TO BACKUP RECORDED VIDEO:
1. Insert CD/DVD (if the DVR is equipped with a CD-RW/DVD-RW disk drive) or formatted USB into the DVR.
2. Move the mouse cursor to the top of the screen and click the BACKUP icon, the second icon from the left. Or with
the remote control press the Backup button to display the BACKUP menu.
3. Click [NONE] in the Target row. If a USB or CD/DVD is inserted into the DVR it will be displayed.
4. Select which device to use.
5. Set From (start) & To (stop) Dates & Time. The longer the time frame, the longer it will take to backup video.
6. Name the file if desired by clicking [backup] in the BACKUP TITLE row.
7. Click the [ON] button next to SELECT CAMERA to select which cameras will be saved. The more cameras selected-
the larger the file size.
8. Click the [ESTIMATE] button. Doing so ensures there is enough room on the selected disk/USB for the saved video.
If the file is too large it can not be saved. To lower the file size either shorten the amount of time to be saved or select
fewer cameras.
9. Click [WRITE] to start the backup process. A progress bar displays the percentage of completion.
10. Once the video is backed up, the DVR will beep. It is now safe to remove the USB device or disc from the DVR.
Select the desired drive/device

BACKUP

Click STOP to
cancel the backup
Available space on
selected device.
Click ESTIMATE before
writing save file.
Click HIDE to return to
regular DVR operation
75
