- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
-
Page 3: Table Of Contents
Table of Contents Warning Precautions Components Installation Operation Button Functions Top/Front Initial Start Up Live View Recording View Playback View System Settings Main Menu Date / Time Setup Motion Setup Manual Record Schedule Record Continuous Record SD-Card System Status Power On Setup Factory Settings Possible Recording Time Troubleshooting... -
Page 4: Warning
Warning The camera requires periodic inspection. Contact an authorized technician to carry out the inspection. Stop using your camera when you find it malfunctioning. If the camera emits smoke or is unusually hot for a long period, a fire may be caused. -
Page 5: Precautions
Precautions Do not install the camera in Do not install or use the camera extreme temperature conditions. in an environment where the humidity is high. Only use the camera under conditions It can cause the image quality to be where temperatures are between poor. - Page 6 Do not drop the camera or subject Never keep the camera pointed it to physical shocks. directly at strong light. It can cause malfunctions to occur. It can damage the CCD. Do not expose the camera to rain Do not expose the camera to or spill beverage on it.
-
Page 7: Components
Components Sales: 1-800-447-3306 Support: 1-800-549-6393 www.clintonelectronics.com... -
Page 8: Installation
Installation Mounting with included wall mount bracket Battery Compartment Access SD-Card Insertion, Video Output, DC Power Supply Sales: 1-800-447-3306 Support: 1-800-549-6393 www.clintonelectronics.com... -
Page 9: Operation
SD card ON / OFF Operation Button Functions EXIT PLAY MENU PAUSE EXIT STOP I>> <<I DOWN Name Function Exit / Stop Stop record / Play, or Exit sub-menu Menu: Confirm or open sub menu Menu/Set Live View: Open main menu Live View: Start playback Play/Pause Playback: Pause playback, press again to continue playback... -
Page 10: Top/Front
Operation continued POWER SD card ON / OFF Front View Top View EXIT PLAY MENU PAUSE STOP EXIT <<I I>> DOWN POWER SD card ON / OFF EXIT PLAY MENU DC 12V A / V OUT PAUSE EXIT STOP I>> <<I DOWN Name... -
Page 11: Initial Start Up
Initial Start Up 1. To turn the device ON / OFF: • Move the switch on the top of the device to the on or off position. This switch is slightly recessed to prevent accidental or unwanted switching. NOTE: Each time after power-on, the system auto-detects its peripherals. When the REC LED flashing indicates that the SD card is proceeding testing (complete boot time is several seconds) When an image file error has been detected, the system will display error message on OSD. -
Page 12: Live View
Live View If the video output of the device is connected to a monitor, you can view the live images on the monitor. The following icons may be shown: Live View Function Shows the current date and time. Shows the recording setup: Shows the recording resolution Shows the recording quality Shows the status of the SD card:... -
Page 13: Recording View
Recording View Recording View Function Record Status: Device is recording data Record Mode: Manual Record Motion Detection Schedule Record Record Storage Mode Status: Overwrite is activated There are three different ways to start recording: Symbol Mode Start Recording Function Manual Press [ ] button to start recording Schedule Recording... - Page 14 Recording View continued To continue the recording following a stop or pause, proceed as follows: Mode Continue Recording Function Manual Press [ ] button again Schedule Recording, Exit playback or menu Motion Detection 1. The event status is determined by the system recording, according to the order of priority.
-
Page 15: Playback View
Playback View To start playback, you can decide between two different modes: Normal Playback During live view press the playback/pause [ ] button to start normal playback: Symbol Normal Playback Function Normal playback speed During the normal playback press [ ] or [ ] button to rewind or fast forward. - Page 16 POWER Event List Function SD card ON / OFF The file view shows the date of recording and the number of files belonging to the recording. To navigate press the direction button up or down and EXIT MENU PLAY press [ ] button to playback.
-
Page 17: System Settings
System Settings Main Menu In the top right corner the menu level is shown: First level (main menu) Second level POWER Third level SD card ON / OFF POWER − Press [ ] or [ ] buttons to navigate. SD card ON / OFF EXIT PLAY... -
Page 18: Date/Time Setup
Date/Time Setup • Date Format : Here you can change the way the date is displayed. • Date/Time Adjustment : Here you can change the date and time. Motion Setup Set MD Area The motion detection area is split up into 16 x 12 cells. Cells which are marked to detect motion are displayed in red. -
Page 19: Manual Record
POWER Motion Setup continued SD card ON / OFF EXIT MENU PLAY In order to navigate use [ ] buttons and confirm by pressing [ PAUSE EXIT STOP button. Press [ ] record button in order to change the editing mode. •... -
Page 20: Schedule Record
Manual Record continued − VIDEO SIZE / FRAME RATE: Here you can change the video size and frame rate for the manual recording. Video Size 640 x 480 1280 x 720 1920 x 1080 Max. Frame Rate 1 fps 2 fps 4 fps 10 fps 15 fps... - Page 21 Schedule Setup SCHEDULE SETUP SCHEDULE : ON : ALL : NONE Mode Schedule Setup Function SCHEDULE Recording ON / OFF (default value is OFF) 00 - 23 With [ ] and [ ] buttons you can navigate between the hours.
-
Page 22: Continuous Record
Motion Record continued − Motion record functions: • VIDEO SIZE : Here you can set the recording resolution. • FRAME RATE : Here you can set up how many fps to be recorded. • QUALITY : Here you can set the recording quality. •... -
Page 23: Sd-Card
l SD-Card − SD-Card functions: • DISK TOTAL : Shows the total capacity of the inserted SD-Card. • DISK REMAIN : Shows the remaining capacity of the inserted SD-Card. • MAX FILE SIZE : Here you can set the max. file size (3 ~ 100 MB) of a recording. -
Page 24: Power On Setup
l Power on Setup − Power On Functions: • LANGUAGE : Here you can set the OSD menu language. • COMPOSITE : Here the video standard for the video output is shown. l Factory Settings Here you can reset all settings, except Date and Time, to factory default. POWER SD card ON / OFF... -
Page 25: Possible Recording Time
Possible Recording Times Frame Rate 30 fps at 30 fps at Resolution 640x480 1280x720 Quality 32GB SD-Card (example) High 134 Hrs. Normal 290 Hrs. Basic 434 Hrs. Recording times are approximate. Design and specifications are subject to change without notice. Sales: 1-800-447-3306 Support: 1-800-549-6393 www.clintonelectronics.com... -
Page 26: Troubleshooting
Troubleshooting If you have trouble operating your device, refer to the following table. If the guidelines do not enable you to solve the problem, contact Clinton Electronics Technical Support at 1-800-549-6393 or 815-633-1444. Problem Solution Why is the power button not •... - Page 27 The material in this document is subject to change without notice. While reasonable efforts have been made to assure the accuracy of this document, Clinton Electronics and it’s employees assume no liability resulting from errors or omissions in this document, or from the use of the information contained herein. Clinton Electronics...
