Goblin SPEED Manual page 11

Bearing 10x 19x5mm
Bearing 12x 24x6mm
Note:
Bearing 12x 24x6mm
Bearing 10x 19x5mm
Copyright © 2013 - SAB Heli Division - All rights reserved
Servo Support
(H0010-S)
x1
......
Socket Head Cap Screw
M3x10mm
......
Flat Head Cap Screw
M2.5x5mm
x3
......
x1
......
Bearing
10x 19x5mm
(HC422-S)
Main Structure
(H0009-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
Socket Head Cap Screw
M3x10mm
......
x1
......
Socket Head Cap Screw
M3x8mm
......
Button Head Cap Screw
M3x4mm
x1
...... ......
Bearing 12x 24x6mm
(HC426-S)
Bearing Support Assembly
(H0024-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
x4
Bearing 10x 19x5mm
(HC422-S)
x3
Bearing 12x
(HC426-S)
x1
x2
Chapter 5, Transmission Assembly
Flat Head Cap Screw
M2.5x5mm
(HC128-S)
Antenna Guide
24x6mm
(H0050-S)
Button Head Cap Screw
M3x4mm
(HC038-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
Column
(H0018-S)
Swash plate
Anti-Rotation Guide
(H0017-S)
Finishing Washer M3
(H0007-S)
Socket Head Cap
Screw M3x8mm
(HC050-S)
Page 9
