LevelOne
User Manual
KVM-0290
2-Port USB/HDMI Cable KVM Switch
Version 1.0

Advertisement

Table of Contents
loading

Related Manuals for LevelOne KVM-0290

Summary of Contents for LevelOne KVM-0290

  • Page 1 LevelOne User Manual KVM-0290 2-Port USB/HDMI Cable KVM Switch Version 1.0...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ............................3 1.1............................. 3 EATURES 1.2..........................4 HYSICAL IAGRAM 1.3........................... 4 ACKAGE ONTENTS SPECIFICATIONS ............................. 5 INSTALLING THE USB/HDMI CABLE KVM SWITCH ................ 6 3.1........................6 YSTEM EQUIREMENTS 3.2........................6 ARDWARE NSTALLATION 3.3.

  • Page 3: Introduction

    1. Introduction Thank you for purchasing 2-port USB/HDMI Cable KVM Switch that employs HDMI display technology for use with high definition digital monitors and HDTVs. With integrated digital audio, the KVM Switches also allow users to experience high-definition sound. You now have a high quality, durable system that enables you to control two computers from one console (USB Mouse, Keyboard, and Monitor).

  • Page 4: Physical Diagram

    1.2. Physical Diagram PC connection 2 LED Indicators (Green) PC connection 1 LED Indicators (Green) PC 1 LED Indicators (Blue) PC 2 LED Indicators (Blue) USB Mouse HDMI Output USB Keyboard PC2 Selection Push Button PC1 Selection Push Button  Active PC LED Indicators: BLUE LED indicates that the 2-port USB/HDMI Cable KVM Switch is switched...

  • Page 5: Specifications

    2. Specifications Specification Number Of Computers Controlled 2 Selection Method USB Keyboard Hot Key and Push button USB Versions supported USB 1.1 / 2.0 Blue for PC Selection LEDs Green for PC ON-Line Selection 2 x Type A USB Connectors PC Connectors Video 2 x HDMI (male)

  • Page 6: Installing The Usb/Hdmi Cable Kvm Switch

    3. Installing the USB/HDMI Cable KVM Switch 3.1. System Requirements A PC with USB port and 1 HDMII port. Graphic card support the audio output over the HDMI port(Recommend). Windows 98 or later, Mac OS 8/9/OS X, Linux Kernel 2.3 or later. USB Keyboard and mouse.
  • Page 7 A. Press “Next” to Continue. (Ref. Fig. A) Fig. A B. Select “Search for the best driver for your device” and press “Next” to continue. (Ref. Fig. B). Fig. B C. Please insert the “Windows 98” CD into your CD-ROM drive. Click “CD-Rom drive”...
  • Page 8 D. Press “Next” to start the installation process. (Ref. Fig. D) Fig. D E. Sometimes Windows cannot locate the necessary driver automatically. So you need to choose “Browse” to specify the location of the driver on your “Windows 98” CD manually. (Ref.

  • Page 9: Operation

    G. Press “Finish” and Windows has finished installing the USB Human Interface Device driver for PS/2 keyboard & mouse. (Ref. Fig. G) Fig. G 4. Operation The 2-port USB/HDMI Cable KVM Switch can switch the keyboard, mouse audio and video by pushing button and Hot Key. 4.1.
  • Page 10 Notification of Compliance Appendix A Europe - EU Declaration of Conformity For complete DoC please visit http://global.level1.com/downloads.php?action=init GPL License Agreement GPL may be included in this product, to view the GPL license agreement goes to http://download.level1.com/level1/gpl/GPL.pdf For GNU General Public License (GPL) related information, please visit http://global.level1.com/downloads.php?action=init...
