ID70
Motherboard
"
Mini-ITX Fanless SBC w/Intel Atom
D2700 2.13GHz Processor, VGA,
LVDS, Dual Giga Ethernet, PCI and
Mini-PCIe Interface.
USER MANUAL Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ID70 and is the answer not in the manual?

Questions and answers

Summary of Contents for Winmate ID70

  • Page 1 ID70 Motherboard ” Mini-ITX Fanless SBC w/Intel Atom D2700 2.13GHz Processor, VGA, LVDS, Dual Giga Ethernet, PCI and Mini-PCIe Interface. USER MANUAL Version 1.0...
  • Page 2: Fcc Statement

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at him own expense. ID70 Motherboard User Manual...
  • Page 3: Copyright Notice

    Applications that are described in this manual are for illustration purposes only. Winmate Communication Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
  • Page 4: Packing List

    In addition, free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products. Please do not hesitate to call or e-mail us. ID70 Motherboard User Manual...
  • Page 5: Safety Precautions

    CPU card. Modern electronic devices are very sensitive to static electric charges. As a safety precaution, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. ID70 Motherboard User Manual...
  • Page 6 F. The equipment has obvious signs of breakage. 15. Do not leave this equipment in an uncontrolled environment where the storage temperature is below -20° C (-4°F) or above 60° C (140° F). It may damage the equipment. ID70 Motherboard User Manual...
  • Page 7 Revision History Version Date Note Author 2012.1.13 Initial Draft Henry Hsu ID70 Motherboard User Manual...
  • Page 8: Table Of Contents

    ............31 NSTALLATION OF THERNET RIVER CHAPTER 6 AUDIO DRIVER INSTALLATION......35 6.1 I ................. 35 NTRODUCTION ..........35 NSTALLATION OF UDIO RIVER CHAPTER 7 AMI BIOS SETUP ............42 7.1 A ................43 DVANCED ETTING VIII ID70 Motherboard User Manual...
  • Page 9: General Information

    General Information This chapter includes the ID30 Motherboard background information. Sections include: Introduction  Feature  Motherboard Specification  Function Block  Board Dimensions  ID70 Motherboard User Manual...
  • Page 10: Chapter 1 General Information

    Connector ; Four Pin Header ) .Additionally, ID70 SBC build-in a 12V DC-IN power adapter. Thus, the ID70 SBC is designed to satisfy most of the applications in the industrial computer market, such as Gaming, POS, KIOSK, Industrial Automation, and Programmable Control System. It is a compact design to meet the demanding performance requirements of today‘s business and...
  • Page 11: Motherboard Specifications

    Operating temperature: 0 deg. C to 60 deg. C Operating Humidity: 10 ~ 90% Relative humidity, Mechanical & non-condensing environmental Shock: Operating 15G, 11ms duration Vibration: Operating 5 Hz~500Hz / 1Grms / 3 Axis Certification: CE, FCC, RoHS ID70 Motherboard User Manual...
  • Page 12: Function Block

    Function Block SO-DIMM x 2 DDR3 800/1066 Max.4GB D2700 CPU 1GB/s Intel NM10 480MB/s LVDS Chipset Audio Realtek ALC655 Super IO SATA II Realtek ALC655 Mini PCI BIOS Realtek ALC655 ID70 Motherboard User Manual...
  • Page 13: Board Dimensions

    Board dimensions ID70 Motherboard User Manual...
  • Page 14: Installations

    Installations This chapter provides information on how to use the jumps and connectors on the ID70 Motherboard. The Sections include: Memory Module Installation  I / O Equipment Installation  Setting the Jumpers  Connectors on ID70 Motherboard  ID70 Motherboard User Manual...
  • Page 15: Memory Module(So-Dimm)Installation

    Chapter 2 Installations 2.1 Memory Module(SO-DIMM)Installation The ID70 Motherboard provides one 204-pin SODIMM slot. The socket supports up to 4GB DDR2 800/1066 SDRAM. When installing the Memory device, please follow the steps below: Step.1. Firmly insert the SO-DIMM at an angle into its slot. Align the SO-DIMM on the slot such that the notch on the SO-DIMM matches the break on the slot.
  • Page 16: I/O Equipment Installation

