Ihse KVM-TEC ScalableLine 4K/5K Quick Instruction

First
Aid
ScalableLine - 4K/5K
No Power USB is not
working
(No LED)
Are the USB
Check the
Devices plugged
powerplug
in correctly?
Is the USB cable
Is the power
on the Local side
supply ok? Try
plugged into the
another Unit.
PC?
Are the USB
Contact kvm-tec
Devices working
support
directly on the
PC?
Replace the USB
cable from PC to
the Local
Extender
Check if local
and remote Unit
have the same
fi rmware
Check if the local
or the remote
Unit is causing
the problem by
swaping fi rst the
local and than the
remote Unit to
another Unit
Contact kvm-tec
support
We are here for you to answer
your questions about installation?
Manual download www.kvm-tec.com
kvm-tec Installationchannel on our homepage
Video error
No video
(stripes in the
picture)
Check if all
Check if all
cables are plug-
cables are plug-
ged in correctly
ged in correctly
Check if the DDC
Check that the PC
is set correctly (in
is turned on, as
the menu under
well as checking
point „o")
the status LED
Check if local and re-
Check if the DDC is
mote Unit have the
set correctly (in menu
correct fi rmware
under point „O")
Ist im im Switching
Manager Frontend Check if the
, „Video" aktiv -
network switch
Video / no Video
is setup correctly
and has enough
bandwidth
Contact kvm-tec
support
Check if other units
have the same
behaviour
Contact kvm-tec
support
or
personally +43 2253 81912
V102022
Scalable
Quickinstruction
free scalable
ScalableLine
4K/5K
Multiview Systems
line
www.kvm-tec.com
Misprints, errors and technical changes reserved
