P121 / P121LC / P121RC / P131
Zero Clearance Direct Vent Gas Fireplace
WARNING:
If the information in these instructions are not followed exactly, a
fi re or explosion may result causing property damage, personal
injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other fl ammable vapours and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualifi ed
installer, service agency or the gas supplier.
Tested by:
918-519b
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
STYLE
See Thru
P121-NG2 Natural Gas
Left Corner
P121LC-NG2 Natural Gas P121LC-LP2 Propane
Right Corner P121RC-NG2 Natural Gas P121RC-LP2 Propane
Pier
P131-NG2 Natural Gas
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
MODEL
P121-LP2 Propane
P131-LP2 Propane
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch: do not use any
phone in your building.
Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
If you cannot reach your gas supplier, call the fi re
department.
Owners &
Installation Manual
www.regency-fi re.com
06/15/10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P121-NG2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Regency P121-NG2

  • Page 1 P121 / P121LC / P121RC / P131 Owners & Zero Clearance Direct Vent Gas Fireplace Installation Manual www.regency-fi re.com STYLE MODEL See Thru P121-NG2 Natural Gas P121-LP2 Propane Left Corner P121LC-NG2 Natural Gas P121LC-LP2 Propane Right Corner P121RC-NG2 Natural Gas P121RC-LP2 Propane...
  • Page 2 Congratulations! ® You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The P121 / P121LC / P121RC / P131 is a hand crafted appliance and has been designed to provide you with all the warmth and charm of a wood fi replace at the fl...
  • Page 3: Manufactured Mobile Home Requirements

    MANUFACTURED MOBILE HOME REQUIREMENTS INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency ® product has been tested and listed by Intertek as a Direct Vent Wall Furnace to the following standards: VENTED GAS FIREPLACE HEATERS ANSI Z21.88a-2007/CSA 2.33a-2007 and GAS-FIRED APPLIANCES FOR USE AT HIGH ALTITUDES CAN/ CGA 2.17-M91.
  • Page 4: Table Of Contents

    Log Set Installation ............31 Glass Door Removal ...........33 Finishing Trim ..............33 Louvers & Grills ............33 Option 1: Remote Control ..........34 Option 2: Wall Switch ..........34 Option 3: Wall Thermostat ..........34 Wiring Diagrams ............35 ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 5: Safety Label

    ® NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one.
  • Page 6 (e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 7: Unit Dimensions

    DIMENSIONS SPECIFICATIONS P121-2 See Thru Note: These units are non-load bearing. P131-2 Pier ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 8 DIMENSIONS P121LC-2 Left Corner Unit Note: These units are non-load bearing. P121RC-2 Right Corner Unit ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 9: Installation

    APPLIANCE SHOULD BE LOCATED OUT OF TRAFFIC AND AWAY FROM FURNITURE AND DRAPERIES. WARNING: FAILURE TO INSTALL THIS APPLIANCE CORRECTLY WILL VOID YOUR WARRANTY AND MAY CAUSE A SERIOUS HOUSE FIRE. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 10: General Safety

    Emissions from burning wood or gas could contain chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 11: Locating Your Gas Fireplace

    Have a qualifi ed inspector, dealer, or installer review your plans before installation. Note: For Exterior Vent Termination Locations see section "Exterior Vent Termination Locations." D) P121RC-2 Right Corner ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 12: Clearances

    "heat resistant" or the paint may discolour. * If the 3" (76mm) metal extension trim is removed it must be replaced with a 8" (203mm) non- combustible material. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 13: Framing And Finishing

    fl ex, see Vent Clearances in the "Clearances" section. P121-2 - See Thru P121LC-2 - Corner Unit P131-2 - Pier P121RC-2 - Corner Unit Note: These units are non-load bearing. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 14: Unit Assembly Prior To Installation

    3) Attach the standoff securely to the top with own separate vent system. Common vent 4 screws per standoff (on opposite corners). systems are prohibited. (See "Rigid Pipe Venting Systems" for more details and exceptions). ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 15: Exterior Vent Termination Locations

    * Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 16: 4" X 6-5/8" Rigid Pipe Cross Reference Chart