    Whatever, you should install the device driver before you use the device. 2.2.6 Audio function The Audio 7.1 channel capabilities are provided by a Realtek ALC886 chipset supporting digital audio outputs. The audio interface includes three jacks: line-in, line-out and mic in. ID70 Motherboard User Manual...
  • Page 17: Jumpers And Connectors

    2.3 Jumpers and Connectors Inverter JP6,7,8 JP3,4 System Fan LVDS LPT port COM2 COM5、6 CPU Fan 、 ID70 Motherboard User Manual...
  • Page 18 BOTTOM ID70 Motherboard User Manual...
  • Page 19: Jumper Setting

    3x1 header , pitch 2.0mm PWM/DA 3x1 header , pitch 2.0mm VR/Software 3x1 header , pitch 2.0mm 2.4.1 JP1: RS232 / RS422 / RS485 Selector for CON port 2.4.2 JP2 : RS232 / RS422 / RS485 Selector for CON port ID70 Motherboard User Manual...
  • Page 20 2.4.3 JP3 : LCD Panel Voltage Select 2.4.4 JP4 : Back Light PWR 2.4.5 JP5 : Clear CMOS 2.4.6 JP6 : PWM Level 2.4.7 JP7 : Brightness Control(DC/PWM) ID70 Motherboard User Manual...
  • Page 21 2.4.8 JP8 : Brightness Control(VR/Software) ID70 Motherboard User Manual...
  • Page 22: Connectors And Pin Assignment

    2x1 header, pitch 2.0mm HDD PWR 12V/5V External Power header ,pitch 2.54mm DC JACK 12V DC Jack 4 Pin Jack Digital I/O 2x5 Pin header Speaker(Right/Left) 2 Pin header Printer Port 2x10 header * Not Default Connector ID70 Motherboard User Manual...
  • Page 23 2.5.1 LVDS: LVDS Connector Pin No. SYMBOL Pin No. SYMBOL LVDS_TX0_DN LVDS_TX0_DP LVDS_TX1_DN LVDS_TX1_DP LVDS_TX2_DN LVDS_TX2_DP LVDS_CLK_DN LCDVDD LVDS_CLK_DP LCDVDD LVDS_TX3_DN LCDVDD LVDS_TX3_DP 2.5.2 CN16: Digital Panel Backlight Brightness Control Pin No. SYMBOL Black Light Control ID70 Motherboard User Manual...
  • Page 24 FK NSIN6 FK NDSR6 FK NDCD6 FK NRI5 FK NDTR5 FK NCTS5 FK NSOUT5 FK NRTS5 FK NSIN5 FK NDSR5 FK NDCD5 2.5.5 USB : USB PIN HEADER SYMBOL SYMBOL USBVCC USBVCC USB_P6- USB_P7- USB_P6+ USB_P7+ ID70 Motherboard User Manual...
  • Page 25 2.5.7 PANEL1: Front Panel System Function Connector SYMBOL SYMBOL HD_LED+ PW_LED+ HD_LED- PW_LED- RT_BT1 PW_BT1 RT_BT2 PW_BT2 5VSB RSEV 2.5.8 5V/12V/CN10: External Power 12V1 CN10 2.5.9 DIDO1: Digital I/O Connector SYMBOL SYMBOL Out1 Out3 Out0 Out2 2.5.1 J2/J3: Amplifier ID70 Motherboard User Manual...
  • Page 26 NRI1A NDTR1A NCTS1A NTXD1A NRTS1A NRXD1A NDSR1A NDCD1A 2.5.1 DVI1: DVI connector Pin No. SYMBOL Pin No. SYMBOL TMDSB_DATA0- TMDSB_DATA0+ DVIC_LVDS_DET TMDSB_DATA1- DVIC_BKLTEN TMDSB_DATA1+ DVIC_VDDEN TMDSB_DATA2- DVI_HOT_DETECT TMDSB_DATA2+ LCDVDD TMDSB_BLK- LCDVDD TMDSB_BLK+ +V5S DVI1_DDC_CLK_R +V5S DVI_DDC_DAT_R ID70 Motherboard User Manual...
  • Page 27: Graphic Driver Installation

    Graphic Driver Installation This chapter offers information on the chipset software Installation utility Installation of Graphic Driver  Panel Resolution Setting  ID70 Motherboard User Manual...
  • Page 28: Standard Cmos Feature

