LevelOne Palm-Sized
KVM Switch
KVM-0205 KVM-0405
User's Guide
Table of Content
Overview.......................................................1
Features.......................................................2
Console Connection........................................3
Computers Connection....................................5
Initial Power-up..............................................6
■ Operations
Front Panel operation.......................................7
Hot-key commands..........................................7
■ Appendices
Specifications...............................................10
Troubleshooting............................................11
Please read this manual thoroughly
and follow the Installation procedures to
prevent
any
damage
to
Palm-Sized KVM or any connecting device.
the
LevelOne
Advertisement
Table of Contents
Related Manuals for LevelOne ViewCon KVM-0205
Summary of Contents for LevelOne ViewCon KVM-0205
-
Page 1: Table Of Contents
LevelOne Palm-Sized KVM Switch KVM-0205 KVM-0405 User's Guide Table of Content ■ Introduction Overview……………...……………………………...1 Features………………….………………………..….2 ■ Installations Console Connection……………….………………...3 Computers Connection……………….……….….…5 Initial Power-up……………….………………..…….6 ■ Operations Front Panel operation…………...…………...…..….7 Hot-key commands…...…………...……………..….7 ■ Appendices Specifications………………..……………………...10 Troubleshooting..………………..……….…………11 Please read this manual thoroughly and follow the Installation procedures to... -
Page 2: Introduction
There is no interface card and software to install and the LevelOne Palm-Sized KVM is independent of the computer operating system. Ready to run right out of the box, this Kit comes with everything you need - a switch and complete cable sets, just hook them up and go. -
Page 3: Installations
Then connect your VGA monitor cable directly to the HDB-15 port as shown in figure 1. Figure 1: KVM-0205 Console Connection The figure 2 shows 4-port LevelOne Palm-Sized KVM console connection. Figure 2: LevelOne KVM-0405 Console Connection The multi-sync monitor must be capable of synchronizing with the computer's video signal. -
Page 4: Computers Connection
HDB-15 connector and the other side has three connectors (one HDB-15 and two mini-DIN6s). The PC 1 ~ PC 4 marks on the LevelOne Palm-Sized KVM are for computer connection as shown in figure 3. Figure 3: COMPUTER Connection NOTE: If your computer uses an AT style keyboard, you will need an "AT-to-PS/2 keyboard adapter"... -
Page 5: Front Panel Operation
Hot-key command is a short keyboard sequence to select a computer or to activate computer scanning. LevelOne Palm-Sized KVM interprets keystrokes for hot-keys all the time. A hot-key sequence starts with two left Ctrl keystrokes followed by one or two more keystrokes. -
Page 6: Specifications
NOTE: Scan Rate is set to default of 3 seconds after LevelOne Palm-Sized KVM loses power, i.e., all connected computers are turned off. adjust keyboard typematic rate (characters/sec), this setting over-rides that of BIOS and any operating system: left Ctrl + left Ctrl + F4 There are four options: 10, 15, 20 and 30 characters/sec. -
Page 7: Troubleshooting
Symptom Causes Solutions Keyboard or Improper power-up Press and hold down the mouse does not sequence. push button for 3 LevelOne work Keyboard or seconds, the Palm-Sized KVM mouse not properly initialized. re-initialize the keyboard and mouse. If problem persists,...
