Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been tested
in accordance with AS4553, NZS 5262
and have been certified by the Australian
Gas Association for installation and op-
eration as described in these Installation
and Operating Instructions.
Your unit should be serviced annu-
ally by an authorised service person.
Panorama
Gas Fireplace
STYLE
See Thru
PG121NG1-R
Left Corner
PG121LCNG1-R
Right Corner PG121RCNG1-R
Pier
PG131NG1-R
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional in-
formation consult an authorized installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flam-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
by an authorized installer, service agency or
the gas supplier.
918-648e
PG121/PG131
®
MODEL
PG121LPG1-R
PG121LCLPG1-R
PG121RCLPG1-R
PG131LPG1-R
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electri-
cal switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fire
department.
12.19.16
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency Panorama PG121NG1-R
Summary of Contents for Regency Panorama PG121NG1-R
- Page 1 Owners & Installation Panorama PG121/PG131 ® Gas Fireplace STYLE MODEL See Thru PG121NG1-R PG121LPG1-R Left Corner PG121LCNG1-R PG121LCLPG1-R Right Corner PG121RCNG1-R PG121RCLPG1-R Pier PG131NG1-R PG131LPG1-R PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, altera- What to do if you smell gas: tion, service or maintenance can cause Do not try to light any appli-...
