- Page 1 INSTALLATION INSTRUCTIONS USER GUIDE Chimney Pyramid Rangehood HC60PHTX1, HC90PHTX1 and HC120PHTX1 models NZ AU IN ROW...
-
Page 3: Table Of Contents
CONTENTS Introduction Safety and warnings Installation instructions Operating instructions Cleaning and maintenance Parts and accessories Manufacturer’s Warranty Customer Care IMPORTANT! Registration SAVE THESE INSTRUCTIONS Register your product with us so we can The models shown in this user guide may provide you with the best service possible. -
Page 5: Introduction
INTRODUCTION Thank you for purchasing a Fisher & Paykel product. Thousands of hours go into the design, engineering, testing and perfecting of each Fisher & Paykel appliance. The care and attention given to creating these beautiful products doesn’t stop once it has found its home with you. This use and care manual will answer most of your questions about the set-up, use and on-going maintenance of your Fisher &... -
Page 6: Safety And Warnings
SAFETY AND WARNINGS WARNING! Weight Hazard The appliance is heavy. Please ensure adequate care is taken when installing the appliance to prevent personal injury. The appliance must be installed onto a solid wall, stud, beam or truss. Weight of the products are 14 kg (HC60) / 16 kg (HC90) / 19 kg (HC120). - Page 7 SAFETY AND WARNINGS Exhaust air must not be discharged into an existing flue that is used for exhausting ● ● fumes from appliances burning gas or other fuels. There shall be adequate ventilation of the room when the rangehood is used at the ●...
-
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS Contents of packaging INSTALLATION INSTRUCTIONS USER GUIDE Chimney Pyramid Rangehood HC60PHTX1, HC90PHTX1 and HC120PHTX1 models NZ AU IN ROW Rangehood hood Installation instructions Chimney User guide manual Upper chimney Upper chimney bracket Chimney bracket 150 mm diameter Expansion plug 30 mm self-tapping screw... - Page 9 INSTALLATION INSTRUCTIONS Product dimensions Power cord location Ø HC60PHTX1 HC90PHTX1 HC120PHTX1 PRODUCT DIMENSIONS Overall height of product 655 – 1094 655 – 1094 655 – 1094 Overall width of product 1198 Overall depth of product Height of product Width of chimney...
-
Page 10: Installation Instructions
INSTALLATION INSTRUCTIONS Height of rangehood INSTALLATION DIMENSIONS Installation height Ducted min. 680 – max. 1094 Recirculation min. 720 – max. 1094 Height top of cooktop to base of product min. 660 – max. 750 Rangehood installation height above the cooktop is the user’s preference. Lower installation heights will improve the efficiency of capturing cooking odours, grease, and smoke. - Page 11 INSTALLATION INSTRUCTIONS Venting options Attention should be given to ensure that any applicable regulations concerning the discharge of exhaust air are fulfilled. The rangehood can be installed to operate with the exhaust air ducted externally from the kitchen, or installed to operate with the exhaust air recirculating within the kitchen. Ducted For ducted installation it is recommended that 150 mm diameter, rigid or semi-rigid ducting is used.
- Page 12 INSTALLATION INSTRUCTIONS Installation WARNING! This appliance is heavy and requires two persons for unpacking and installation ● ● Installation work and electrical wiring must be done by qualified person(s) in ● ● accordance with all applicable codes and standards. Failure to install the screws or fixing device in accordance with these instructions ●...
-
Page 13: Upper Chimney Bracket
INSTALLATION INSTRUCTIONS Upper chimney bracket attachment point Chimney bracket attachment point Upper rangehood attachment point Lower rangehood attachment point Fig.2 PRODUCT DIMENSIONS Lower rangehood attachment point width Lower rangehood attachment point height Upper rangehood attachment point width Upper rangehood attachment point height Chimney bracket attachment point width Chimney bracket attachment point height Upper chimney bracket attachment point width... - Page 14 INSTALLATION INSTRUCTIONS Fig.3 Attach the ducting adapter to the rangehood Place the ducting adapter onto the ● ● rangehood and screw it in place using 10 mm screws.
- Page 15 INSTALLATION INSTRUCTIONS Wall mounting Remove the filters – pull the relative catch and tilt the filter downwards until it ● ● disengages from the supports. Hang the rangehood off the upper rangehood mounting screws with 2 mm gap. ● ● Hang off the keyhole attachment points on the back of the rangehood then tighten the screws.
- Page 16 INSTALLATION INSTRUCTIONS Attach the ducting Attach ducting to the ducting adapter using aluminium duct tape and vent outside. ● ● Attach chimney Bend the tabs on the chimney (A). ● ● Place chimney around the rangehood chassis and hang off the chimney bracket (B). ●...
-
Page 17: Operating Instructions
OPERATING INSTRUCTIONS Control panel CONTROL PANEL FEATURES Light Turns the light on and off. Power ON/OFF Turn the rangehood on or off. The fan automatically turns on to operate at level 1. Reduce fan speed Adjust the fan speed levels from 1 – 3 with 1 being the lowest. -
Page 18: Cleaning And Maintenance
CLEANING AND MAINTENANCE WARNING! Unplug or disconnect the appliance from the power supply before servicing or cleaning. IMPORTANT! Never use abrasive or oil based cleaners. ● ● Wear gloves to protect against sharp edges. ● ● Maintenance The rangehood should be cleaned regularly using a mild, liquid detergent and a clean soft cloth to avoid a build-up of grease occurring. -
Page 19: Parts And Accessories
PARTS AND ACCESSORIES ITEM REFERENCE NUMBER Aluminium filter 792564 Recirculation carbon filter x2 792481 Recirculation diverter 792560 Ducting kit 150 mm (eaves) PD-RHK150E Ducting kit 150 mm (wall) PD-RHK150W... -
Page 20: Manufacturer's Warranty
MANUFACTURER’S WARRANTY You automatically receive a 2 year Manufacturer’s Warranty with the purchase of this rangehood covering parts and labour for servicing within the country of purchase. Fisher & Paykel undertakes to: Repair or, at its option, replace without cost to the owner either for material or labour any part of the product, the serial number of which appears on the product, which is found to be defective within TWO YEARS of the date of purchase. - Page 21 MANUFACTURER’S WARRANTY For Australian Customers This Manufacturer’s Warranty is an extra benefit and does not affect your legal rights. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage.
-
Page 22: Customer Care
CUSTOMER CARE Before you call for service or assistance... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: Your product is correctly installed. You are familiar with its normal operation. If after checking these points you still need assistance or parts, please refer to your nearest Fisher &... -
Page 23: Registration
CUSTOMER CARE *If you call, write or contact us via our website please provide: your name and address, model number, serial number, date of purchase and a complete description of the problem. This information is needed in order to better respond to your request for assistance. -
Page 24: Www.fisherpaykel.com
www.fisherpaykel.com Copyright © Fisher & Paykel 2016. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your dealer to ensure this booklet correctly describes the product currently available.