    46DVA-ES (N/A - FPI) 4DT-OS SV4SU Wall Thimble-Black 46DVA-WT 4DT-WT 4DWT 4DWT SV4RSM TE-4DE90 Wall Thimble Support/Ceiling Support 46DVA-DC SV4PF TE-4DE90B Firestop Spacer 46DVA-FS 4DT-FS 4DFSP 4DFS SV4BF Trim Plate-Black 4DT-TP 4DFPB 4DCP SV4LA ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 17 Note: Horizontal runs of vent must be level, or have a 1/4” rise for every 1 foot of run towards the termination. Never allow the vent to run downward - this could cause high temperatures and may present a possible fi re hazard. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 18: Venting Arrangement - Horizontal Terminations

    8) plated screws (8) 9) screws #8 x 1-1/2" drill point, stainless steel (4) Notes: 1) Liner sections should be continuous without any joints or seams. 2) Only Flex pipe purchased from Regency ® may be used for Flex installations. Regency ®...
  • Page 19: Rigid Pipe Venting Systems

    Metal Products Ameri Vent Direct Vent, Security Secure Vent , Selkirk Direct-Temp. AstroCap is a proprietary trademark of FPI Fireplace Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 20: Rigid Pipe Venting Arrangements

    INSTALLATION RIGID PIPE VENTING ARRANGEMENTS HORIZONTAL TERMINATIONS REGENCY DIRECT VENT SYSTEM (FLEX) (Propane & Natural Gas) The diagram below shows examples of horizontal termination arrangements using one, two, or three 90 elbows (two 45 elbows equal one 90 elbow). Note:...
  • Page 21 With the above options, maximum total pipe length if 37 feet with minimum of 5 feet total vertical and maximum 12 feet total horizontal. Please note minimum 1 foot between 90 elbows is required. Diagram 4 Diagram 6 ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 22 Rigid Pipe Adaptor will pertrude past the unit 1-1/2" (38mm) when measured from the rear standoffs. Note: A 1-1/4" (32mm) clearance from the elbow must also be maintained. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 23 With the above options, maximum total pipe length if 37 feet with minimum of 5 feet total vertical and maximum 12 feet total horizontal. Please note minimum 1 foot between 90 elbows is required. Diagram 11 ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 24: Horizontal Terminations

    Diagram 1. Push the pipe sections recessed into the siding. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 25: Vertical Terminations

    11/12 to 12/12 1.22 over 12/12 to 14/12 1.52 over 14/12 to 16/12 1.83 over 16/12 to 18/12 2.13 over 18/12 to 20/12 2.29 Diagram 5 over 20/12 to 21/12 2.44 Diagram 3 ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 26: Installation Procedures

    2 x 4 or 2 x 6 walls. The liners must slip over the collars a minimum of 1-3/8". INSTALLATION PROCEDURES ® for Regency AstroCap Direct Vent System (Flex) 1) Locate the unit in the framing, rough in the gas.
  • Page 27: Conversion From Ng To Lp

    1) Remove the louvers and trim kit. Remove the front door. Fig. 1 Diagram 2 2) Remove the logs, embers. 5) Pull off the pilot cap to expose the pilot orifi ce. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 28: Installation Of The Dc Sparker

    # decal. 19) Replace yellow "NG" label with red "LPG" label. Fig.4 WARNING! Do not over tighten the screw. Recommended to grip the wrench by the short side. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 29 DC spark generator wires through the bushing on the heat shield. 31) Mount the heat shield to the DC Sparker. Secure into place with the velcro, which is Heat Shield provided in the kit. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 30: High Elevation

    PILOT ADJUSTMENT (High) 3.8"+/- 0.2"w.c. pressure tap(s) using a 5/16" ID hose. Log Set: Ceramic fi bre, 8 per set. 4) Light the pilot and turn the valve to "ON" Vent System: Regency ® Astrocap position. Regency ® Direct Vent System (Flex) and...
  • Page 31: Log Set Installation

    Avoid stacking platinum embers. IMPORTANT When placing Embers, do not block burner ports as this can cause an incorrect fl ame pattern, Tab on Burner Grate Post carbon deposits and delayed ignition. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 32 Ensure that the log fi ts into a pin that is Repeat step 6 on the opposite side of the burner. on Log 326. Grate Post Completed Log Set Installation: Repeat step 5 on the opposite side of the burner. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 33: Glass Door Removal

