Hybrid IP-PBX
PT Programming Manual
KX-TDA50/KX-TDA100
KX-TDA200/KX-TDA600
Model
Thank you for purchasing a Panasonic Hybrid IP-PBX.
Please read this manual carefully before using this product and save this manual for future use.
KX-TDA50: PSMPR Software File Version 3.0000 or later
KX-TDA100/KX-TDA200: PMPR Software File Version 3.0000 or later
KX-TDA600: PLMPR Software File Version 3.0000 or later
Document Version: 2006-02

Advertisement

   Summary of Contents for Panasonic KX-TDA50

  • Page 1

    Thank you for purchasing a Panasonic Hybrid IP-PBX. Please read this manual carefully before using this product and save this manual for future use. KX-TDA50: PSMPR Software File Version 3.0000 or later KX-TDA100/KX-TDA200: PMPR Software File Version 3.0000 or later KX-TDA600: PLMPR Software File Version 3.0000 or later...

  • Page 2

    Introduction About this Programming Manual The PT Programming Manual is designed to serve as a reference to programming the Panasonic Hybrid IP-PBX using a Panasonic proprietary telephone (PT) with display. The PT Programming Manual is divided into the following sections: Section 1, Overview Provides an overview of programming the PBX.

  • Page 3

    Some optional service cards, PTs, and features are not available in some areas. Additionally, some optional service cards and features are not available for some PBX models. Please consult your certified Panasonic dealer for more information. • Product specifications are subject to change without notice.

  • Page 4: Table Of Contents

    Table of Contents Overview....................7 Introduction ........................8 1.1.1 Introduction ........................8 1.1.2 Password Security......................8 1.1.3 Entering Characters ......................9 PT Programming................... 11 PT Programming ......................12 2.1.1 Programming Instructions ....................12 2.1.2 Maximum Values ......................14 2.1.3 Basic Programming ......................16 [000] Date & Time............................16 [001] System Speed Dialing Number ......................

  • Page 5

    [330] ARS Routing Plan Time Table.........................24 [331–346] ARS Routing Plan Table (1–16) (KX-TDA50/KX-TDA100/KX-TDA200 only) ........24 [347] ARS Routing Plan Table (1–48) (KX-TDA600 only) ................24 [350] ARS Carrier Name ..........................24 [351] ARS Trunk Group for Carrier Access ......................24 [352] ARS Removed Number of Digits for Carrier Access ................25 [353] ARS Carrier Access Code ........................25...

  • Page 6

    [699] CS Status Reference..........................38 2.1.10 Resource/Interface Programming ..................38 [700] External Pager Floating Extension Number ................... 38 [710] Music Source Selection for BGM (with the KX-TDA50)/BGM2 (with the KX-TDA100/KX-TDA200/KX- TDA600) ................................38 [711] Music on Hold............................38 [712] Music for Transfer ........................... 39 [720] Doorphone Call Destination ........................

  • Page 7: Overview

    Section 1 Overview This section provides an overview of programming the PBX. PT Programming Manual...

  • Page 8: Introduction

    These programming instructions are designed to serve as an overall system programming reference for the Panasonic Hybrid IP-PBX. Each feature in the PBX has default settings that can be changed to customise the PBX to your requirements. These settings control the functions of the PBX, and changing them is referred to as "system programming".

  • Page 9: Entering Characters

    1.1 Introduction It is strongly recommended that passwords of 10 numbers or characters be used for maximum protection against unauthorized access. For a list of numbers and characters that can be used in system passwords, refer to Section 1.1.3 Entering Characters. If a system password is forgotten, it can be found by loading a backup of the system data into a PC, and checking the password using the KX-TDA Maintenance Console software.

  • Page 10

    1.1 Introduction Table 2 (Option mode) [Example of Entering Characters] To enter "Ann": (5 times) (5 times) FWD/DND Notes • To erase the character on the cursor, press CLEAR. • To move the cursor to the left, press • To move the cursor to the right, press .

  • Page 11: Pt Programming

    Section 2 PT Programming This section serves as reference operating instructions when using a display PT to program the PBX. PT Programming Manual...

  • Page 12: Pt Programming

    2.1 PT Programming PT Programming 2.1.1 Programming Instructions Required Telephone/Extension PBX settings can be customised through system programming by using a proprietary telephone (PT) with a multiline display, such as the KX-T7636. To access system programming, the Class of Service (COS) assigned to the PT's extension must be programmed to allow system programming, or the PT must be connected to the lowest-numbered port on the card installed in the lowest-numbered slot.

