- Page 1 UseR MANUAl GLENDA WIFI eNGlIsH/INGlese...
- Page 2 ENGLISH...
-
Page 3: Table Of Contents
MInIMUM DISTanCeS ........................................5 COMBUSTIOn aIr COnneCTIOn ..................................... 6 HErMEtIc INStaLLatIoN ................................ 7 COMBUSTIOn aIr ........................................... 7 FUMeS eXHaUST SYSTeM ......................................7 GLENda WIfI dEtaILS................................8 rearM ..............................................8 SpaCerS .............................................. 9 NotES for ProPEr oPEratIoN ............................9 PELLEtS aNd fEEdING ................................10 PELLEt taNk - PrESSurE cLoSING. -
Page 4: English
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner or user, or if transferred to another place. -
Page 5: Installation
InstallatIon general The flue gas exhaust and hydraulic connections must be carried out by qualified personnel who must issue installation conformity documentation compliant with national standards. The installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);... -
Page 6: Combustion Air Connection
In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: Š they must be protected with grids, metal mesh, etc., but without reducing the net useful section; Š... -
Page 7: Hermetic Installation
HermetIc InstallatIon The Glenda Wifi is a completely sealed product with respect to the installation environment, which makes it ideal for passive houses, as it does not take air from inside the homes. combustIon aIr To respect the air-tight seal of the stove, the combustion air connection pipe must be directly connected to the outside using specific sealed fittings and pipes. -
Page 8: Glenda Wifi Details
Glenda Wifi detailS Display Room air outlet Upper fumes outlet Pellet tank Spacers Ait inlet Ait inlet lateral combustion rear combustion Rearm Power supply On/OFF Lateral fumes Rear fumes outlet outlet External thermostats input Serial inputs Pellet tank Pressure closing Before starting the product, make sure it has been properly closed. -
Page 9: Spacers
SPacerS The stove features 2 spacers at the back which delimit the minimum distance to be maintained from any rear support. The spacers must not be removed. noteS for ProPer oPeration The following instructions must be observed for the proper Pellet tank lid operation of the stove: Both the pellet tank door and lid must always remain closed... -
Page 10: Pellets And Feeding
Pellets and feeding Pellets are made by applying high pressure to sawdust, or wood waste products (not containing paint) from sawmills, carpentry and other activities related to processing and working with wood. Given that it does not use any glue to hold it together this type of fuel is completely environmentally friendly. -
Page 11: Control Panel
Control panel Display OF variOUs TO aCCess BUTTON TexT messages THe meNU ON/OFF aDJUsTmeNT seTTiNg OperaTiNg pOWer TemperaTUre Display iCons key indicates the receipt of the radio signal On = during radio communication Not used Off = no radio communication Fixed on = serial input disabled it indicates fumes motor operation. -
Page 12: General Menu
General menu Go back - exit Parameter scrolling: next (2) ; previous (3) Modify settings data: increase (4); decrease (5) Confirm - access Menu User meNU pelleT % v1 air reseT seT CHrONO eNaBle CHrONO eNaBle prg1 eNaBle prg2 eNaBle prg3 eNaBle prg4 seTTiNgs seT ClOCk... -
Page 13: The Remote Control
the remote Control all that can normally be implemented through the lCD can be adjusted using the remote control. The table below provides a detailed description of the various functions: on / oFF pressing the key for three seconds, the stove will switch on or off power inCrease pressing the key will increase the operating power power DeCrease... -
Page 14: Mains Frequency 50/ 60Hz
mains FrequenCy 50/ 60hz in the event the stove is installed in a country with 60Hz frequency, the stove will display "frequenza rete errata" ("mains frequency incorrect"). vary the frequency as described below. CONTrOls prOCeDUre Š press key 6. select the frequency required using key 4 or 5. Š... -
Page 15: Operation And Logic
operation anD loGiC iGnition Once the points listed previously have been checked, press key 1 for three seconds to ignite the stove. 15 minutes are given for the ignition stage, after ignition and once the control temperature has been reached, the stove interrupts the ignition phase and switches to the sTarT- Up mode. -
Page 16: User Menu
user menu The following menu allows the user to adjust the percentage of pellet feed. if the stove has functioning problems owing to the quantity of pellets, adjust pellet feeding directly from the control board. The problems correlated to the amount of fuel can be divided into 2 categories: NO FUel: Š... -
Page 17: Set Chrono
