- Page 1 ID30 Motherboard 3.5” Fanless SBC w/Intel Atom D2700 2.13GHz Processor, VGA, LVDS, Dual Giga Ethernet, and Mini-PCIe Interface. USER MANUAL Version 1.0...
-
Page 2: Fcc Statement
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at him own expense. ID30 Motherboard User Manual... -
Page 3: Copyright Notice
Applications that are described in this manual are for illustration purposes only. Winmate Communication Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification. -
Page 4: Packing List
In addition, free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products. Please do not hesitate to call or e-mail us. ID30 Motherboard User Manual... -
Page 5: Safety Precautions
CPU card. Modern electronic devices are very sensitive to static electric charges. As a safety precaution, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. ID30 Motherboard User Manual... - Page 6 F. The equipment has obvious signs of breakage. 15. Do not leave this equipment in an uncontrolled environment where the storage temperature is below -20° C (-4°F) or above 60° C (140° F). It may damage the equipment. ID30 Motherboard User Manual...
- Page 7 Revision History Version Date Note Author 2011.12.16 Initial Draft Henry Hsu ID30 Motherboard User Manual...
-
Page 8: Table Of Contents
............31 NSTALLATION OF THERNET RIVER CHAPTER 6 AUDIO DRIVER INSTALLATION......35 6.1 I ................. 35 NTRODUCTION ..........35 NSTALLATION OF UDIO RIVER CHAPTER 7 AMI BIOS SETUP ............42 7.1 A ................43 DVANCED ETTING VIII ID30 Motherboard User Manual... -
Page 9: General Information
General Information This chapter includes the ID30 Motherboard background information. Sections include: Introduction Feature Motherboard Specification Function Block Board Dimensions ID30 Motherboard User Manual... -
Page 10: Chapter 1 General Information
Header ) and Six Hi-Speed USB 2.0 connectors( Two Connector ; Four Pin Header ) .Additionally, ID30 SBC build-in a 12V DC-IN power adapter. Thus, the ID30 SBC is designed to satisfy most of the applications in the industrial computer market, such as Gaming, POS, KIOSK, Industrial Automation, and Programmable Control System. -
Page 11: Motherboard Specifications
Operating temperature: 0 deg. C to 60 deg. C Operating Humidity: 10 ~ 90% Relative humidity, Mechanical & non-condensing environmental Shock: Operating 15G, 11ms duration Vibration: Operating 5 Hz~500Hz / 1Grms / 3 Axis Certification: CE, FCC, RoHS ID30 Motherboard User Manual... -
Page 12: Function Block
Function Block SO-DIMM x 1 DDR3 800/1066 Max.4GB D2700 CPU 1GB/s Intel NM10 480MB/s LVDS Chipset Audio Realtek ALC655 Super IO 3GB/s SATA II Realtek ALC655 Mini PCIe BIOS Realtek ALC655 ID30 Motherboard User Manual... -
Page 13: Board Dimensions
Board dimensions ID30 Motherboard User Manual... -
Page 14: Installations
Installations This chapter provides information on how to use the jumps and connectors on the ID30 Motherboard. The Sections include: Memory Module Installation I / O Equipment Installation Setting the Jumpers Connectors on ID30 Motherboard ID30 Motherboard User Manual... -
Page 15: Memory Module（So-Dimm）Installation
Chapter 2 Installations 2.1 Memory Module（SO-DIMM）Installation The ID30 Motherboard provides one 204-pin SODIMM slot. The socket supports up to 4GB DDR2 800/1066 SDRAM. When installing the Memory device, please follow the steps below： Step.1. Firmly insert the SO-DIMM at an angle into its slot. Align the SO-DIMM on the slot such that the notch on the SO-DIMM matches the break on the slot. -
Page 16: I/O Equipment Installation
Whatever, you should install the device driver before you use the device. 2.2.6 Audio function The Audio 7.1 channel capabilities are provided by a Realtek ALC886 chipset supporting digital audio outputs. The audio interface includes two jacks: line-in and line-out. ID30 Motherboard User Manual... -
Page 17: Jumpers And Connectors
2.3 Jumpers and Connectors COM2 COM3 SIM Slot DVI1 MiniPCIe J2/J3 12V in ID30 Motherboard User Manual... - Page 18 BOTTOM MiniPCIe for SSD SO-DIMM ID30 Motherboard User Manual...