  • Page 13

    2.1 PT Programming Fixed Buttons Function T7600/IP-PT* T7200/T7400* AUTO ANS MESSAGE AUTO ANSWER MESSAGE SELECT MUTE MUTE FLASH/ FLASH FLASH RECALL TRANSFER CLEAR TRANSFER INTERCOM SECRET INTERCOM : The buttons shown in this column are from the KX-T7600 series. : The buttons shown in this column are from the KX-T7400 series. Entering System Programming Mode Using a PT to perform system programming allows an authorized extension user to set a wide range of PBX features and parameters.

  • Page 14: Maximum Values

    However, please note that extension number, slot and port entry values are not listed within each programming item. These values vary depending on the model of PBX and the card type installed, as shown below. Extension Numbers (Including Feature Numbers) • KX-TDA50/KX-TDA100/KX-TDA200: 1–4 digits • KX-TDA600: 1–5 digits PT Programming Manual...

  • Page 15

    2.1 PT Programming KX-TDA50 Slot and Port Values Available Slot Entry Values Slot Number Supported Cards Pre-installed Super Hybrid Ports 02–04 DLC4, HLC4, PLC4, LCOT4 cards 05–07 DLC8, PLC8, SLC8 cards 08–09 DPH4 cards Enter slot numbers as two-digit numbers (e.g. "04" for slot 4).

  • Page 16: Basic Programming

    2.1 PT Programming Slot Number Supported Cards 101–110 201–211 All cards 301–311 401–411 Enter slot numbers as three-digit numbers of the form "XYY": • X: Shelf number (1-4) • YY: Slot number (01-11) Available Port Entry Values Card Type Port Number Related Programming DHLC8 01–08...

  • Page 17: System Speed Dialing Number

    2.1 PT Programming [001] System Speed Dialing Number [001] Speed Dialing No. Telephone No. 000–999 Max. 32 digits ENTER ENTER To the Next Speed Dialing No. To the Desired Speed Dialing No. NEXT CANCEL [002] System Speed Dialing Name [002] Name Speed Dialing No.

  • Page 18: Operator Assignment

    ENTER ENTER 3 Break/4 Night [007] DSS Console Paired Telephone [007] DSS Console No. Extn. No. KX-TDA50: 01–04 ENTER ENTER KX-TDA100: 01–08 KX-TDA200: 01–08 KX-TDA600: 01–64 Note This program is only available after the port connected to the DSS Console is assigned as "DSS Console"...

  • Page 19: Time Service Switching Mode

    To the Next Time No. To the Next Day No. NEXT Page up [103] Idle Line Access (Local Access) [103] Location No. Trunk Group No. KX-TDA50: 01–64 KX-TDA50: 01–64 ENTER ENTER KX-TDA100: 01–64 KX-TDA100: 01–64 KX-TDA200: 01–64 KX-TDA200: 01–64 KX-TDA600: 01–96 KX-TDA600: 01–96...

  • Page 20: Manager Password

    2.1 PT Programming [112] Manager Password [112] Password 4–10 digits ENTER ENTER 1234 [120] Verification Code [120] Location No. Verification Code 0001–1000 1–4 digits ENTER ENTER [121] Verification Code Name [121] Location No. Name 0001–1000 Max. 20 characters ENTER ENTER [122] Verification Code Personal Identification Number (PIN) [122] Location No.

  • Page 21: Main Processing (mpr) Software Version Reference

    2.1 PT Programming [190] Main Processing (MPR) Software Version Reference [190] MPR Version Reference only ENTER 2.1.5 Timer Programming [200] Hold Recall Time [200] Time 0–240 s ENTER ENTER (HOLD) 60 s [201] Transfer Recall Time [201] Time 1–240 s ENTER ENTER 60 s...

  • Page 22: Call Duration Count Starting Time For Lcot

    2.1 PT Programming [208] Call Duration Count Starting Time for LCOT [208] Time 0–60 s ENTER ENTER [209] DISA Delayed Answer Time [209] Time 0–30 s ENTER ENTER [210] DISA CO-to-CO Line Call Prolong Time [210] Time 0–7 min ENTER ENTER 3 min [211] DISA Intercept Time...

  • Page 23: Trs Exception Code

    Location No. 2–6 001–100 Max. 16 digits ENTER ENTER [303] Special Carrier Access Code [303] Location No. Carrier Access Code KX-TDA50: 01–20 Max. 16 digits ENTER ENTER KX-TDA100: 01–20 KX-TDA200: 01–20 KX-TDA600: 001–100 [304] Emergency Number [304] Emergency No. Location No.

