEMBLY(5 boxes)..5096.921 #3..SAND (Two Bags) ......TC42.SAND34 #4..PILOT ROCK, BLACK........8421-A ....PILOT ROCK, GREY ........8422-A NOT SHOWN KIT CONTENTS: TCWS.54CSTE 220313-68...

  • Page 60: Replacement Parts - Black Diamond Burner

    Replacement Parts - Black Diamond Burner (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM ..DESCRIPTION ............PART NO. #1..BLACK DIAMOND BURNER ..TCWS.54NGST03C #2..GLASS MEDIA (3 required) ....TCRP.501201 #3..LIGHT BULB ..........5033.713 NOT SHOWN KIT CONTENTS: TCWS.54CSTE 220313-68...

  • Page 61: Replacement Parts - Tcvt.pvoc

    Replacement Parts Replacement Parts - TCVT.PVOC ITEM PART No. DESCRIPTION TCVT.7895 FLUSH MOUNT POWER VENT ASSY. 7895 BLOWER GRILL 7895.5 GRILL COVER 8020.5 INNER WALL PLATE TCVT.9280 PRESSURE SWITCH ASSEMBLY 5068.8065 1/4” LDF PAPER GASKET TCVT.7893 TCVT.FMPV OUTER CASING ASSEMBLY TCVT.502464 BLOWER, POWERVENT TCVT.80285WLD...

  • Page 62: Replacement Parts - Tcvt.pvob2

    Replacement Parts - TCVT.PVOB2 ITEM PART No. DESCRIPTION ITEM PART No. DESCRIPTION 5024.62 BLOWER POWER VENT INSIDE COVER 5027.15 PRESSURE SWITCH EXHAUST SHIELD 3/8” STRAIN RELIEF SECONDARY RAIN SHIELD #8 x 1/2” PAN HD SKT 18.8 STAINLESS STEEL JUNCTION BOX ID x .379 OD x .062 THK TOP COVER 1/4 MED LOCKWASHER 18.8 SS...

  • Page 63: Replacement Parts - Maestro Control System

    Replacement Parts – Maestro Control System (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM ..DESCRIPTION ..........PART NO. ITEM ..DESCRIPTION ..........PART NO. #1..CONTROL ASSEMBLY KIT ....TCRP.8470 #5..COMMUNICATION CABLE KIT ..5005.06 #2..BULKHEAD ASSEMBLY KIT ....TCRP.8485 #6..

  • Page 64: Light Wiring Diagrams

    Light Wiring Diagrams Fig. #121 UPPER LIGHTS MEDIA TRAY LIGHTS (Optional) GREEN GREEN TERMINAL TERMINAL BLOCK BLOCK (UPPER LIGHTS) (FLOOR LIGHTS) GROUND GROUND WALL WALL SWITCH SWITCH TCWS.54CSTE 220313-68...

  • Page 65: Safety Label Location

    Maximum supply pressure / Pression maximum d’alimentation: 13.9 in/wc / 13.9 po/c.e. 13.9 in/wc / 13.9 po/c.e. MODEL/ (3.45 kPa) (3.45 kPa) TCWS54ST MODELE: Manifold pressure / Pression de la tuyauterie: Maximum 3.5 in/wc / 3.5 po/c.e. 11.0 in/wc / 11.0 po/c.e.
  • Page 66 TCWS.54CSTE 220313-68...
  • Page 67 TCWS.54CSTE 220313-68...
  • Page 68 Technical support: 1-250-748-1184 Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