-
Page 19: Jumper Setting
RS232 / RS422 / RS485 Selector 3x4 header , pitch 2.0mm CON2 LVDS VOLTAGE 2x3 header , pitch 2.0mm 2.4.1 JP4 : Clear CMOS 2.4.2 JP2 : RS232 / RS422 / RS485 Selector for CON port ID30 Motherboard User Manual... - Page 20 2.4.3 JP3: RS232 / RS422 / RS485 Selector for CON port 2.4.4 CON2 : LCD Panel Voltage Select ID30 Motherboard User Manual...
-
Page 21: Connectors And Pin Assignment
CN10 12V/5V External Power header ,pitch 2.54mm DC JACK2 12V DC Jack 2 Pin Jack DIDO1 Digital I/O 2x5 Pin header J2/J3 Amplifier 2 Pin header DVI1 DVI LCD Output Connector 20DP-1.25V * Not Default Connector ID30 Motherboard User Manual... - Page 22 2.5.1 LVDS1: LVDS Connector Pin No. SYMBOL Pin No. SYMBOL LVDS_TX0_DN LVDS_TX0_DP LVDS_TX1_DN LVDS_TX1_DP LVDS_TX2_DN LVDS_TX2_DP LVDS_CLK_DN LCDVDD LVDS_CLK_DP LCDVDD LVDS_TX3_DN LCDVDD LCDVDD LVDS_TX3_DP 2.5.2 JP1: Digital Panel Backlight Brightness Control Pin No. SYMBOL Black Light Control ID30 Motherboard User Manual...
- Page 23 SYMBOL Pin No. SYMBOL FK NRI2 FK NDTR2 FK NCTS2 FK NSOUT2 FK NRTS2 FK NSIN2 FK NDSR2 FK NDCD2 FK NRI1 FK NDTR1 FK NCTS1 FK NSOUT1 FK NRTS1 FK NSIN1 FK NDSR1 FK NDCD1 ID30 Motherboard User Manual...
- Page 24 2.5.7 PANEL1: Front Panel System Function Connector SYMBOL SYMBOL HD_LED+ PW_LED+ HD_LED- PW_LED- RT_BT1 PW_BT1 RT_BT2 PW_BT2 5VSB RSEV 2.5.8 AUDIO1: Audio Connector SYMBOL SYMBOL AZ_FOUT_L AZ_FOUT_R AUGND +5VA LINE1_L LINE1_R MIC1_L MIC1_R SW_D AUGND SW_C SW_B ID30 Motherboard User Manual...
- Page 25 2.5.9 5V1/12V1/CN10: External Power 12V1 CN10 2.5.10 DIDO1: Digital I/O Connector SYMBOL SYMBOL Out1 Out3 Out0 Out2 2.5.1 J2/J3: Amplifier 2.5.1 COM2: Serial port COM2 SYMBOL SYMBOL NRI1A NDTR1A NCTS1A NTXD1A NRTS1A NRXD1A NDSR1A NDCD1A ID30 Motherboard User Manual...
- Page 26 2.5.1 DVI1: DVI connector Pin No. SYMBOL Pin No. SYMBOL TMDSB_DATA0- TMDSB_DATA0+ DVIC_LVDS_DET TMDSB_DATA1- DVIC_BKLTEN TMDSB_DATA1+ DVIC_VDDEN TMDSB_DATA2- DVI_HOT_DETECT TMDSB_DATA2+ LCDVDD TMDSB_BLK- LCDVDD TMDSB_BLK+ +V5S DVI1_DDC_CLK_R +V5S DVI_DDC_DAT_R ID30 Motherboard User Manual...
-
Page 27: Graphic Driver Installation
Graphic Driver Installation This chapter offers information on the chipset software Installation utility Installation of Graphic Driver Panel Resolution Setting ID30 Motherboard User Manual... -
Page 28: Standard Cmos Feature
Graphic Driver Installation 3.1 Standard CMOS Feature ID30 Motherboard is equipped with Intel NM10 Companion Device. The Intel Graphic Drivers should be installed first, and it will enable “Video Controller (VGA compatible). Follow the instructions below to complete the installation. - Page 29 Step.3. Click on “Next “ to install Driver. Step.4. Click on “Yes “ to agree License. ID30 Motherboard User Manual...
- Page 30 Step.5. Click on “Next “ to install Driver. Step.6. Click on “Next “ to install Driver. ID30 Motherboard User Manual...