    (VGA compatible). Follow the instructions below to complete the installation. You will quickly complete the installation. Step.1. Insert the CD that comes with the Motherboard. Open the file document “Graphic Driver “. Step.2. Click on “setup” to execute the setup. ID70 Motherboard User Manual...
  • Page 29 Step.3. Click on “Next “ to install Driver. Step.4. Click on “Yes “ to agree License. ID70 Motherboard User Manual...
  • Page 30 Step.5. Click on “Next “ to install Driver. Step.6. Click on “Next “ to install Driver. ID70 Motherboard User Manual...
  • Page 31 Step.7. Click on “Yes, I want to restart this computer now“ to go on. ID70 Motherboard User Manual...
  • Page 32: Panel Resolution Setting

    3.2 Panel Resolution Setting Step.1. Right-click the desktop, and then click Properties. Step.2. In the Display Properties dialog box, click the Settings tab. Step.3. Click on “Monitor”. ID70 Motherboard User Manual...
  • Page 33 Step.4. Click on “Hide modes that this monitor cannot display” to remove this option. Step.5. Click on “Setting”, then could choose 32bit color qualify. ID70 Motherboard User Manual...
  • Page 34: Chipset Driver Installation

    Chipset Driver Installation This chapter offers information on the chipset software Installation utility Installation of Chipset Driver  Further information  ID70 Motherboard User Manual...
  • Page 35: Standard Cmos Features

    Chapter 4 Chipset Driver Installation 4.1 Standard CMOS Features Setp.1. Insert the CD that comes with the motherboard. Open the file document “Chipset Driver”. Setp.2. Click on “infinst_auto.exe“ to install driver. ID70 Motherboard User Manual...
  • Page 36 Click on “Yes “ to agree License Setp.3. Setp.4. Click on “Next“ to install driver. ID70 Motherboard User Manual...
  • Page 37 Setp.5. Click on “Next“ to install driver. Step.7. Click on “Yes, I want to restart this computer now“ to go on. ID70 Motherboard User Manual...
  • Page 38: Chapter 5 Ethernet Driver Installation

    Ethernet Driver Installation This chapter offers information on the Ethernet software installation utility. Sections include: Introduction  Installation of Ethernet Driver  ID70 Motherboard User Manual...
  • Page 39 Broadcom BCM57780 Gigabit Ethernet controller LAN drivers. You will quickly complete the installation. Step.1. Right-click the desktop, and then click Properties. Step.2. In the Other device dialog box, click the Settings tab. ID70 Motherboard User Manual...
  • Page 40 Step.2 Click on “Update Driver” to execute the setup. Click on “Browse my computer for driver software“ to install driver. Step.4. ID70 Motherboard User Manual...
  • Page 41 Step.5. Choose the path to install driver. Click on “Close“ and go on. Setp.6. ID70 Motherboard User Manual...
  • Page 42: Audio Driver Installation

    Audio Driver Installation This chapter offers information on the Audio software installation utility. Sections include: Introduction  Installation of Audio Driver  ID70 Motherboard User Manual...
  • Page 43: Chapter 6 Audio Driver Installation

    Realtek ALC655 Audio drivers. You will quickly complete the installation. Step.1. Insert the CD that comes with the motherboard. Open the file document “alc655_driver” and click on “Vista_Win7_R260.exe” to execute the setup. ID70 Motherboard User Manual...
  • Page 44 Step.2. Click on “Yes“ to install driver. Click on “Yes, I want to restart my computer now” to finish installation. Step.3. ID70 Motherboard User Manual...
  • Page 45: Driver Installation

    Fintek COM Port Driver Installation This chapter describes the step by step method to install the Fintek COM port driver. ID70 Motherboard User Manual...
  • Page 46 STEP 4.Check driver install success. Before the update or update fail. After the update and update success. STEP 5.You will need to restart your computer for driver install success. Type in this command from the Run menu: C:\Windows\System32\UserAccountControlSettings.exe ID70 Motherboard User Manual...
  • Page 47 To turn off UAC, move the slider to the Never notify position, and then click OK. If you're prompted for an administrator password or confirmation, type the password or provide confirmation. ID70 Motherboard User Manual...
  • Page 48 To turn UAC back on, move the slider to choose when you want to be notified, and then click OK. If you're prompted for an administrator password or confirmation, type the password or provide confirmation. You will need to restart your computer for UAC to be turned off. ID70 Motherboard User Manual...
  • Page 49: Ami Bios Setup

