GeoVision GV-IP Decoder Box Quick Start Manual page 6

3
Connection
GV-IP Decoder Box
2
2
1. Connect a display device to VGA connector or HDMI connector for
video output.
2. Connect the device to LAN.
A. For wired network, connect to a standard network cable.
B. For wireless network, insert a Wi-Fi USB adapter.
3. Connect to power using the supplied power adapter.
4. Turn the Power switch to ON.
Note:
1. The GV-IP Decoder Box can only be connected to one display
device through the HDMI or VGA connector.
2. The default video output is set to VGA with 1024 x 768 resolutions.
If you use an HDMI monitor, be sure to configure the output type. To
change the default setting or configure the output type, see 3.5
Configurging the Accout, Storage and Output Type in the GV-IP
Decoder Box and GV-Pad User's Manual on software DVD.
1
4 3
GV-Pad
3
2
1. Connect the device to LAN.
A. For wired network, connect to a standard network cable.
B. For wireless network, insert a Wi-Fi USB adapter.
2. Connect to power using the supplied power adapter.
3. Turn the Power switch to ON.
1
Continued on the reverse
