1-way paging remote engine starting & keyless entry system with 5 button sidekick remote control dp series (data port)
Hide thumbs Also See for Cool Start RS-1405DP:

Advertisement

RS-1405DP/RS-1505DP
DP SERIES (Data port)
1-Way Paging Remote Engine Starting & Keyless
Entry System with 5 Button Sidekick Remote Control
-PRIMARY: These are features that must be connected in order for the system to operate properly i.e.
Remote Start connections, Flashing lights, Brake Reset. For programming, the hood pin and program button
are required.
-OPTIONAL: These are features are to be connected only if desired or agreed upon by the customer and the
installing dealer i.e. Door Locks, Trunk Pop, Dome Light Illumination, Horn-Honk, Anti-Grind, etc. These
features may also require additional parts and/or labor fees. Consult with your installer beforehand to be sure
of what is going to be installed with your particular system.
TECHNICAL SUPPORT: (800) 998-6880
Monday - Friday 8:00am - 4:30pm Pacific Std. Time
Web Site: www.crimestopper.com
E-mail: email@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV A – 10.26.2005
OPERATING INSTRUCTIONS
This device complies with FCC Rules part 15. Operation is
subject to the following two conditions: 1) This device may not
cause interference, and (2) this device must accept any
interference that may be received, including interference that
may cause undesired operation.
responsible for any radio or TV interference caused by
unauthorized
modification could void the user's authority to operate the
equipment.
The manufacturer is not
modification
to
this
equipment.
Such

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cool Start RS-1405DP and is the answer not in the manual?

Questions and answers

Summary of Contents for CrimeStopper Cool Start RS-1405DP

  • Page 1 TECHNICAL SUPPORT: (800) 998-6880 Monday - Friday 8:00am - 4:30pm Pacific Std. Time Web Site: www.crimestopper.com E-mail: email@crimestopper.com CRIMESTOPPER SECURITY PRODUCTS, INC. 1770 S. TAPO STREET, SIMI VALLEY, CA. 93063 REV A – 10.26.2005 OPERATING INSTRUCTIONS This device complies with FCC Rules part 15. Operation is...
  • Page 2: Table Of Contents

    Troubleshooting “Before You Call”………….…………..………………………………………….…………..….12-13 OPERATION CAUTIONS & WARNINGS CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be liable for any accident resulting from the use of this equipment. This system is designed to be professionally installed into a car or vehicle in which all items, such as parking brake and all associated components, door switches, transmission shift linkage, throttle linkage, and all engine safety features, are in perfect working condition.
  • Page 3: Remote Operation

    The transmitter supplied with the RS-1405DP/1505DP system has five buttons. The button configuration of the RS-1405DP/1505DP is Factory-set and unchangeable. See Page 12 for additional information on how to use your remote to operate a second vehicle equipped with a CoolStart system.
  • Page 4: Remote Engine Starting ,Idle Down Mode, Infinity Run Mode

    REMOTE ENGINE STARTING - SUCCESSFUL START: 1) Press the remote start button for at least 1/2 second (Default) or twice if set for double press. 2) Parking lights flash once; return solid, and the Ignition/Acc circuits turn on. 3) After a few seconds the Starter Motor engages, Parking lights and Acc circuits will turn off while cranking. 4) Engine Starts and Runs.
  • Page 5 2) Enter vehicle and be careful not to step on brake pedal! (Remote Start Reset). 3) Turn Ignition to ON/RUN position, then press brake pedal to reset the Remote Starter & Shift out of park. 4) Remote starter will reset instantly when the brake is pressed. Parking lights will turn off and the ignition key is now controlling your vehicle.
  • Page 6 2. Enter vehicle and be careful not to step on brake pedal! (Remote Start Reset) 3. Turn Ignition to ON/RUN position, then depress brake pedal to reset the Remote Starter. Parking lights will turn off indicating the Remote Start is OFF and Vehicle is running by the Key. Drive away as normal INFINITY RUN MODE This mode can only be activated when "Idle Down"...
  • Page 7 REMOTE ENGINE STARTING Cont. (Infinity Run Mode) INFINITY RUN MODE – EXITING THE VEHICLE: 1) With vehicle engine running with the key, **press the Remote Start button for at least 1/2 second, pause a few seconds, then press and release the remote start button a second time. 2) Parking Lights will start flashing, and doors will unlock.
  • Page 8: Turbo Timer Mode

    TURBO TIMER MODE (OPTIONAL) The optional Turbo Timer mode allows the CoolStart system to keep a Turbo or Turbo Diesel vehicle running for 1 to 5 minutes [selectively] after you remove the key, exit the vehicle, and lock the doors remotely. This is handy for turbo cool-down without the need for expensive turbo timers.
  • Page 9: Convenience And Safety Features

    CONVENIENCE AND SAFETY FEATURES KEYLESS ENTRY (POWER DOOR LOCK CONTROL, Optional) This system enables you to remotely lock and unlock the vehicle’s doors (if equipped with power locks) via remote control for safety and convenience. Note: This feature may require extra labor and/or parts to install. Press the Lock or Unlock transmitter button as you leave or come near the vehicle.
  • Page 10 This Optional feature prevents the user from accidentally grinding the starter if the Ignition key is turned too far to the start position while engine is already running from the remote starter. The Anti-Grind/Starter Disable requires the use of an external relay.
  • Page 11: Transmitter Programming

    Note: All transmitter codes must be learned at time of programming!! The unit will learns up to 4 different transmitter codes. 1. Open Hood (If no hood pin installed with your system, then you must ground the Blue Hood pin wire). 2.
  • Page 12: Vehicle Operation

    2-VEHICLE OPERATION A single remote can control two different vehicles CoolStart systems installed. However, both systems must be the same type. RS-1405DP/1505DP are only compatible with each other. Programming: You must first Programming your remote for 2 vehicle operation: Vehicle Programming and Operation instruction): In step #4 of transmitter programming (see page 11) press and hold middle button #5 for 2 sec., then press the lock...
  • Page 13 SYSTEM IS UNSUCCESSFUL AT REMOTE START DURING EXTREME COLD CONDITIONS: Please be aware that during sub-freezing conditions your remote starter may take more that one attempt to start or it may not successfully start the vehicle after 3 attempts. During these conditions the vehicle may not properly start even using the key;...
  • Page 14: Battery Replacement

    To replace the battery: Simply remove the screws on back of the transmitter and open the case. Remove the battery and replace. The replacement battery for all transmitters is GP23A. www.crimestopper.com email@crimestopper.com © 2005 Crimestopper Security Products BATTERY REPLACEMENT ONLINE TECHNICAL SUPPORT http://www.crimestopper.com/index3.html...