- Page 31 Step.7. Click on “Yes, I want to restart this computer now“ to go on. ID30 Motherboard User Manual...
-
Page 32: Panel Resolution Setting
3.2 Panel Resolution Setting Step.1. Right-click the desktop, and then click Properties. Step.2. In the Display Properties dialog box, click the Settings tab. Step.3. Click on “Monitor”. ID30 Motherboard User Manual... - Page 33 Step.4. Click on “Hide modes that this monitor cannot display” to remove this option. Step.5. Click on “Setting”, then could choose 32bit color qualify. ID30 Motherboard User Manual...
-
Page 34: Chipset Driver Installation
Chipset Driver Installation This chapter offers information on the chipset software Installation utility Installation of Chipset Driver Further information ID30 Motherboard User Manual... -
Page 35: Standard Cmos Features
Chapter 4 Chipset Driver Installation 4.1 Standard CMOS Features Setp.1. Insert the CD that comes with the motherboard. Open the file document “Chipset Driver”. Setp.2. Click on “infinst_auto.exe“ to install driver. ID30 Motherboard User Manual... - Page 36 Click on “Yes “ to agree License Setp.3. Setp.4. Click on “Next“ to install driver. ID30 Motherboard User Manual...
- Page 37 Setp.5. Click on “Next“ to install driver. Step.7. Click on “Yes, I want to restart this computer now“ to go on. ID30 Motherboard User Manual...
-
Page 38: Chapter 5 Ethernet Driver Installation
Ethernet Driver Installation This chapter offers information on the Ethernet software installation utility. Sections include: Introduction Installation of Ethernet Driver ID30 Motherboard User Manual... - Page 39 Chapter 5 Ethernet Driver Installation Installation of Ethernet Driver The Users must make sure which operating system you are using in the ID30 Motherboard before installing the Ethernet drivers. Follow the steps below to complete the installation of the Broadcom BCM57780 Gigabit Ethernet controller LAN drivers.
- Page 40 Step.2 Click on “Update Driver” to execute the setup. Click on “Browse my computer for driver software“ to install driver. Step.4. ID30 Motherboard User Manual...
- Page 41 Step.5. Choose the path to install driver. Click on “Close“ and go on. Setp.6. ID30 Motherboard User Manual...
-
Page 42: Audio Driver Installation
Audio Driver Installation This chapter offers information on the Audio software installation utility. Sections include: Introduction Installation of Audio Driver ID30 Motherboard User Manual... -
Page 43: Chapter 6 Audio Driver Installation
Realtek ALC655 Audio drivers. You will quickly complete the installation. Step.1. Insert the CD that comes with the motherboard. Open the file document “alc655_driver” and click on “Vista_Win7_R260.exe” to execute the setup. ID30 Motherboard User Manual... - Page 44 Step.2. Click on “Yes“ to install driver. Click on “Yes, I want to restart my computer now” to finish installation. Step.3. ID30 Motherboard User Manual...
-
Page 45: Driver Installation
Fintek COM Port Driver Installation This chapter describes the step by step method to install the Fintek COM port driver. ID30 Motherboard User Manual... - Page 46 STEP 4.Check driver install success. Before the update or update fail. After the update and update success. STEP 5.You will need to restart your computer for driver install success. Type in this command from the Run menu: C:\Windows\System32\UserAccountControlSettings.exe ID30 Motherboard User Manual...
- Page 47 To turn off UAC, move the slider to the Never notify position, and then click OK. If you're prompted for an administrator password or confirmation, type the password or provide confirmation. ID30 Motherboard User Manual...
- Page 48 To turn UAC back on, move the slider to choose when you want to be notified, and then click OK. If you're prompted for an administrator password or confirmation, type the password or provide confirmation. You will need to restart your computer for UAC to be turned off. ID30 Motherboard User Manual...
-
Page 49: Ami Bios Setup
AMI BIOS Setup This chapter describes how to set up the BIOS configuration ID30 Motherboard User Manual... -
Page 50: Chapter 7 Ami Bios Setup
When you first enter the BIOS Setup Utility, you will enter the Main setup image. You can always return to the Main setup image by selecting the Main tab. There are two Main Setup options. They are described in this section. The Main BIOS Setup image is shown as below. ID30 Motherboard User Manual... -
Page 51: Advanced Setting
Disabled Use this setting to ignore all Storage Option ROMs. Enabled Use this setting to load Storage Option ROMs. To limit the Storage support to particular devices, use the function Use device for Storage. Default: Disabled ID30 Motherboard User Manual... - Page 52 Selects the PCI Option ROM to launch in case Multiple Option ROMs (Legacy ROM and EFI Compatible ROM) are present. PCI Latency Timer Use this function to select the number of PCI bus clocks to be used for the PCI latency timer. ID30 Motherboard User Manual...