set Chrono This stage is used to program when the generator automatically turns on and off. The factory setting for set Crono is disabled on the generator. The chrono allows the user to program 4 time spans within a day to use every day of the week. the switch-on and switch-off time can be set in every time slot, along with the days of use of the programmed time slot and the desired temperature. -
Page 18: Settings
settinGs set CloCk aDjustinG lanGuaGe Š see chapter: commissioning settings Display The "Display" menu contains two sub-menus: Š key lOCk Š BrigHTNess. key loCk The menu allows the user to lock the display keys (like with mobile phones). CONTrOls prOCeDUre Š... -
Page 19: Delta T Off
sTBy FUNCTiON seT aT OFF (DeFaUlT seTTiNg) if the stby function is not active (OFF), if the stove reaches the set room temperature, it will go to minimum, modulating and displaying modulate. When the room temperature is below the setting, it will start to work again at the set power and displaying work. Delta t oFF The function allows for the setting of DelTa T OFF. -
Page 20: Comfort Function
ComFort FunCtion This reduces the ventilation speed, favouring the silence of the stove. CONTrOls prOCeDUre To activate, press key 4 until the display shows ComFort on. Š To deactivate, press key 4 until the display shows ComFort oFF: Š when the ComFort moDe is aCtive, the Fan 1 leD will Flash on the Control panel. when the ComFort FunCtion has Been aCtivateD usinG key 4, the stove will always use reDuCeD ventilation! aDDitional thermostat (optional) -
Page 21: Wifi Remote Control Module - Total Control Application
wiFi remote Control moDule - total Control appliCation The stove is standard supplied with the WiFi remote control module. With an internet connection, it allows for remote monitoring and control of the stove via smartphone. For further information, consult the manual contained in the WiFi remote control module box. TOTal CONTROl aPPlICaTION WIFI REMOTE CONTROl MOdulE SERIAL... -
Page 22: Cleaning And Maintenance
CLeAnIng AnD mAIntenAnCe ALwAYs foLLow the InstruCtIons In mAxImum sAfetY ConDItIons! Š Make sure the power cable's plug has been pulled out, as the generator might have been programmed to turn on. Š Make sure all the parts of the generator are cold. Š... - Page 23 Open the door - Clean the glass with a damp cloth. Never spray the detergent or any other liquid used for cleaning directly on the ceramic glass. everY 3/4 DAYs - weekLY CombustIon ChAmber AnD Ash DrAwer Every 3-4 days, check and remove the ash drawer and empty it into a designated container. The ash drawer content must be emptied at least once/twice a week.
-
Page 24: Routine Maintenance Carried Out By Authorised Technicians
routIne mAIntenAnCe CArrIeD out bY AuthorIseD teChnICIAns routine maintenance must be performed at least once a year. As the generator uses pellets as solid fuel, it needs an annual routine maintenance interval that needs to be performed by an authorised technician by only using original spare parts. - Page 25 The images are for illustration purposes. Combustion chamber (total cleaning of the entire chamber) and ignition plug tube cleaning Inspection of gaskets, ash drawer and burn pot door (replace them and apply silicone where required) Room air fan disassembly and removal of dust and any pellet debris Fumes motor (disassembly and cleaning and fumes pipe), new silicone in required points Fumes box inspection opening, deposited waste complete intake.
-
Page 26: Displays
Displays Display Reason solution Stove off staRt The start phase is in progress pellet feeDing Pellet feeding during the ignition phase is in progress ignition The ignition phase is in progress staRt-up The start phase is in progress WoRk The normal work phase is in progress MoDulation The stove is modulating The automatic burn pot cleaning is in... -
Page 27: Alarms
When this message appears, contact the authorised technician to carry out the routine cleaning of the device. seRviCe If cleaning is not carried out, the message will be displayed at every ignition without, however, interrupting the normal functioning of the stove. alaRMs explanation solution... -
Page 28: Guarantee Terms
Extraflame S.p.A. cannot be held liable for injury or damage which may - either directly or indirectly - be caused to persons, animals and property ensuing from failure to observe all the instructions provided in the relevant instruction manual and the warnings regarding installation, use and maintenance of the product, that can also be downloaded on the website. - Page 29 AddITIONAL wARNINGs Š Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator. Š Do not use the product as a ladder or supporting structure. Š Do not place laundry on the product to dry it. Any clothes-horse or similar objects must be kept at due distance from the product. Danger of fire or damage to the coating.
- Page 30 ENGLISH...
- Page 31 ENGLISH...
- Page 32 +39.0445.865911 - +39.0445.865912 - info@extraflame.it - www.lanordica-extraflame.com The Manufacturer reserves the right to vary the features and data shown in this booklet at any time and without prior notice, in order to improve its products. This manual cannot be considered as a contract for third parties.
