- Page 1 ID70 Motherboard Mini-ITX Fanless SBC w/Intel Atom D2550 1.86GHz Processor, VGA, LVDS, Dual Giga Ethernet, PCI and Mini-PCIe Interface. User Manual / Engineering Spec. Version 1.2...
-
Page 2: Fcc Statement
ID70 Motherboard User Manual / Engineering Spec. FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions： This device may not cause harmful interference. This device must accept any interference received including ... -
Page 3: Copyright Notice
Applications that are described in this manual are for illustration purposes only. Winmate Communication Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification. -
Page 4: Packing List
ID70 Motherboard User Manual / Engineering Spec. Packing List Before using this Motherboard, please make sure that all the items listed below are present in your package： ID70 Motherboard User Manual HDD SATA Cable User’s Manual & Driver CD If any of these items are missing or damaged, contact your distributor or sales representative immediately. -
Page 5: Safety Precautions
ID70 Motherboard User Manual / Engineering Spec. Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. - Page 6 ID70 Motherboard User Manual / Engineering Spec. Safety and Warranty Please read these safety instructions carefully. Please keep this user's manual for later reference. Please disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth.
-
Page 7: Revision History
ID70 Motherboard User Manual / Engineering Spec. Revision History Version Date Note Author 2012.1.13 Initial Draft Henry Hsu Revise Panel1 Pin Define 2014.7.18 Jimmy Chen Revise content 2015.5.08 Tom Huang ID70 Motherboard User Manual... -
Page 8: Table Of Contents
ID70 Motherboard User Manual / Engineering Spec. Contents CHAPTER 1 GENERAL INFORMATION ........2 ................2 NTRODUCTION ....................2 EATURE ............3 OTHERBOARD PECIFICATIONS ................4 UNCTION LOCK ................ 5 OARD DIMENSIONS CHAPTER 2 INSTALLATIONS ............7 （SO-DIMM）I ......7... -
Page 9: Chapter 1 General Information
ID70 Motherboard User Manual / Engineering Spec. General Information This chapter includes the ID30 Motherboard background information. Sections include: Introduction Feature Motherboard Specification Function Block Board Dimensions ID70 Motherboard User Manual... - Page 10 Connector ; Four Pin Header ) .Additionally, ID70 SBC build-in a 12V DC-IN power adapter. Thus, the ID70 SBC is designed to satisfy most of the applications in the industrial computer market, such as Gaming, POS, KIOSK, Industrial Automation, and Programmable Control System. It is a compact design to meet the demanding performance requirements of today’s business and...
-
Page 11: Motherboard Specifications
ID70 Motherboard User Manual / Engineering Spec. Motherboard Specifications CPU Type Intel Atom Dual Core D2550 1.86GHz Processor CPU Speed 1.86GHz Chipset Intel NM10 BIOS AMI 16Mbit Flash Graphic Intel® Graphic Accelerator 3650 support DX10, OGL2.0 LCD interface Single-channel 24 bit LVDS Up to 1440 x 900 @ 60Hz VGA mode：... -
Page 12: Function Block
ID70 Motherboard User Manual / Engineering Spec. Function Block SO-DIMM x 2 DDR3 800/1066 Max.4GB D2550 CPU 1GB/s Intel NM10 480MB/s LVDS Chipset Audio Super IO SATA II Mini PCI BIOS ID70 Motherboard User Manual... -
Page 13: Board Dimensions
ID70 Motherboard User Manual / Engineering Spec. Board dimensions ID70 Motherboard User Manual... -
Page 14: Chapter 2 Installations
ID70 Motherboard User Manual / Engineering Spec. Installations This chapter provides information on how to use the jumps and connectors on the ID70 Motherboard. The Sections include: Memory Module Installation I / O Equipment Installation Setting the Jumpers ... - Page 15 Chapter 2 Installations Memory Module（SO-DIMM）Installation The ID70 Motherboard provides one 204-pin SODIMM slot. The socket supports up to 4GB DDR3 800/1066 SDRAM. When installing the Memory device, please follow the steps below： Step.1. Firmly insert the SO-DIMM at an angle into its slot. Align the SO-DIMM on the slot such that the notch on the SO-DIMM matches the break on the slot.