- Page 53 (when a snoop write cycles) with an ISA video card. Enables or Disables VGA Palette Registers Snooping. Default: Disabled PERR# Generation Enables or Disables PCI Device to Generate PERR#. Default: Disabled SERR# Generation Enables or Disables PCI Device to Generate SERR#. Default: Disabled ID30 Motherboard User Manual...
- Page 54 ACPI Sleep State SETTING DESCRIPTION Suspend Disable System ability to Hibernate (OS/S3 Sleep State) CPU Stop Clock Suspend to RAM Default: S3 (Suspend to RAM) Lock Legacy Resources Enables or Disable Lock of Legacy Resource. Default: Disable ID30 Motherboard User Manual...
-
Page 55: S5 Rtc Wake Settings
S5 RTC Wake Settings SETTING DESCRIPTION Wake system with Fixed Time System wake on alarm event. When enabled, System will wake on the hr: min:: sec specified. Wake system with Dynamic Time Options: Enabled, Disabled ID30 Motherboard User Manual... -
Page 56: Cpu Configuration
XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3.) Limit CPUID Maximum Disabled for Windows XP ID30 Motherboard User Manual... -
Page 57: Thermal Configuration
SETTING DESCRIPTION Disabled Uses EC reported temperature values Enabled Uses DTS SMM mechanism to obtain CPU temperature value Critical Temp Reporting(Out of spec) Uses EC reported temperature values and DTS SMM to handle out of spec ID30 Motherboard User Manual... - Page 58 This field enables or disables the smart fan feature. At a certain temperature, the fan starts turning. Once the temperature drops to a certain level, it stops turning again. Passive TC1 Value Passive TC2 Value Passive TSP Value ID30 Motherboard User Manual...
-
Page 59: Ide Configuration
IDE Configuration Configure SATA as Determines how SATA controllers(s) operate. The options are IDE and AHCI. ID30 Motherboard User Manual... - Page 60 Select Port0 AHCI Speed Limit. The options are No Limit, GEN1 Rate and GEN2 Rate. SATA Port 0/1 Enable or disable SATA Port. SATA Port 0/1 Hot Plug Designates this port as Hot Pluggable ID30 Motherboard User Manual...
- Page 61 Intel Fast Flash Standy iFFS Support Enable or disable ID30 Motherboard User Manual...
-
Page 62: Usb Configuration
Maximun time the device will take before it properly reports itself to the Host Controller. ‘Auto‘ uses default value: for a Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. ID30 Motherboard User Manual... - Page 63 Mass Storage Device: Mass storage device emulation type. ‗AUTO‘ enumerates devices less than 530MB as floppies. Forced FDD option can be used to force HDD formatted drive to boot as FDD. ID30 Motherboard User Manual...
- Page 64 F81865 Super IO Configuration System Super IO Chip Parameters. Serial Port 1、2、3 、4、5、6 Configuration ID30 Motherboard User Manual...
- Page 65 The watchdog timer circuit has to be triggered within a specified time by the application software. If the watchdog is not triggered because proper software execution fails or a hardware malfunction occurs, it will reset the system ID30 Motherboard User Manual...
- Page 66 F81865 H/W Monitor Fan 1、2 Config smart fan mode, can choose 50,60 and 70 three degree mode ID30 Motherboard User Manual...
-
Page 67: Ppm Configuration
PPM Configuration EIST Enable/Disable Intel SpeedStep. CPU C state Report Enable/Disable CPU C state report to OS. ID30 Motherboard User Manual... -
Page 68: C4 Exit Timing
C4 Exit Timing This option controls a programmable time for the CPU voltage to stabilize when exiting from a C4 state. ID30 Motherboard User Manual... - Page 69 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. Memory Frequency and Timing ID30 Motherboard User Manual...
- Page 70 Intel IGD Configuration Primary Display Select which of IGFX/PEG/PCI Graphics device should be Primary display. Internal Graphics Keep IGD enabled based on the setup options. ID30 Motherboard User Manual...
