The display shows:
The display shows:
Until the display shows:
| }
/ To select the alternative parameter.
To confirm the setting.
To return the fax machine to the initial stand-by mode.
T
O SET IT UP FOR THE TELEPHONE LINE
T
O CONNECT IT TO A PUBLIC LINE
The fax machine is set up to be connected to a public line. In
any case, it is a good idea to check that:
• The " PUBL.LINE (PSTN) " parameter is selected.
• The dialling mode ( tone or pulse ) is compatible with the
public telephone exchange that manages the line to which
you have connected the fax machine. If in doubt about the
choice to be made, ask your public telephone company.
Until the display shows:
The display shows:
The display shows:
| }
/ If the fax machine is set up for connection to the "Private line",
press the |/} keys to select connection to the "public" line.
To confirm your choice. The display shows:
| }
/ To view the other dialling mode (in countries where it is
available):
To confirm your choice.
To return the fax machine to the initial stand-by mode.
T
O CONNECT IT TO A PRIVATE LINE
To connect the fax machine to a private line and be able to
use it also on a public line, proceed as follows:
• Select the " PRIV.LINE (PBX) " parameter.
• Set the same dialling mode ( tone or pulse ) as the one
used by the private telephone exchange that manages the
line to which you have connected the fax machine. If in
doubt about the choice to be made, ask the company that
manages your private telephone network.
8
( )
PBX
• Set the output mode ( area code or flash ) to access the
public telephone network from the private telephone net-
work.
• Set the same dialling mode ( tone or pulse ) as the one
used by the public telephone exchange.
Until the display shows:
The display shows:
The display shows:
| }
/ To view the other available option:
The display shows:
| }
/ To view the other dialling mode:
To confirm your choice.
| }
/ To view the other available option, "EXT.LINE:FLASH". If
you want to confirm the output mode "EXT.LINE:PREFIX",
skip to the next step.
If you confirmed, by pressing the key
"EXT.LINE:PREFIX" mode, the fax machine prompts you
to enter the number corresponding to the area code (max.
3 digits).
The display shows:
| }
/ To view the other dialling mode:
To confirm the setting.
To return the fax machine to the initial stand-by mode.
Having confirmed the dialling mode to be used by the fax
machine to connect to the public line, simply press the
key, before dialling the correspondent's fax or telephone
number, to gain access to it. The display will show the letter
"E" (external).
Y
OU WANT TO CHANGE THE DIALLING MODE TEMPORARILY
If the fax machine is set up for pulse dialling (decadic) and you want
to change it to tone dialling (multifrequency):
Press the key, before dialling the fax or telephone number, to
change the dialing mode temporarily.
At the end of transmission, the fax machine always restores the dial-
ling mode set up on it.