  • Page 24: Ars Routing Plan Time Table

    3 Wed/4 Thu/5 Fri/6 Sat 3 TimeC/4 TimeD KX-TDA200: 01–16 KX-TDA600: 01–48 Hour:Minute SELECT 01–12/00–59 AM/PM ENTER [331–346] ARS Routing Plan Table (1–16) (KX-TDA50/KX-TDA100/KX- TDA200 only) [331–346] Day No. Priority ARS Time No. 0 Sun/1 Mon/2 Tue/ 1 TimeA/2 TimeB/ 1–6...

  • Page 25: Ars Removed Number Of Digits For Carrier Access

    2.1 PT Programming [352] ARS Removed Number of Digits for Carrier Access [352] Digits to Remove Carrier Table No. KX-TDA50: 01–10 0–15 ENTER ENTER KX-TDA100: 01–10 KX-TDA200: 01–10 KX-TDA600: 01–48 [353] ARS Carrier Access Code [353] Carrier Table No. Carrier Access Code KX-TDA50: 01–10...

  • Page 26: Lcot Co Line Number Reference

    2.1 PT Programming [409] LCOT CO Line Number Reference [409] Slot No. Port No. CO Line No. Reference only ENTER [410] LCOT Dialing Mode [410] Slot No. Port No. SELECT DTMF/Pulse ENTER ENTER [411] LCOT Pulse Rate [411] Slot No. Port No.

  • Page 27: Lcot Flash/recall Time

    2.1 PT Programming [417] LCOT Flash/Recall Time [417] Slot No. Port No. SELECT None/80/96/112/ ENTER ENTER 300/ 600/900/ 1200 ms/option [418] LCOT Disconnect Time [418] Slot No. Port No. SELECT 0.5/ 1.5/2.0/ ENTER ENTER 4.0/12.0 s [450] DIL 1:1 Destination [450] Slot No.

  • Page 28: Trunk Group Intercept Destination

    2.1 PT Programming [470] Trunk Group Intercept Destination [470] Trunk Group No. Time No. Destination No. 1 Day/2 Lunch/ KX-TDA50: 01–64 Max. 32 digits 3 Break/4 Night KX-TDA100: 01–64 ENTER KX-TDA200: 01–64 KX-TDA600: 01–96 ENTER [471] Host PBX Access Code [471] Trunk Group No.

  • Page 29: Disa Continuous Signal Detection

    2.1 PT Programming [476] DISA Continuous Signal Detection [476] Trunk Group No. SELECT KX-TDA50: 01–64 No Detect/ ENTER ENTER KX-TDA100: 01–64 Detect KX-TDA200: 01–64 KX-TDA600: 01–96 [477] DISA Cyclic Signal Detection [477] Trunk Group No. SELECT KX-TDA50: 01–64 No Detect/...

  • Page 30: Co Line Call Duration Limitation

    2.1 PT Programming [502] CO Line Call Duration Limitation [502] COS No. SELECT 01–64 Disable/ ENTER ENTER Enable [503] Call Transfer to CO Line [503] COS No. SELECT 01–64 Disable/ ENTER ENTER Enable [504] Call Forwarding to CO Line [504] COS No.

  • Page 31: Trs Level For System Speed Dialing

    2.1 PT Programming [509] TRS Level for System Speed Dialing [509] COS No. TRS Level 01–64 1–7 ENTER ENTER [510] TRS Level for Extension Dial Lock [510] COS No. TRS Level 01–64 1–7 ENTER ENTER [511] Manager Assignment [511] COS No. SELECT Disable/Enable 01–64...

  • Page 32: Extension Programming

    [602] Extn. No. COS No. 01–64 ENTER ENTER [603] Extension User Group [603] Extn. No. Extn. User Group No. KX-TDA50: 001–032 ENTER ENTER KX-TDA100: 001–032 KX-TDA200: 001–032 KX-TDA600: 001–096 [604] Extension Intercept Destination [604] Time No. Destination No. Extn. No.

  • Page 33: Call Forwarding-no Answer Time

    Max. 16 digits ENTER ENTER [620] Incoming Call Distribution Group Member Incoming Call [620] Location No. Extn. No. Distribution KX-TDA50: 01–32 Group No. ENTER KX-TDA100: 01–32 KX-TDA200: 01–32 001–128 KX-TDA600: 001–128 ENTER [621] Incoming Call Distribution Group Delayed Ringing Incoming Call [621] Location No.

  • Page 34: Incoming Call Distribution Group Distribution Method

    2.1 PT Programming [624] Incoming Call Distribution Group Distribution Method Incoming Call [624] SELECT Distribution Ring/UCD/ ENTER ENTER Group No. Priority Hunt 001–128 [625] Destination for Overflow Time Expiration Incoming Call [625] Destination No. Time No. Distribution Max. 32 digits 1 Day/2 Lunch/ Group No.

