- Page 1 WHAT’S IN THE BOX BELT SANDER Belt Sander 850W INSTRUCTION MANUAL SPECIFICATIONS Sanding Belt Input: 230-240V ~ 50Hz Power: 850W Belt Speed: 300-400m/min Belt Surface: 75 x 140mm Belt Size: 75 x 533mm Weight: 3.1kg ozito.com.au BSV-9000...
-
Page 2: Setup & Preparation
KNOW YOUR PRODUCT SETUP & PREPARATION BELT SANDER 1. DUST CANISTER 1 Adjustable Front Handle 5 ON/OFF Trigger (not shown) 2 Belt Tracking Knob 6 Lock-on Switch (not shown) Ensure the tool is disconnected from the power supply before performing any of the following operations. 3 Sanding Guard Release 7 Dust Canister Button... -
Page 3: Operation
OPERATION 2. SANDING BELT 3. BELT ADJUSTMENT Install Tracking Adjustment When installing a belt, ensure you have the correct size for your CAUTION: Ensure body parts, cords, workpieces and any belt sander, and correct grit for your workpiece. Belts have arrows loose items are clear of the sanding belt before performing marked on them to assist in fitting them to the belt sander in the the tracking adjustment operation... - Page 4 5. Use a back and forth motion. Do not apply pressure on the Variable Speed Dial sander. Allow the sander to do the work. 1. Rotate the dial clockwise to select a higher speed or anti-clockwise to lower the speed. Align the number with the marker on the tool housing. BSV-9000...
-
Page 5: Maintenance
Always replace both carbon brushes at the same time. Note: Ozito Industries will not be responsible for any damage or injuries caused MATERIAL APPROPRIATE GRIT... -
Page 6: Electrical Safety
Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock. -
Page 7: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 1214...