    AMI BIOS Setup This chapter describes how to set up the BIOS configuration ID70 Motherboard User Manual...
  • Page 50: Chapter 7 Ami Bios Setup

    When you first enter the BIOS Setup Utility, you will enter the Main setup image. You can always return to the Main setup image by selecting the Main tab. There are two Main Setup options. They are described in this section. The Main BIOS Setup image is shown as below. ID70 Motherboard User Manual...
  • Page 51: Advanced Setting

    Disabled Use this setting to ignore all Storage Option ROMs. Enabled Use this setting to load Storage Option ROMs. To limit the Storage support to particular devices, use the function Use device for Storage. Default: Disabled ID70 Motherboard User Manual...
  • Page 52 Selects the PCI Option ROM to launch in case Multiple Option ROMs (Legacy ROM and EFI Compatible ROM) are present.  PCI Latency Timer Use this function to select the number of PCI bus clocks to be used for the PCI latency timer. ID70 Motherboard User Manual...
  • Page 53 (when a snoop write cycles) with an ISA video card. Enables or Disables VGA Palette Registers Snooping. Default: Disabled  PERR# Generation Enables or Disables PCI Device to Generate PERR#. Default: Disabled  SERR# Generation Enables or Disables PCI Device to Generate SERR#. Default: Disabled ID70 Motherboard User Manual...
  • Page 54 CPU Stop Clock Suspend to RAM Default: S3 (Suspend to RAM)  Lock Legacy Resources Enables or Disable Lock of Legacy Resource. Default: Disable  S3 Video Repost Enables or Disable S3 Video Repost Default: Disable ID70 Motherboard User Manual...
  • Page 55: S5 Rtc Wake Settings

    S5 RTC Wake Settings SETTING DESCRIPTION Wake system with Fixed Time System wake on alarm event. When enabled, System will wake on the hr: min:: sec specified. Wake system with Dynamic Time Options: Enabled, Disabled ID70 Motherboard User Manual...
  • Page 56: Cpu Configuration

    XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3.)  Limit CPUID Maximum Disabled for Windows XP ID70 Motherboard User Manual...
  • Page 57: Thermal Configuration

    SETTING DESCRIPTION Disabled Uses EC reported temperature values Enabled Uses DTS SMM mechanism to obtain CPU temperature value Critical Temp Reporting(Out of spec) Uses EC reported temperature values and DTS SMM to handle out of spec ID70 Motherboard User Manual...
  • Page 58 This field enables or disables the smart fan feature. At a certain temperature, the fan starts turning. Once the temperature drops to a certain level, it stops turning again.  Passive TC1 Value  Passive TC2 Value  Passive TSP Value ID70 Motherboard User Manual...
  • Page 59: Ide Configuration

    IDE Configuration  Configure SATA as Determines how SATA controllers(s) operate. The options are IDE and AHCI. ID70 Motherboard User Manual...
  • Page 60 Select Port0 AHCI Speed Limit. The options are No Limit, GEN1 Rate and GEN2 Rate.  SATA Port 0/1 Enable or disable SATA Port.  SATA Port 0/1 Hot Plug Designates this port as Hot Pluggable ID70 Motherboard User Manual...
  • Page 61 Intel Fast Flash Standy  iFFS Support Enable or disable iFFS. ID70 Motherboard User Manual...
  • Page 62: Usb Configuration

    Maximun time the device will take before it properly reports itself to the Host Controller. ‘Auto‘ uses default value: for a Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. ID70 Motherboard User Manual...
  • Page 63  Mass Storage Device: Mass storage device emulation type. ‗AUTO‘ enumerates devices less than 530MB as floppies. Forced FDD option can be used to force HDD formatted drive to boot as FDD. ID70 Motherboard User Manual...
  • Page 64 F81865 Super IO Configuration System Super IO Chip Parameters.  Serial Port 1、2、3 、4、5、6 Configuration ID70 Motherboard User Manual...
  • Page 65 The watchdog timer circuit has to be triggered within a specified time by the application software. If the watchdog is not triggered because proper software execution fails or a hardware malfunction occurs, it will reset the system ID70 Motherboard User Manual...
  • Page 66  F81865 H/W Monitor Fan 1、2 Config smart fan mode, can choose 50,60 and 70 three degree mode ID70 Motherboard User Manual...
  • Page 67: Ppm Configuration