-
Page 16: I/O Equipment Installation
ID70 Motherboard User Manual / Engineering Spec. I/O Equipment Installation 2.2.1 12V DC-IN The Motherboard allows plugging 12V DC-IN jack on the board without another power module converter under power consumption by Intel Atom D2550 1.86GHz Processor in NM10 chipset. -
Page 17: Jumpers And Connectors
ID70 Motherboard User Manual / Engineering Spec. Jumpers and Connectors Inverter 2 x Mini PCIe slot (for WLAN, 3G Module) JP6,7,8 System Fan JP3,4 LVDS LPT port COM2 COM5、6 CPU Fan 、 ID70 Motherboard User Manual... - Page 18 ID70 Motherboard User Manual / Engineering Spec. BOTTOM ID70 Motherboard User Manual...
-
Page 19: Jumper Setting
ID70 Motherboard User Manual / Engineering Spec. Jumper Setting A pair of needle-nose pliers may be helpful when working with jumpers. If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes. Generally, you simply need a standard cable to make most connections. - Page 20 ID70 Motherboard User Manual / Engineering Spec. 2.4.3 JP3 : LCD Panel Voltage Select 2.4.4 JP4 : Back Light PWR 2.4.5 JP5 : Clear CMOS 2.4.6 JP6 : PWM Level 2.4.7 JP7 : Brightness Control(DC/PWM) ID70 Motherboard User Manual...
- Page 21 ID70 Motherboard User Manual / Engineering Spec. 2.4.8 JP8 : Brightness Control(VR/Software) ID70 Motherboard User Manual...
-
Page 22: Connectors And Pin Assignment
ID70 Motherboard User Manual / Engineering Spec. Connectors and Pin Assignment The table below lists the function of each of the board’s connectors. Label Function Note LVDS LVDS Connector LCD Output 2x10 Pin, 1.25mm Digital Panel Backlight Brightness CN16 3x1 header, pitch 2.54mm... - Page 23 ID70 Motherboard User Manual / Engineering Spec. 2.5.1 LVDS: LVDS Connector Pin No. SYMBOL Pin No. SYMBOL LVDS_TX0_DN LVDS_TX0_DP LVDS_TX1_DN LVDS_TX1_DP LVDS_TX2_DN LVDS_TX2_DP LVDS_CLK_DN LCDVDD LVDS_CLK_DP LCDVDD LVDS_TX3_DN LVDS_TX3_DP LCDVDD 2.5.2 CN16: Digital Panel Backlight Brightness Control Pin No. SYMBOL...
- Page 24 ID70 Motherboard User Manual / Engineering Spec. 2.5.3 CN19: Inverter Power Pin No. SYMBOL +12V +12V +12V Black Light Control Black Light EN 5V 2.5.4 COM5、6: Dual Output The serial port COM5、6, which is RS232 only , is the Fintek I/O serial port.
- Page 25 ID70 Motherboard User Manual / Engineering Spec. 2.5.6 CPU_FAN: FAN CONNECTOR 2.5.7 PANEL1: Front Panel System Function Connector Without power/reset OSD, short circuit pin 5 and 6 together to boot up the motherboard. SYMBOL SYMBOL HD_LED+ PW_LED+ HD_LED- PW_LED- PW_BT1...
- Page 26 ID70 Motherboard User Manual / Engineering Spec. 2.5.11 COM2: Serial port COM2 SYMBOL SYMBOL NRI1A NDTR1A NCTS1A NTXD1A NRTS1A NRXD1A NDSR1A NDCD1A 2.5.12 DVI1: DVI connector Pin No. SYMBOL Pin No. SYMBOL TMDSB_DATA0- TMDSB_DATA0+ DVIC_LVDS_DET TMDSB_DATA1- DVIC_BKLTEN TMDSB_DATA1+ DVIC_VDDEN TMDSB_DATA2-...
- Page 27 ID70 Motherboard User Manual / Engineering Spec. 2.5.14 Switch 2 Signal Name 2.5.15 Mini PCIe slot for WLAN Pin Number Signal Name Pin Number Signal Name +V3.3DX_SSD +V1.5S_SSD SATA_RXP2 +V3.3DX_SSD SATA_RXN2 +V1.5S_SSD SATA_TXN2 SATA_TXP2 +V3.3DX_SSD +V3.3DX_SSD SATA2_DEVSLP +V1.5S_SSD SSD_LED# +V3.3DX_SSD +V3.3DX_SSD...
