RADIO CONTROL MODEL
Semi Scale – Almost ready to fly
P-51D MUSTANG

ASSEMBLY INSTRUCTION

.40 - .46 CLASS – 2 CYCLE ENGINE
.60 - .70 CLASS – 4 CYCLE ENGINE
WARNING: This radio control model is not a toy. If modify or
flown carelessly, it could go out of control and cause serious
bodily injury or property damage, It is your responsibility to
build this kit correctly, to properly install all components and to
seek the help of an experienced R/C pilot for a pre-flight sa
inspection and flight test.
NORTH AMERICAN
fety

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P-51D MUSTANG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VQ P-51D MUSTANG

Summary of Contents for VQ P-51D MUSTANG

  • Page 1: Assembly Instruction

    RADIO CONTROL MODEL Semi Scale – Almost ready to fly NORTH AMERICAN P-51D MUSTANG ASSEMBLY INSTRUCTION .40 - .46 CLASS – 2 CYCLE ENGINE .60 - .70 CLASS – 4 CYCLE ENGINE WARNING: This radio control model is not a toy. If modify or...
  • Page 2 REQUIRED FOR OPERATION (Purchase separately) For 40 ~ 46 ( 2 cycle engine) For 60 ~ 70 (4 cycle engine) 10.5x6 ~ 11x6 12x6 ~ 13x7 Extension for aileron servo Silicon tube Minimum of 4 channel airplane 40 ~ 46 2 cycle 60 ~ 70 4 cycle radio (with 4 standard servos).
  • Page 3 4- Retract Push rod 50mm 130mm To retract servo To landing gear 10mm RIGHT RETRACT PUSHROD 30mm LEFT RETRACT PUSHROD To landing gear To retract servo 50mm 80mm 5- Retract landing gear Installation Right Wing Top-view Left RETRACTED EXTENDED Retract servo Push rod Retract gear Gear cover...
  • Page 4 Fix main gear 7- Gear cover Fitting strap ABS Gear cover Collar Stopper Wing Bottom-view 8- Fix gear Gear cover ABS Wheel well cover (for fix gear) 3mm screw 9- Air Scoop Bottom-view Plastic air scoop 12mm 6x40 nylon bolt 12mm Plastic cover Cut away the covering inside...

  • Page 5: Top View

    10- Air-scoop - Bottom wing cover Plastic mount nut Wing bolt block (Ply wood) Plastic cover Plastic air scoop 6x40 plastic bolt 11- Four-stroke Engine 3.1mm ! Engine thrust on balk head is already adjust at factory ! Before installing the engine mounts, place the engine onto the mounts and make four 3.1mm holes 2.5mm...

  • Page 6: Fuel Tank Installation

    13- Fuel tank installation After confirming the direction . Insert this assembly, clunk end first, into the fuel tank and tighten and screw the fuel tank cap on To muffler firmly. Filler tube Rubber stopper To engine 3x35 mm screw 3x35mm screw 14- Vertical / Horizontal Tail A = A’...

  • Page 7: Bottom View

    15- Tail gear Collar 3x12mm screw 12~15mm 1.5mm BOTTOM VIEW 1.5mm BOTTOM VIEW 16- Linkages Plastic control horn ......1 Rudder rod Plastic back plate ......1 Elevator rod Elevator rod 2x10mm screw .......2 10mm -When you are satisfied with the alignment of the control horn mark the mounting hole positions with a felt tipped pen or a pencil.
  • Page 8 18-Servo / Push rod Rudder push rod Rudder servo Elevator push rod Throttle pushrod Throttle servo Elevator servo Elevator pushrod 3mm set Screw 3mm set Screw Elevator pushrod Rudder pushrod (Or throttle pushrod) Connector 2 mm 2 mm ..3 Connector ..
  • Page 9 20- Cowling The box art can be used for the placement of the decal 1.5mm Decal 2x10mm screw Relieve the cowl to clear the engine head 2x10mm screw ...4 Drill hole for needle valve 10mm 21- Balance DO NOT try to fly an out-of-balance model ! 132 mm Wing center section 22- Control Surface...
