Model L- / R490-BPHC

CPU Module
1
Rear View
1 Service port
2 Connect to interconnect cable
3 To CPU: USB-HID
4 To CPU: DisplayPort
Pos: 21 /806-IHSE/Beschreibung/Geräteansichten/490-xx/Typ L- / R490-BPHS / -BPHX @ 15\mod_1455283096578_6.doc @ 165647 @ 3 @ 1
3.6.9

Model L- / R490-BPHS / -BPHX

CPU Module
1
Rear View
1 Service port
2 Connect to interconnect cable
3 To CPU: USB-HID
4 To CPU: DisplayPort
Pos: 22 /806-IHSE/zz_Layout/Seitenumbruch @ 8\mod_1348581820516_0.doc @ 69462 @ @ 1
22
2 3 4
2 3 4
CON Module
1 2
Rear View
1 Service port
2 Connect to interconnect cable
3 Connect to USB-HID devices
4 Connect to DisplayPort monitor
CON Module
1 2
Rear View
1 Service port
2 Connect to interconnect cable
3 Connect to USB-HID devices
4 Connect to DisplayPort monitor
3 4
3 4