-
Page 28: Chapter 3 Graphic Driver Installation
ID70 Motherboard User Manual / Engineering Spec. Graphic Driver Installation This chapter offers information on the chipset software Installation utility Installation of Graphic Driver Panel Resolution Setting ID70 Motherboard User Manual... -
Page 29: Standard Cmos Feature
ID70 Motherboard User Manual / Engineering Spec. Chapter 3 Graphic Driver Installation 3.1 Standard CMOS Feature ID30 Motherboard is equipped with Intel NM10 Companion Device. The Intel Graphic Drivers should be installed first, and it will enable “Video Controller (VGA compatible). Follow the instructions below to complete the installation. - Page 30 ID70 Motherboard User Manual / Engineering Spec. Step.3. Click on “Next “ to install Driver. Step.4. Click on “Yes “ to agree License. ID70 Motherboard User Manual...
- Page 31 ID70 Motherboard User Manual / Engineering Spec. Step.5. Click on “Next “ to install Driver. Step.6. Click on “Next “ to install Driver. ID70 Motherboard User Manual...
- Page 32 ID70 Motherboard User Manual / Engineering Spec. Step.7. Click on “Yes, I want to restart this computer now“ to go on. ID70 Motherboard User Manual...
-
Page 33: Panel Resolution Setting
ID70 Motherboard User Manual / Engineering Spec. 3.2 Panel Resolution Setting Step.1. Right-click the desktop, and then click Properties. Step.2. In the Display Properties dialog box, click the Settings tab. Step.3. Click on “Monitor”. ID70 Motherboard User Manual... - Page 34 ID70 Motherboard User Manual / Engineering Spec. Step.4. Click on “Hide modes that this monitor cannot display” to remove this option. Step.5. Click on “Setting”, then could choose 32bit color qualify. ID70 Motherboard User Manual...
-
Page 35: Chapter 4 Chipset Driver Installation
ID70 Motherboard User Manual / Engineering Spec. Chipset Driver Installation This chapter offers information on the chipset software Installation utility Installation of Chipset Driver Further information ID70 Motherboard User Manual... -
Page 36: Standard Cmos Features
ID70 Motherboard User Manual / Engineering Spec. Chapter 4 Chipset Driver Installation 4.1 Standard CMOS Features Setp.1. Insert the CD that comes with the motherboard. Open the file document “Chipset Driver”. Setp.2. Click on “infinst_auto.exe“ to install driver. ID70 Motherboard User Manual... - Page 37 ID70 Motherboard User Manual / Engineering Spec. Click on “Yes “ to agree License Setp.3. Setp.4. Click on “Next“ to install driver. Setp.5. Click on “Next“ to install driver. ID70 Motherboard User Manual...
- Page 38 ID70 Motherboard User Manual / Engineering Spec. Step.7. Click on “Yes, I want to restart this computer now“ to go on. ID70 Motherboard User Manual...
-
Page 39: Chapter 5 Ethernet Driver Installation
ID70 Motherboard User Manual / Engineering Spec. Ethernet Driver Installation This chapter offers information on the Ethernet software installation utility. Sections include: Introduction Installation of Ethernet Driver ID70 Motherboard User Manual... - Page 40 ID70 Motherboard User Manual / Engineering Spec. Chapter 5 Ethernet Driver Installation Installation of Ethernet Driver The Users must make sure which operating system you are using in the ID30 Motherboard before installing the Ethernet drivers. Follow the steps below to...
- Page 41 ID70 Motherboard User Manual / Engineering Spec. Click on “Browse my computer for driver software“ to install driver. Step.4. Step.5. Choose the path to install driver. ID70 Motherboard User Manual...
- Page 42 ID70 Motherboard User Manual / Engineering Spec. Click on “Close“ and go on. Setp.6. ID70 Motherboard User Manual...
-
Page 43: Chapter 6 Audio Driver Installation
ID70 Motherboard User Manual / Engineering Spec. Audio Driver Installation This chapter offers information on the Audio software installation utility. Sections include: Introduction Installation of Audio Driver ID70 Motherboard User Manual... - Page 44 ID70 Motherboard User Manual / Engineering Spec. Chapter 6 Audio Driver Installation 6.1 Introduction The ALC888 series are high-performance 7.1+2 Channel High Definition Audio Codecs providing ten DAC channels that simultaneously support 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs.
- Page 45 ID70 Motherboard User Manual / Engineering Spec. Step.2. Click on “Yes“ to install driver. Click on “Yes, I want to restart my computer now” to finish installation. Step.3. ID70 Motherboard User Manual...
