Goblin SPEED Manual page 14

Socket Head Cap
Screw M3x8mm
(HC050-S)
Bearing Support (H0142-S)
Lock H0142 after have locked
the motor.Motor shaft is requires
to optimize the centering.
H0142 can not be used with motor
shaft 8mm.
22T Pulley
(H0175-22-S)
Lock motor pulley after locking
H0142
Set Screw M4x6mm
(HC153-S)
Button Head Cap Screw
M4x8mm
(HC098-S)
Motor Support
(H0316-S)
Set Screw M5x20mm
(HC158-S)
Set Screw M4x6mm
.....x1
Button Head Cap Screw M4x8mm
.....x4
Socket Head Cap Screw M3x8mm
.....x2
Set Screw M5x20mm
.....x2
Note for 6mm motor shaft
To maximize space for the batteries, it
is advisable to shorten the motor shaft.
Follow the dimensions given in this
drawing. For the cut, you can use an
electric tool like a "Dremel" with a cut-
off disc.
Additionally, ensure the motor shaft
has an appropriate 'flat' for one of the
set screws.
Copyright © 2013 - SAB Heli Division - All rights reserved
Flanged Bearing
6x 13x5mm
(HC414-S)
Spring
HC310
(HC315-S)
Spring
HC314
(HC315-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
Bushing
6x 8x18mm
(H0176-S)
Use with 6mm
motor shaft.
Finishing Washer M3
Socket Head Cap Screw M3x10mm
Motor
Washer
7mm
6mm
Chapter 5, Transmission Assembly
Finishing Washer
M3
(H0007-S)
.....x2
.....x2
5.3x 15x1mm
.....x2
Metric Hex Nylon
Nut M5
(HC218-S)
Washer
5.3x 15x1mm
(HC188-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
Finishing
Washer M3
(H0007-S)
0.2mm
Page 12