    PPM Configuration  EIST Enable/Disable Intel SpeedStep.  CPU C state Report Enable/Disable CPU C state report to OS. ID70 Motherboard User Manual...
  • Page 68: C4 Exit Timing

     C4 Exit Timing This option controls a programmable time for the CPU voltage to stabilize when exiting from a C4 state. ID70 Motherboard User Manual...
  • Page 69 This section allows you to configure and improve your system and allows you to set up some system features according to your preference.  Memory Frequency and Timing Can choose enable or disable MRC fast boot. ID70 Motherboard User Manual...
  • Page 70  Intel IGD Configuration  Auto Disable IGD Auto disable IGD upon external GFX detected. ID70 Motherboard User Manual...
  • Page 71  IGFX-Boot Type Select the Video Device which will be activated during POST. This has no effect if external graphics present.  DVMT ID70 Motherboard User Manual...
  • Page 72 Back Light Control Setting.  Auto:GMCH Use VBT Default; Level n: Enabled with Selected Aggressiveness Level, .  ALS Support Valid only for ACPI.  TPT Devices Enable/Disable Intel IO controller hub device  PCI Express Root Port 0/1/2/3 ID70 Motherboard User Manual...
  • Page 73  PCI-Exp. High Priority Port Select a PCI Express High Priority Port. 5.3 Boot  Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535 (0xFFFF) means indefinite waiting. Default: 1 ID70 Motherboard User Manual...
  • Page 74 Enable: Allows Option ROMs to trap Int 19. 5.4 Security  Administrator Password This section allows you to configure and improve your system and allows you to set up some system features according to your p reference. ID70 Motherboard User Manual...
  • Page 75  Administrator Password Set Setup Administrator Password.  User Password Set User Password. ID70 Motherboard User Manual...
  • Page 76 Save the changes done so far as User Defaults.  Restore User Defaults Restore the User Defaults to all the setup options.  Launch EFI Shell from filesystem devices Attempts to launch EFI shell application from one of the available filesystem devices. ID70 Motherboard User Manual...
  • Page 77 Note1: Digital I/O Sample Code //========================================================== //File of the D_F81865.C //========================================================== //This Sample code is for ID70 DIDO configuration //========================================================== #include <dos.h> #include <conio.h> #include <stdio.h> #include <stdlib.h> //========================================================== #define F81865_INDEX_PORT 0x4E #define F81865_DATA_PORT 0x4F #define F81865_UNLOCK 0x87 #define F81865_LOCK 0xAA...
  • Page 78 //data for digital input unsigned char ucBuf; DIDO_Init_Reg(); DIDO_Set_In_Out_Reg(); DIDO_Clear_Reg(); ucDI = DIDO_Get_Reg(); ClrKbBuf(); while(1) //Output Test ucDO++; DIDO_Set_Reg(ucDO); //Intput Test ucBuf = DIDO_Get_Reg(); if (ucBuf != ucDI) ucDI = ucBuf; printf("Digital I/O Input Changed. Current Data is 0x%X\n",ucDI); ID70 Motherboard User Manual...
  • Page 79 //============================================================ void Unlock_F81865 (void) outportb(F81865_INDEX_PORT, F81865_UNLOCK); outportb(F81865_INDEX_PORT, F81865_UNLOCK); //============================================================ void Lock_F81865 (void) outportb(F81865_INDEX_PORT, F81865_LOCK); //============================================================ void Set_F81865_Reg( unsigned char REG, unsigned char DATA) Unlock_F81865(); outportb(F81865_INDEX_PORT, REG); outportb(F81865_DATA_PORT, DATA); Lock_F81865(); //============================================================ unsigned char Get_F81865_Reg( unsigned char REG) ID70 Motherboard User Manual...
