Displaying Channels Using Gv Ip Device Utility - GeoVision GV-IP Decoder Box Quick Start Manual

3. To move the cursor (shown in yellow), press the up and down arrow
keys. To select a channel, press the right arrow key (shown in red).
4. Press the OK key, the selected channels will be displayed.
Note:
1. When the system idles over 30 seconds or resumes after power
interruption, the GV-IP Decoder Box / GV-Pad will automatically
display channels based on the last successful settings.
2. Every time when the search function
channels selected previously on the Device List will be unselected.
To add third-party IP channels, see 6. Displaying Channels Using GV IP
Device Utility in the Quick Start Guide.
To access the channels connected to GV-System, see 2.6 Displaying
Channels from GV-Mobile Server in GV-IP Decoder Box and GV-Pad
User's Manual on software DVD.
is performed, any
6

Displaying Channels Using GV IP Device Utility

You may use the GV IP Device Utility to add channels from GV IP devices,
GV-Mobile Server and third-party IP devices that adhere to RTSP, ONVIF
or PSIA. The GV IP Device Utility is available on software DVD.
1. Make sure your GV IP devices, GV-System or third-party IP devices
are under same LAN with the GV-IP Decoder Box / GV-Pad.
2. Install the GV IP Device Utility in a computer under the same LAN
with GV-IP Decoder Box / GV-Pad. Run the GV IP Device Utility. It will
automatically search for all the channels from GV IP devices and from
GV-System under the same LAN.
3. Click on the IP address of your GV-IP Decoder Box / GV-Pad and
select Connect Setting. This dialog box appears.
4. Type the ID and password of your GV-IP Decoder Box / GV-Pad and
click OK. For detail, see Configuring the ID and Password, 4.
Configuring the Basics in the Quick Start Guide. The Video
Connection Setting window appears.
