Ozito DSL-4000 Instruction Manual

Ozito DSL-4000 Instruction Manual

Cordless detail sander
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
CORDLESS
DETAIL
SANDER
12V Li-ion
INSTRUCTION MANUAL
SPECIFICATIONS
Input:
12V
No Load Speed:
10,000/min
Pad Size:
140 x 140 x 100mm
Paper Fitment:
Hook & Loop
Battery:
1.3Ah Li-ion
Charge time:
3 - 5 hours
Weight with Battery:
0.72kg
ozito.com.au
WHAT'S IN THE BOX
Cordless Detail Sander
Sand Paper x 3
Charging Cradle
Charging Adaptor
DSL-4000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSL-4000 and is the answer not in the manual?

Questions and answers

Related Manuals for Ozito DSL-4000

Summary of Contents for Ozito DSL-4000

  • Page 1 Sand Paper x 3 INSTRUCTION MANUAL SPECIFICATIONS Input: No Load Speed: 10,000/min Pad Size: 140 x 140 x 100mm Paper Fitment: Hook & Loop Charging Cradle Battery: 1.3Ah Li-ion Charge time: 3 - 5 hours Weight with Battery: 0.72kg ozito.com.au Charging Adaptor DSL-4000...

  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS DETAIL SANDER 1. BATTERY 1 On/Off Switch 5 Battery Release Button This charger is recommended for use with a residual current 2 Charge Check 6 12V Li-ion Battery device with a rated residual current of 30mA or less. 3 Sanding Pad 7 Dust Canister Charging...

  • Page 3: Operation

    OPERATION 2. ASSEMBLY 3. CONTROLS On / Off Switch Attaching Sandpaper 1. To turn on, press the on/off switch. To turn off, press the on/off 1. Align the sanding sheet with the sanding pad and press on. switch again. Note: Ensure the sander is turned off before removing the battery.
  • Page 4 The orbital action of your sander allows you to sand with the grain, 4. For optimum results, use either of these strokes. or at any angle across it for most sanding jobs. In the final stages a better finish will be achieved by sanding with the grain. Do not sand on one spot for too long. The sander’s rapid action may remove too much material, creating an uneven surface. Side to Side Backward/ Forward DSL-4000...

  • Page 5: Maintenance

    Ensure the battery is properly charged. It will take 4-5 charging cycles before the battery reaches optimum charge and run time. On the initial Note: Ozito Industries will not be responsible for any damage or charge, the battery requires 5 hours of charging. Subsequent charging injuries caused by repair of the detail sander by an unauthorised only requires 3-5 hours.
  • Page 6 Tool: 12V Detail Sander SPARE PARTS Model No. DSL-4000 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. 12V Lithium-Ion Battery...

  • Page 7: Electrical Safety

    Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock.

  • Page 8: Warranty

    • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 1113...