-
Page 46: Driver Installation
ID70 Motherboard User Manual / Engineering Spec. Fintek COM Port Driver Installation This chapter describes the step by step method to install the Fintek COM port driver. ID70 Motherboard User Manual... - Page 47 ID70 Motherboard User Manual / Engineering Spec. STEP 1.If the system is WIN7 please first do close UAC.(Refer following “Disabling User Account Control (UAC) in Windows 7”) STEP 2.Extract the Patch_0408.zip to a folder. STEP 3.Double-click batch file(patch.bat) will install driver.
- Page 48 ID70 Motherboard User Manual / Engineering Spec. To turn off UAC, move the slider to the Never notify position, and then click OK. If you're prompted for an administrator password or confirmation, type the password or provide confirmation. ID70 Motherboard User Manual...
- Page 49 ID70 Motherboard User Manual / Engineering Spec. To turn UAC back on, move the slider to choose when you want to be notified, and then click OK. If you're prompted for an administrator password or confirmation, type the password or provide confirmation.
-
Page 50: Chapter 7 Ami Bios Setup
ID70 Motherboard User Manual / Engineering Spec. AMI BIOS Setup This chapter describes how to set up the BIOS configuration ID70 Motherboard User Manual... - Page 51 ID70 Motherboard User Manual / Engineering Spec. Chapter 7 AMI BIOS SETUP Your computer comes with a hardware configuration program which called BIOS Setup that allows you to view and set up the system parameters. The BIOS (Basic Input / Output System) is a layer of the software called ‘firmware’...
-
Page 52: Advanced Setting
ID70 Motherboard User Manual / Engineering Spec. The Main BIOS setup image has two main frames. The left frame displays all the options that can be configured. Grayed-out options cannot be configured. On the contrary, options in blue can be configured. The right frame displays the key legend. - Page 53 ID70 Motherboard User Manual / Engineering Spec. PCI ROM Priority Selects the PCI Option ROM to launch in case Multiple Option ROMs (Legacy ROM and EFI Compatible ROM) are present. PCI Latency Timer Use this function to select the number of PCI bus clocks to be used for the PCI latency timer.
- Page 54 ID70 Motherboard User Manual / Engineering Spec. SETTING DESCRIPTION 32 PCI Bus Clocks Use this setting to program the PCI latency timer to 32 PCI bus clocks. 64 PCI Bus Clocks Use this setting to program the PCI latency timer to 64 PCI bus clocks.
- Page 55 ID70 Motherboard User Manual / Engineering Spec. ACPI Settings Enable ACPI Auto Configuration Enables or Disables BIOS ACPI Auto Configuration Default: Disabled Enable Hibernation Enables or Disables System ability to Hibernate. This option may be not effective with some OS.
-
Page 56: S5 Rtc Wake Settings
ID70 Motherboard User Manual / Engineering Spec. S5 RTC Wake Settings SETTING DESCRIPTION Wake system with Fixed Time System wake on alarm event. When enabled, System will wake on the hr: min:: sec specified. Wake system with Dynamic Time Options: Enabled, Disabled... - Page 57 ID70 Motherboard User Manual / Engineering Spec. CPU Configuration Hyper-threading Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology). When Disabled, only one thread per enabled core is enabled.
-
Page 58: Thermal Configuration
ID70 Motherboard User Manual / Engineering Spec. Thermal Configuration CPU Thermal Configuration > DTS SMM SETTING DESCRIPTION Disabled Uses EC reported temperature values Enabled Uses DTS SMM mechanism to obtain CPU temperature value Critical Temp Reporting(Out of spec) Uses EC reported temperature values and DTS SMM to handle out of... - Page 59 ID70 Motherboard User Manual / Engineering Spec. Critical Trip Point This value controls the temperature of the ACPI critical Trip point—the point in which the OS will shut the system off. Active Trip Point Lo Fan Speed ...
-
Page 60: Ide Configuration
ID70 Motherboard User Manual / Engineering Spec. IDE Configuration Configure SATA as Determines how SATA controllers(s) operate. The options are IDE and AHCI. ID70 Motherboard User Manual... - Page 61 ID70 Motherboard User Manual / Engineering Spec. Port0 Speed Limit Select Port0 AHCI Speed Limit. The options are No Limit, GEN1 Rate and GEN2 Rate. SATA Port 0/1 Enable or disable SATA Port. SATA Port 0/1 Hot Plug...
