Options
Optional accessories can expand the capabilities and versatility of your
GV-IP Decoder Box / GV-Pad. Contact your dealer for more information.
Device
Wall Mount Kit
VESA monitor
mount kit
GV-Joystick
GV-WiFi USB
Adapter
Description
For GV-IP Decoder Box only.
Used to mount GV-IP Decoder Box on
wall.
For GV-IP Decoder Box only.
Used to mount GV-IP Decoder Box on
the back of a VESA monitor.
The GV-Joystick facilitates focusing,
zooming, panning, tilting of GeoVision
and third-party PT, PTZ and Speed
Dome cameras on GV-IP Decoder
Box / GV-Pad.
The GV-WiFi USB adapter is a
plug-and-play device that provides
wireless connectivity to GeoVision IP
devices. The GV-WiFi USB Adapter
complies with IEEE802.11 b/g/n (Draft
3.0) standards for wireless networking.
2
Overview

GV-IP Decoder Box

Front View
1 2
No. Name Function
1 LED Indicators The green LED indicates the system is ready
for use.
The red LED indicates the power is supplied.
2 USB Connect to a GV-Joystick, a USB storage device
or a GV-WiFi USB adapter.
3 IR Built-in IR receiver to receive the IR signals from
the IR remote control.
4 Default Reset the GV-IP Decoder Box to the default
factory settings. Use a pin to press the button
until the green LED fades. This will take about
10 seconds. The system will then reset and
reboot itself shortly.
5 SD Card Slot Connect to an SD card for local storage of
snapshot and firmware upgrade.
Back View
1
No. Name Function
1 Network Connect to the network.
2 HDMI Connect to an HDMI supported display device.
3 VGA Connect to a VGA monitor.
4 Power OFF/ON Switch the power on or off.
5 DC 12V Connect to power by using the supplied power
adapter.
Note: The SPDIF and L/R ports are not functional.
3 4 5
2 3 4 5
