10
To change the order of the DVR listing; press EDIT, then press and hold the 3 horizontal lines and move to the
desired location
GTDvr
192.168.1.30:7000
HD-SDI
173.15.127.114:7734
HYBRID
173.15.127.114:6734
LIVE VIEW MENU SCREEN:
CEC Connect can be viewed either in Portrait (vertical) or Landscape (horizontal) mode. Rotate the phone to change
between the two viewing options.
1.
Exit to Main Menu (DVR Address Menu)
2.
DVR Name
3.
Search Recorded Video
4.
PNG (Image) Export
5.
Freeze Live Video
REMOTE ACCESS > CEC Connect App
1
4
5
6
Screen images from iOS ver9.1
HYBRID
173.15.127.114:6734
HD-SDI
173.15.127.114:7734
GTDvr
192.168.1.30:7000
2
7
8
6.
Date & Time Info
7.
Multiplex Views (1 / 4 / 9 / 16)
8.
PTZ Control
9.
Help
3
TOP
MENU BAR
Frame Rate
(hidden under menu bar)
BOTTOM
MENU BAR
9
83
