CONTENTS
INTRODUCTION
CHECK LIST
APPROVALS
CONSTRUCTION
INSTALLATION
LOCATION
COLD WATER INLET
DIMENSIONS AND WEIGHTS
VENT / OVERFLOW
ELECTRICAL CONNECTIONS
USER INSTRUCTIONS
SCALE
GENERAL OPERATION
CLEANING
TROUBLE SHOOTING
ACCESSORIES
SPARE PARTS
EXPLODED DIAGRAM
SERVICE INSTRUCTIONS
GENERAL FUNCTION
WIRING DIAGRAM
SERVICE HISTORY NOTES
WARRANTY
PRODUCT SPECIFICATION
Page 2
PAGE
3
3
3
4
4
4
5
6
7
8
8
9
9
9
10
11
12/13
14/15/16/17
18/19
20
21
22
23
24

INTRODUCTION

Thank you for purchasing a boiler from the Calomax Eclipse range.
All our products are designed to give years of simple, reliable
operation. To ensure this, it is important that the installation and
subsequent servicing and maintenance is carried out by a suitably
qualifi ed engineer in accordance with these instructions. For
assistance in fi nding a suitable engineer in your area, visit our
website www.calomax.co.uk, contact our service department on
0113 249 6681 or e-mail: service@calomax.co.uk
CHECK LIST counter top models
Before commencing installation, check that the following parts have
been supplied with the boiler:
1. WRAS approved fl exible water inlet hose suitable for
potable water.
2. Drip tray kit
CHECK LIST wall mounted models
Before commencing installation, check that the following parts have
been supplied with the boiler:
1. Wall mounting bracket

APPROVALS

This product conforms to the CE marking directive 93/68/EEC
through compliance with the following standards:
Electromagnetic Compatibility Directive
Low Voltage Directive 73/23/EEC in accordance with:
BS EN 60335-2-75:2004. Compliance with these standards
has been confi rmed through testing by an independent NAMAS
approved body
The tap handle and drip tray (part ref: MDTBK
where supplied) have been treated with Steritouch
additive and independently tested to prove
the effectiveness of the surface hygiene.
Page 3