  • Page 35: Queuing Hurry-up Level

    KX-TDA100: 001–032 KX-TDA200: 01–32 KX-TDA200: 001–032 KX-TDA600: 01–96 KX-TDA600: 001–096 SELECT No/Yes ENTER KX-TDA50/KX-TDA100/KX-TDA200: Paging Group No. 01–31=Extn. User Group No. 001–031, Paging Group No. 32=All extension user groups KX-TDA600: Paging Group No.= Extn. User Group No. PT Programming Manual...

  • Page 36: External Pagers Of A Paging Group

    KX-TDA600: 01–96 KX-TDA600: 001–096 SELECT No/Yes ENTER KX-TDA50/100/200: Pickup Group No. 01–32=Extn. User Group No. 001–032, Pickup Group No. 33–64=All extension user groups KX-TDA600: Pickup Group No.=Extn. User Group No. [660] VM Group Floating Extension Number [660] VM (DPT) Group No.

  • Page 37: Idle Extension Hunting Group Member

    2.1 PT Programming [681] Idle Extension Hunting Group Member [681] Hunting Group No. Location No. 01–16 KX-TDA50: 01–64 ENTER KX-TDA100: 01–64 KX-TDA200: 01–64 KX-TDA600: 001–128 Extn. No. ENTER [690] PS Registration [690] PS No. Extn. No. To the PS operation...

  • Page 38: Personal Identification Number (pin) For Ps Registration

    To the Desired Pager No. NEXT CANCEL [KX-TDA50] [700] Pager No. Extn. No. (HOLD) ENTER ENTER [710] Music Source Selection for BGM (with the KX-TDA50)/BGM2 (with the KX-TDA100/KX-TDA200/KX-TDA600) [710] SELECT (AUTO ANS/ MESSAGE) ENTER ENTER External/ Internal1/ Internal2 [711] Music on Hold [711] Music Source No.

  • Page 39: Music For Transfer

    Doorphone No. Slot No. Port No. Reference only 1–4 ENTER [730] Outgoing Message (OGM) Floating Extension Number [730] Message No. Extn. No. KX-TDA50: 01–32 KX-TDA50: 501–532 ENTER ENTER KX-TDA100: 01–64 KX-TDA100: 501–564 KX-TDA200: 01–64 KX-TDA200: 501–564 KX-TDA600: 01–64 KX-TDA600: 501–564...

  • Page 40: Outgoing Message (ogm) Name

    2.1 PT Programming [731] Outgoing Message (OGM) Name [731] Message No. Name KX-TDA50: 01–32 Max. 20 characters ENTER ENTER KX-TDA100: 01–64 KX-TDA200: 01–64 KX-TDA600: 01–64 [732] DISA Security Mode [732] SELECT None/ CO Line/All ENTER ENTER 2.1.11 SMDR & Maintenance Programming [800] RS-232C Parameter—New Line Code...

  • Page 41: External Modem Control

    2.1 PT Programming [801] External Modem Control [801] Command No. 1–5 ENTER ENTER [802] SMDR Page Length [802] Page length 4–99 lines ENTER ENTER [803] SMDR Skip Perforation [803] Skip Perforation 0–95 lines ENTER ENTER [804] SMDR Outgoing Call Printing [804] SELECT No print/...

  • Page 42: Isdn Remote Floating Extension Number (kx-tda100/kx-tda200/kx-tda600 Only)

    2.1 PT Programming [812] ISDN Remote Floating Extension Number (KX-TDA100/KX-TDA200/ KX-TDA600 only) [812] Extn. No. ENTER ENTER 2.1.12 Card Programming [900] Slot Card Type Reference [900] Slot No. Card Name Reference only (HOLD) ENTER [901] Slot Card Deletion [901] Slot No. Delete Confirming the ENTER...

  • Page 43: Opb3 Option Card Deletion (kx-tda100/kx-tda200/kx-tda600 Only)

    2.1 PT Programming [911] OPB3 Option Card Deletion (KX-TDA100/KX-TDA200/KX-TDA600 only) [911] Slot No. Card No. Delete Confirming the 1–3 ENTER ENTER deleting operation. PT Programming Manual...

  • Page 44

    2.1 PT Programming PT Programming Manual...

  • Page 45: Appendix

    Section 3 Appendix PT Programming Manual...