- Page 71 Select the LCD panel scaling option used by the Internal Graphics Device. Backlight Control IGD clock selection. Backlight Control Support Back Light Control Setting. Auto:GMCH Use VBT Default; Level n: Enabled with Selected Aggressiveness Level, . ALS Support Valid only for ACPI. ID30 Motherboard User Manual...
- Page 72 The Desktop Management Interface (DMI) generates a standard framework for managing and tracking components in a desktop, notebook or server computer, by abstracting these components from the software that manages them. PCI-Exp. High Priority Port Select a PCI Express High Priority Port. ID30 Motherboard User Manual...
- Page 73 GA20; this option is useful when any RT code is executed above 1MB. Option ROM Messages Set display mode for Option ROM. Options are Force BIOS and Keep Current. Interrupt 19 Canture Enable: Allows Option ROMs to trap Int 19. ID30 Motherboard User Manual...
- Page 74 It will list all the Boot options that are configured as Network/Hard Drive. User can change the priority as similar to the main boot option priorities. The first boot option will be having top boot priority and will appear at the boot option priorities and boot order. ID30 Motherboard User Manual...
- Page 75 This section allows you to configure and improve your system and allows you to set up some system features according to your p reference. Administrator Password Set Setup Administrator Password. User Password Set User Password. ID30 Motherboard User Manual...
- Page 76 Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup options. Launch EFI Shell from filesystem devices Attempts to launch EFI shell application from one of the available filesystem devices. ID30 Motherboard User Manual...
- Page 77 = 0; //data for digital output unsigned char ucDI; //data for digital input unsigned char ucBuf; Set_W83627EHG_Reg(0x07,0x07);//switch to logic device 7 PIN 121~128 function select Bit0 = 0 -> Game Port. = 1 -> GPIO1. ID30 Motherboard User Manual...
- Page 78 Set_W83627EHG_Reg(0xF1, ((ucDO & 0x0F) << 4)); ucBuf = Get_W83627EHG_Reg(0xF1) & 0x0F; if (ucBuf != ucDI) ucDI = ucBuf; printf("Digital I/O Input Changed. Current Data is 0x%X\n",ucDI); if (kbhit()) getch(); break; delay(500); return 0; //============================================================ void ClrKbBuf(void) while(kbhit()) { getch(); } ID30 Motherboard User Manual...
- Page 79 W83627EHG_LOCK); //============================================================ void Set_W83627EHG_Reg( unsigned char REG, unsigned char DATA) Unlock_W83627EHG(); outportb(W83627EHG_INDEX_PORT, REG); outportb(W83627EHG_DATA_PORT, DATA); Lock_W83627EHG(); //============================================================ unsigned char Get_W83627EHG_Reg( unsigned char REG) unsigned char Result; Unlock_W83627EHG(); outportb(W83627EHG_INDEX_PORT, REG); Result = inportb(W83627EHG_DATA_PORT); Lock_W83627EHG(); return Result; //============================================================ ID30 Motherboard User Manual...
- Page 80 () int Watchdog_timeout = 10; printf("Input Watchdog Timer time-out value [0-255] : "); scanf("%d",&Watchdog_timeout); if(Watchdog_timeout <= 0 || Watchdog_timeout > 255) printf("Time-out value out of range!!\n\n"); printf("Input Watchdog Timer time-out value [0-255] : "); scanf("%d",&Watchdog_timeout); ID30 Motherboard User Manual...
- Page 81 //Reset Watchdog timer Set_W83627_Reg(0xF6,Watchdog_timeout); //Set Watch Dog Timer Time-out value clrscr(); if(i>0){ i--; printf("After %2d sec reset computer!\n",i); printf("Press any key to reset watchdog timer!\n"); printf("Press [Esc] to exit!\n"); else printf("Watchdog timer fail!"); delay(1000); ID30 Motherboard User Manual...
- Page 82 W83627_LOCK); //============================================================ void Set_W83627_Reg( unsigned char REG, unsigned char DATA) Unlock_W83627(); outportb(W83627_INDEX_PORT, REG); outportb(W83627_DATA_PORT, DATA); Lock_W83627(); //============================================================ unsigned char Get_W83627_Reg( unsigned char REG) unsigned char Result; Unlock_W83627(); outportb(W83627_INDEX_PORT, REG); Result = inportb(W83627_DATA_PORT); Lock_W83627(); return Result; //============================================================ ID30 Motherboard User Manual...
