LevelOne FEP-0311 User Manual

FEP-0311
3-Port Fast Ethernet PoE Switch, 2
PoE Outputs
User's Manual
FCC Warning
This device has been tested and found to comply with limits
for a Class A digital device, pursuant to Part 15 of FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference when the
equipment is operated in a commercial environment.
This equipment generates and radiates radio frequency
energy and, if not installed and used in accordance with
the user's manual, it may cause interference in which case
users will be required to correct interference at their own
expenses.
CE Mark Warning
This is a Class A product. In a domestic environment, this
product may cause radio interference in which case the
user may be required to take adequate measures.
Energy Saving Note of the Device
This power required device doesn't support Standby
mode operation. For energy saving, please remove the
power cable to disconnect the device from the power
circuit. Without removing power cable, the device will
consume power from the power source.
WEEE Warning
To avoid the potential effects on the environment and
human health as a result of the presence of
hazardous substances in electrical and electronic
equipment, end users of electrical and electronic
equipment should understand the meaning of
crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste; WEEE has to
be collected separately.

Package Contents

Thank you for purchasing our FEP-0311 series PoE
Switch.
Before installation, please check the contents of your
package for the following parts:
1. FEP-0311 x 1
2. User's Manual x 1
3. Power Adaptor x 1
4. Power cord x 1
5. Rubber Feet x 4

Product Introduction

The FEP-0311 series is a 2-Port Adjustable 10/100Mbps
802.3af/at Power over Ethernet + 1-port 10/100Mbps
Uplink switch with a total power of 36/65/90 watts.
FEP-0311 series features IEEE 802.3af and IEEE 802.3at
High Power PoE capabilities that offer a combined power
output of upto 30w over Cat.5e/6 Ethernet cable.
0311 series is flexible to adjust PoE on/off via DIP switch
on device itself. Meanwhile, the PoE output could supply
60 watts. max. to powered device when only one PoE port
is enabled. Furthermore, users could also extend wire
coverage up to 600 meters with PoE extender or PoE
repeater in the network.

Key Features

。Complies with IEEE 802.3, 10BASE-T, IEEE 802.3u,
100BASE-TX
。Complies with IEEE802.3af/at Standard
。3-Port 10/100Mbps Fast Ethernet Switch
。2-Port supports Power over Ethernet
。Supports PoE power up to 50 watts for each PoE port
。External Power 36/65/90Watts
。Could supply 50 watts max. PoE output when only one
PoE port is enabled
。PoE on/off selectable via a DIP switch on the unit
。Over Current Protection / Over Temperature Protection /
Over Voltage Protection
。Remote power feeding up to 100meters
。Could extend up to 600 meters with PoE Extender or
PoE Repeater in the network
。Made of metal and desktop / wall-mount design
