1
PANEL DESCRIPTION

Multi function switches

D
M1 FUNCTIONS
During SSB operation
AGC DUP
F 1 F 2
During SSB data operation
AGC DUP
F 1 F 2
During CW operation
AGC DUP
F 1 F 2
During RTTY operation
AGC DUP
F 1 F 2
During AM operation
AGC DUP
F 1 F 2
During FM operation
AGC DUP
F 1 F 2
AGC (p. 49)
Push momentarily to changes the time
AGC
constant of the AGC circuit.
F 1
Push for 1 sec. to enter to the AGC set
mode.
DUPLEX (p. 44)
Push momentarily to selects the duplex
DUP
direction or turn the function OFF.
F 2
• "DUP–" or "DUP+" indicator appears during
duplex operation.
Push for 1 sec. to turn the one-touch re-
peater function ON/OFF.
SPEECH COMPRESSOR (p. 58)
Push momentarily to turn the speech
CMP
compressor function ON/OFF.
F 3
• "COMP" indicator appears when the speech
compressor is ON.
Push for 1 sec. to enter to the compres-
sor set mode.
11
CMP TBW SCP
F 3 F 4 F 5
1/4 SCP
F 3 F 4 F 5
1/4 KEY SCP
F 3 F 4 F 5
1/4 RTY SCP
F 3 F 4 F 5
CMP SCP
F 3 F 4 F 5
CMP TON SCP
F 3 F 4 F 5
1
⁄ FUNCTION (p. 21)
4
Push to turn the
1/4
• " " indicator appears when the
F 3
ON.
TRANSMISSION BANDWIDTH (p. 58)
Push to select the transmission bandwidth.
TBW
• Bandwidth is selectable from narrow, middle
F 4
and wide.
MEMORY KEYER MENU (p. 29)
Push to select the memory keyer or keyer
KEY
send menu, depending on the KEYER
F 4
1st Menu setting in the set mode (p. 86).
RTTY MENU (p. 36)
Push to select the RTTY menu.
RTY
F 4
BAND SCOPE FUNCTION (p. 47)
Push to select the band scope screen.
SCP
F 5
D M2 FUNCTIONS
SCN MEM SWR
F 1 F 2
SCAN MENU (p. 70)
Push to select the scan menu.
SCN
F 1
MEMORY NAME MENU (p. 67)
Push to select the memory name screen.
MEM
F 2
SWR GRAPH FUNCTION (p. 61)
Push to indicates the SWR graph screen.
SWR
F 3
TONE CONTROL SET MODE (p. 88)
Push to enter the audio tone set mode.
TCN
F 4
VSC FUNCTION (p. 54)
Push to turns the VSC (Voice Squelch
VSC
Control) function ON and OFF.
F 5
1
⁄ function ON/OFF.
4
1 ⁄ function is
4
TCN VSC
F 3 F 4 F 5
