Side - Canon imageprograf IPF785 User Manual

iPF785
h Maintenance Cartridge Cover
Open this cover to replace the Maintenance Cartridge.
i Maintenance Cartridge
Absorbs ink used for maintenance purposes such as head cleaning. (Replace the cartridge when it is full.)
j Cutter Unit
A round-bladed cutter for automatic roll cutting.
k Cutter Rail
The Cutter Unit passes over this rail to cut paper.
l Output Tray
All printed documents are ejected from this slot.
m Ejection Guide
Supports output paper.
n Top Cover
Open this cover to install the Printhead and remove any jammed paper from inside the printer, as needed.
(See "Top Cover (Inside).")
o Width Guide
When loading the sheets , move the guide to match the paper size.
p Stand
A stand that holds the printer. Equipped with casters to facilitate moving it. (See "Stand.")

Side

Side

User's Guide
P.436
➔
Side
P.439
➔
