Package Contents; Requirements; Hardware Review - LevelOne KVM-0223 User Manual

English

Package Contents

1. KVM-0223
2. User Manual
3. Quick Installation Guide

Requirements

Console
A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be using
on any computer in the installation
A USB Keyboard
A USB Mouse
Computers
The following equipment must be installed on each computer that is to be connected to the
system:
A VGA, SVGA or Multisync video port
A USB Type A port

Hardware Review

1. Port LEDs
2. KVM Cables
3. Speaker Jack
4. Console Port
5. USB keyboard/Mouse connector
6. Speaker Plug
7. Video Connector
1
4
2
3
5
6
7