  • Page 46: Feature Programming References

    [322] ARS Routing Plan Table Number • [325] ARS Exception Number • [330] ARS Routing Plan Time Table • [331–346] ARS Routing Plan Table (1–16) (KX-TDA50/KX-TDA100/KX-TDA200 only) • [347] ARS Routing Plan Table (1–48) (KX-TDA600 only) • [350] ARS Carrier Name •...

  • Page 47

    3.1 Feature Programming References Feature Manual Reference 1.3.8 Call Transfer Caller ID • [001] System Speed Dialing Number • [002] System Speed Dialing Name • [490] Caller ID Signal Type Feature Manual Reference 1.3.1 Caller ID CLI (Calling Line Identification) Distribution •...

  • Page 48

    3.1 Feature Programming References Feature Manual Reference 1.3.15 CO Line Call Limitation Dial Mode Selection • [410] LCOT Dialing Mode • [411] LCOT Pulse Rate • [412] LCOT DTMF Minimum Duration Feature Manual Reference 1.4.2 Dial Mode Selection DID (Direct Inward Dialing) •...

  • Page 49

    3.1 Feature Programming References Door Open • [207] Door Open Duration • [512] Permission for Door Open Access Feature Manual Reference 1.4.10 Door Open Doorphone Call • [720] Doorphone Call Destination • [729] Doorphone Number Reference Feature Manual Reference 1.4.11 Doorphone Call EFA (External Feature Access) •...

  • Page 50

    3.1 Feature Programming References Flash/Recall/Terminate • [418] LCOT Disconnect Time Feature Manual Reference 1.6.2 Flash/Recall/Terminate Flexible Numbering/Fixed Numbering • [100] Flexible Numbering Feature Manual Reference 1.6.4 Flexible Numbering/Fixed Numbering Floating Extension • [623] Incoming Call Distribution Group Name • [660] VM Group Floating Extension Number •...

  • Page 51

    3.1 Feature Programming References ICD Group Features • [620] Incoming Call Distribution Group Member • [621] Incoming Call Distribution Group Delayed Ringing • [622] Incoming Call Distribution Group Floating Extension Number • [623] Incoming Call Distribution Group Name • [624] Incoming Call Distribution Group Distribution Method •...

  • Page 52

    3.1 Feature Programming References ICD Group Features—Queuing • [628] Queuing Call Capacity • [629] Queuing Hurry-up Level • [630] Queuing Time Table • [631] Sequences in Queuing Time Table • [632] Maximum Number of Agents Feature Manual Reference 1.9.6 ICD Group Features—Queuing Idle Extension Hunting •...

  • Page 53

    • [511] Manager Assignment Feature Manual Reference 1.11.1 Manager Features Music on Hold • [710] Music Source Selection for BGM (with the KX-TDA50)/BGM2 (with the KX-TDA100/ KX-TDA200/KX-TDA600) • [711] Music on Hold Feature Manual Reference 1.11.4 Music on Hold OGM (Outgoing Message) •...

  • Page 54

    3.1 Feature Programming References PC Console/PC Phone • [601] Terminal Device Assignment Feature Manual Reference 1.13.5 PC Console/PC Phone Private Network Features • [453] DID Destination (KX-TDA100/KX-TDA200/KX-TDA600 only) • [500] Trunk Group Number Feature Manual Reference 1.13.12 PRIVATE NETWORK FEATURES Private Network Features—NDSS (Network Direct Station Selection) •...

  • Page 55

    3.1 Feature Programming References PS Ring Group • [620] Incoming Call Distribution Group Member Feature Manual Reference 1.13.26 PS Ring Group PT Programming • 2.1 PT Programming • [516] Programming Mode Limitation Feature Manual Reference 1.13.27 PT Programming Redial, Last Number •...

  • Page 56

    3.1 Feature Programming References TAFAS (Trunk Answer From Any Station) • [700] External Pager Floating Extension Number Feature Manual Reference 1.17.2 TAFAS (Trunk Answer From Any Station) Tenant Service • [001] System Speed Dialing Number • [006] Operator Assignment • [320] ARS Mode •...

  • Page 57

    3.1 Feature Programming References • [123] Verification Code COS Number Feature Manual Reference 1.19.1 Verification Code Entry Virtual PS • [690] PS Registration Feature Manual Reference 1.19.2 Virtual PS Voice Mail (VM) Group • [601] Terminal Device Assignment • [660] VM Group Floating Extension Number Feature Manual Reference 1.19.3 Voice Mail (VM) Group Voice Mail DPT (Digital) Integration...

  • Page 58

    Copyright: This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd. © 2006 Panasonic Communications Co., Ltd. All Rights Reserved.