- Page 62 ID70 Motherboard User Manual / Engineering Spec. Intel Fast Flash Standy iFFS Support Enable or disable iFFS. ID70 Motherboard User Manual...
-
Page 63: Usb Configuration
ID70 Motherboard User Manual / Engineering Spec. USB Configuration Legacy USB support Enables Legacy USB support. AUTO option disable legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. ... - Page 64 ID70 Motherboard User Manual / Engineering Spec. Mass Storage Device: Mass storage device emulation type. ‘AUTO’ enumerates devices less than 530MB as floppies. Forced FDD option can be used to force HDD formatted drive to boot as FDD. ID70 Motherboard User Manual...
- Page 65 ID70 Motherboard User Manual / Engineering Spec. F81865 Super IO Configuration System Super IO Chip Parameters. Serial Port 1、2、3 、4、5、6 Configuration ID70 Motherboard User Manual...
- Page 66 ID70 Motherboard User Manual / Engineering Spec. Set Parameters of Serial Ports. User can Enable/Disable the serial port and Select an optimal settings for the Super IO Device. Enable or Disable Serial Port (COM) Default: Enable The watchdog timer circuit has to be triggered within a specified time by the application software.
- Page 67 ID70 Motherboard User Manual / Engineering Spec. GPIO Port Configuration ID70 Motherboard User Manual...
- Page 68 ID70 Motherboard User Manual / Engineering Spec. F81865 H/W Monitor Fan 1、2 Config smart fan mode, can choose 50,60 and 70 three degree mode ID70 Motherboard User Manual...
-
Page 69: Ppm Configuration
ID70 Motherboard User Manual / Engineering Spec. PPM Configuration EIST Enable/Disable Intel SpeedStep. CPU C state Report Enable/Disable CPU C state report to OS. ID70 Motherboard User Manual... - Page 70 ID70 Motherboard User Manual / Engineering Spec. C4 Exit Timing This option controls a programmable time for the CPU voltage to stabilize when exiting from a C4 state. ID70 Motherboard User Manual...
- Page 71 ID70 Motherboard User Manual / Engineering Spec. Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. Memory Frequency and Timing Can choose enable or disable MRC fast boot.
- Page 72 ID70 Motherboard User Manual / Engineering Spec. Intel IGD Configuration Auto Disable IGD Auto disable IGD upon external GFX detected. ID70 Motherboard User Manual...
- Page 73 ID70 Motherboard User Manual / Engineering Spec. IGFX-Boot Type Select the Video Device which will be activated during POST. This has no effect if external graphics present. DVMT ID70 Motherboard User Manual...
- Page 74 ID70 Motherboard User Manual / Engineering Spec. Intel's Dynamic Video Memory Technology (DVMT) takes that concept further by allowing the system to dynamically allocate memory resources according to the demands of the system at any point in time. The key idea in DVMT is to improve the efficiency of the memory allocated to either system or graphics processor.
- Page 75 ID70 Motherboard User Manual / Engineering Spec. PCI Express root port settings DMI Link ASPM Control The Desktop Management Interface (DMI) generates a standard framework for managing and tracking components in a desktop, notebook or server computer, by abstracting these components from the software that manages them.
- Page 76 ID70 Motherboard User Manual / Engineering Spec. Bootup NumLock State Select the keyboard NumLock State Default: On Quiet Boot Enable or Disable Quiet Boot Option. Default: Disable GateA20 Active UPON REQUEST – GA20 can be disabled using BIOS services. Always – do not allow disabling GA20;...
- Page 77 ID70 Motherboard User Manual / Engineering Spec. Administrator Password Set Setup Administrator Password. User Password Set User Password. ID70 Motherboard User Manual...
- Page 78 ID70 Motherboard User Manual / Engineering Spec. 5.5 Save & Exit Save Changes and Exit Exit system setup after saving the changes. Disacard Changes and Exit Exit system setup without saving any changes. Save Changes and Reset Reset the system after saving the changes.
- Page 79 ID70 Motherboard User Manual / Engineering Spec. Appendix Note1: Digital I/O Sample Code To find the Digital I/O Sample code, please refer to the IH70 driver DVD SDK or contact us. Note2: Watchdog Sample Code To find the Watchdog Sample code, please refer to the IH70 driver DVD SDK or contact us.