    Push trim tight Remove the 6 screws that secure the glass The Top and Bottom Side Louver or Grill is against magnet. door and repeat step 2. installed the same way. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 34: Option 1: Remote Control

    ® Use the Regency Remote Control Kit approved 1) Run the supplied 15' of wire through the back A wall thermostat may be installed if desired, connect for this unit. Use of other systems may void your gas inlet opening.
  • Page 35: Wiring Diagrams

    "S.I.T" Valve ON OFF Remote Receiver Remote Transmitter or Thermostat (Optional) (Millivolt) (Optional) CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 36 (To TH) Switch Black To Thermocouple IN "S.I.T" Valve ON OFF Remote Receiver Remote Transmitter or Thermostat (Optional) (Millivolt) (Optional) Terminal Block Location Terminal Block Remove cover to access Terminal Block ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 37: Operating Instructions

    Open - Short Blue LIGHTING Note: Aeration Adjustment should only be The fi rst fi re in your fi replace is part of the paint performed by an authorized Regency ® curing process. To ensure that the paint is PROCEDURE...
  • Page 38: Copy Of The Lighting Plate Instructions

    Listed below are some examples. All are normal operating sounds and should not be considered as defects in your appliance. Blower: Regency ® gas appliances use high tech blowers to push heated air farther into the room. It is not unusual for the fan to make a "whirring"...
  • Page 39: Maintenance Instructions

    Regency dealer only. Replacement glass is Note: Never operate the appliance without warranty. shipped already installed into the door frame.
  • Page 40: Removing Valve

    6) Remove the burner by removing the 4 screws. 7) Slide the burner assembly away from the 12) Lift the entire assembly out. orifi ce and lift out. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 41: Installing Valve

    15) Check the manifold pressure. 16) Reinstall the logs, grate and brick panels as needed. 17) Reinstall the glass doors. 18) Fire up the unit again and check for proper fl ame appearance. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 42: Parts List

    910-882 Wire - Valve to Burner Switch 360-529 Door Assy Side - Tempered 135) 360-069 Heat Shield - Side ® 205) 948-216 Regency Logo Plate 360-539 Door Assy Side - Ceramic 206) 910-171 Fan Axial 115V (Optional) 146) 360-033 Left Side Door Trim...
  • Page 43: P131-2 (Pier) Main Assembly

    Magnet Bracket - Corner 360-046 Nailing Strip - Top - Front 10) 360-047 Nailing Strip - Top - Side 150) 360-123 Magnet Bracket - Front 225) 948-216 Regency ® Logo Plate 11) 430-001 Standoff - Top 151) 904-258 Magnet 226) 910-412...
  • Page 44: P121Rc-2 (Right Corner) Main Assembly

    Dec. Grill Side - Black (set) 360-046 Nailing Strip - Top - Front 146) 360-035 Finishing Trim - Left Side 10) 360-047 Nailing Strip - Top - Side 225) 948-216 Regency ® Logo Plate 11) 430-001 Standoff - Top 226) 910-142 Thermodisc 780-013...
  • Page 45: P121Lc-2 (Left Corner) Main Assembly

    141) 360-031 Column Finishing Trim 360-046 Nailing Strip - Top - Front 146) 360-035 Finishing Trim ® 225) 948-216 Regency Logo Plate 10) 360-047 Nailing Strip - Top - Side 226) 910-142 Thermodisc 149) 360-122 Magnet Bracket - Corner 11) 430-001...
  • Page 46: P121/P121Lc/P121Rc/P131-2 Burner Assembly & Log Set

    Pilot Assembly Gasket 69) 910-190 Piezo Ignitor and Nut 79) 360-525 Burner Assembly 82) 360-027 Grate Assembly 904-690 Orifi ce #31 - NG 936-170 Orifi ce Gasket *Not available as a replacement part. ® Regency P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace...
  • Page 47: Warranty

    It is the general practice of FPI to charge for larger, higher priced replacement parts and issue credit once the replaced component has been returned to FPI and evaluated for manufacturer defect. The authorized selling dealer is responsible for all in-fi eld service work carried out on your Regency product. FPI will not be liable for results or costs of workmanship from unauthorized service persons or dealers.
  • Page 48 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency and Panorama are trademarks of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2010, FPI Fireplace Products International Ltd. All rights reserved.
