4. AX-250/500PLUS
4-1. TERMINAL
Receiver
Wiring Distance
When using two or more units on one wire, the maximum length is obtained by dividing the wire length listed below by the
number of units used.
Power wires should not exceed the following length.
MODEL
WIRE SIZE
2
AWG22 (0.33mm
)
2
AWG20 (0.52mm
)
2
AWG18 (0.83mm
)
2
AWG16 (1.31mm
)
UL requires AX-250PLUS/500PLUS to be connected to a UL listed power supply capable of providing a
norminal input of 12VDC, (10.5~30VDC) 50mA and battery standby time of 4 hours.
4-2. WIRING
1 Set
AX-250/500PLUS
12V DC
1300' (400m)
2000' (600m)
3300' (1000m)
5000' (1500m)
Transmitter
24V DC
7500' (2300m)
12000' (3600m)
19000' (5800m)
30000' (9200m)
2 Set in the line
4
Do not exceed the voltage
or current rating specifi ed
for any of the terminals
during installation,
doing so might cause fi re
WARNING
or damage to the devices.
