Sun Fire X4600/X4600 M2 Server Back Panel Features and Components
Figure Legend
1
Locate button/LED (white)
2
Service action required LED
(amber)
3
Power/OK LED (green)
4
Power button
5
Top fan fault LED
6
Rear power supply fault LED
Sun Fire X4600/X4600 M2 Server Back Panel Features and
Components
For front panel features and components, see
Features and Components" on page
12
Sun Fire X4600 and Sun Fire X4600 M2 Servers Installation Guide • January 2010, Rev. A
7
System overheat fault LED
8
Hard drive status LEDs
9
USB ports (2)
10 DVD module
11 Hard drives (4 maximum)
"Sun Fire X4600/X4600 M2 Server Front Panel
11.