  • Page 80 = Get_F81865_Reg(0x2A); Set_F81865_Reg(0x2A,ucBuf&0xFB); Bit0 = 0 -> GPIO is inactive. Bit1 = 1 -> Activate GPIO. ucBuf = Get_F81865_Reg(0x30); Set_F81865_Reg(0x30,ucBuf|0x01);//Activate GPIO //============================================================ void DIDO_Set_In_Out_Reg(void) unsigned char ucBuf; Set_F81865_Reg(F81865_GPIO0_IN_OUT,OUTPUT_MASK);//switch GPIO Input(0)/Output(1) port #if 1 //for DIDO GPIO7(GPIO10) control ID70 Motherboard User Manual...
  • Page 81 #if 1 //for DIDO GPIO7(GPIO10) control ucBuf = Get_F81865_Reg(F81865_GPIO1_IN); Set_F81865_Reg(F81865_GPIO1_IN,ucBuf&0xFE); #endif //============================================================ void DIDO_Set_Reg(unsigned char DATA) unsigned char ucBuf; Set_F81865_Reg(F81865_GPIO0_OUT, (DATA & OUTPUT_MASK)); #if 1 //for DIDO GPIO7(GPIO10) control ucBuf = Get_F81865_Reg(F81865_GPIO1_OUT); if ((DATA & OUTPUT_MASK)&0x80) Set_F81865_Reg(F81865_GPIO1_OUT,ucBuf|0x01); else Set_F81865_Reg(F81865_GPIO1_OUT,ucBuf&0xFE); #endif ID70 Motherboard User Manual...
  • Page 82 DIDO_Get_Reg(void) unsigned char ucDI; //data for digital input unsigned char ucBuf; ucDI = Get_F81865_Reg(F81865_GPIO0_IN) & INPUT_MASK; #if 1 //for DIDO GPIO7(GPIO10) control ucBuf = Get_F81865_Reg(F81865_GPIO1_IN)&0x01; if (ucBuf) ucDI|=(ucDI|0x80)&INPUT_MASK; else ucDI=(ucDI&0x7F)&INPUT_MASK; #endif return ucDI; //============================================================ ID70 Motherboard User Manual...
  • Page 83 //========================================================== int g_bDisableWatchdog = 0; int g_iWatchdog_timeout = 10; int g_iCount = 0; //========================================================== int main(int argc, char* argv[]) int Watchdog_mode = 0; Watchdog_mode = atoi(argv[1]);//0:seconds, 1:minutes if (Watchdog_mode==0) printf("Watchdog Second Mode\n"); else ID70 Motherboard User Manual...
  • Page 84 Set_F81865_Reg(0x30,0x01);//Activate watchdog Set_F81865_Reg(0xF6,g_iWatchdog_timeout); //Set Watch Dog Timer Time-out value if (Watchdog_mode==0) Set_F81865_Reg(0xF5,0x60);//Select WDTO# count mode.seconds Mode. else Set_F81865_Reg(0xF5,0x68);//Select WDTO# count mode.minutes Mode. g_iCount = g_iWatchdog_timeout; while(1) if (kbhit()) if(getch()==0x1B) //Esc g_bDisableWatchdog=1; else g_iCount=g_iWatchdog_timeout; //Reset Watchdog timer ID70 Motherboard User Manual...
  • Page 85 %2d sec reset computer!\n",g_iCount); else printf("After %2d min reset computer!\n",g_iCount+1); printf("Press any key to reset watchdog timer!\n"); printf("Press [Esc] to exit!\n"); else printf("Watchdog timer fail!"); if (Watchdog_mode==0) delay1second(); else delay1minute(); Set_F81865_Reg(0xF5,0x48); //Disable Watchdog timer return 0; //========================================================== =========== ID70 Motherboard User Manual...
  • Page 86 =========== void delay1minute(void) int i=60; while (i) if (kbhit()) if(getch()==0x1B) //Esc g_bDisableWatchdog=1; else g_iCount=g_iWatchdog_timeout; //Reset Watchdog timer Set_F81865_Reg(0xF6,g_iWatchdog_timeout); //Set Watch Dog Timer Time-out value break; delay1second(); i--; //========================================================== =========== void Unlock_F81865 (void) outportb(F81865_INDEX_PORT, F81865_UNLOCK); outportb(F81865_INDEX_PORT, F81865_UNLOCK); ID70 Motherboard User Manual...
  • Page 87 //========================================================== =========== void Set_F81865_Reg( unsigned char REG, unsigned char DATA) Unlock_F81865(); outportb(F81865_INDEX_PORT, REG); outportb(F81865_DATA_PORT, DATA); Lock_F81865(); //========================================================== =========== unsigned char Get_F81865_Reg( unsigned char REG) unsigned char Result; Unlock_F81865(); outportb(F81865_INDEX_PORT, REG); Result = inportb(F81865_DATA_PORT); Lock_F81865(); return Result; ID70 Motherboard User Manual...
