HARDWARE OVERVIEW > Shadow Series 8/16-Ch
FRONT
2
1
1. USB Ports:
Top - for Firmware Update and/or Video Backup
Bottom - for Mouse
2.
Recording Indicator LED
3.
Network Indicator LED
4. IR Sensor for Remote
BACK (16-Ch Shown)
CH1
CH2
1
1. Audio Input (Channels 2-16, uses RCA to Multi-Pin Plug Adapter)
2. BNC Camera Inputs
3. BNC Video Output - MAIN or SPOT
*MAIN or SPOT configured in DVR Settings
4. HDMI Video Output - MAIN
5.
RCA Audio Input (Channel 1)
6. RCA Audio Output
6
4
3
2
CH3 CH5 CH7 CH9
CH4 CH6 CH8 CH10
3
CH11 CH13 CH15
AUDIO IN
CH12 CH14 CH16
4
7. VGA Video Output - MAIN
8. RJ45 Network Connection
9. USB Port - for Mouse
10. Alarm Connection
11.
RS485
12. DC12V Power Input
Late 2015 960H Version
