3.7

Status LEDs

Pos: 43 /806-IHSE/Beschreibung/Diagnose LEDs/490-xx/490-xx Diagnose KVM-Extender-Modul @ 15\mod_1455285196917_6.doc @ 165912 @ 3 @ 1
3.7.1

Status KVM Extender Module

The KVM Extender module is fitted with a multi color LED on both sides
for overall status indication and with two further LEDs on the back side for
indication of the connection status.
CPU Module
Rear View
LED 1 and 2: Connection Status Link 1
LED 3 and 4: Connection Status Link 2
Pos. LED
1, 3
2, 4
LED 5: USB and Video Status Link 1
LED 6: USB and Video Status Link 2
LED color
Red
Violet
Green /
light blue
flashing
Light Blue
2016-02-29
1 2 3 4 5 6
1 2 3 4 5 6
Status
Failure LED Off
(green)
On or
Flashing
Status LED Flashing
(green)
On
Description
Device ready
Connection and USB signal (interconnect) available
Connection and video signal available
Connection, USB and video signal available
(operating status)
CON Module
1 2 3
1 2
Rear View
Description
Connection available
Connection failure (flashing for about
20 s following a connection failure)
No connection via interconnect cable
Connection available
Description
4 5 6
3 4 5 6
