HARDWARE OVERVIEW > Shadow Series 8/16-Ch
FRONT
2
4
1
3
1.
USB Ports:
Top - for Firmware Update and/or Video Backup
Bottom - for Mouse
2.
Recording Indicator LED
3.
Network Indicator LED
4.
IR Sensor for Remote
BACK
1.
DC12V Power Input
2.
RJ45 Network Connection
3.
RCA Video Output - Main
4.
RCA Video Output - Spot
5.
Camera Inputs (uses BNC to Multi-Pin Plug Adapter)
3
MAIN
DC+12V/5A
NETWORK
SPOT
HDMI
2
6
1
4
6.
HDMI Video Output - Main
7.
VGA Video Output - Main
8.
Sensor/Audio/RS485/Alarm Connections
9.
Connection Diagram
D1 (704x480) Version
5
9
CAMERA INPUTS
RS
SENSOR
AUDIO
ALARM
S
T
S
S
S
S
M
M
485
P
X
1
3
5
7
1
3
VIN
+
1
2
K
G
T
S
S
S
S
M
M
N
X
NO
2
4
6
8
2
4
2
D
-
1
VGA
8
7
