- Page 1 ME-163 OPERATING MANUAL...
-
Page 2: Safety Precautions And Warnings
WARNING WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury. This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense and enquires some basic mechanical ability. - Page 3 Installing the main wing 1. Install the rocker. 2.1. Apply glue on the combined side 2.2. Apply glue on the combined side of the main wing of the fuselage 3. Install the main wing...
-
Page 4: Installing The Rudder
Installing the rudder 2.1. Apply glue on the combined side 1. Install the rocker. of the main wing 2.2. Apply glue on the combined side 3. Install the rudder of the fuselage... -
Page 5: Installing The Propeller
Installing the propeller 2. Install the 1. Install the propeller 4. Install the propeller cover 3.Locking the propeller. 5.Locking the propeller cover. -
Page 6: Installing The Canopy
Installing the canopy 1. Battery position. 2. Connect power battery, adjust the elevator and rudder. 3. Apply glue on the combined side 4. Install the antenna of the antenna 6.When the plane takes off, the aircraft 5. Install the canopy should be horizontal throwed, and ailerons on both sides to pull up. -
Page 7: Main Specification
Main specification Specification Wingspan : 900mm /35.4 in Length : 600mm /23.6 in Weight : 770-800g /27.2-28.2 oz CG Position : 57mm Battery : 4S 2200mA 30C-50C Li-Po Battery when the voltage lower than 2.9V,the motor will be high to low speed cyclic : 80A 2-3 times,remind that into half speed status,it is normal function Motor... -
Page 8: Spare Parts List
Spare Parts List Fuselage Main Wing Set Rudder Canopy Propeller Glue Spinner 9g Servo Sticker Brushless ESC Brushless Motor... -
Page 9: Troubleshooting
Trouble shooting Problem Possible Cause Solution Aircraft will not Lower throttle stick and throttle ESC is not armed. respond to the trim to lowest settings. Throttle channel is reversed. throttle but responds Reverse throttle channel on to other controls. transmitter. Extra propeller nosie Damaged spinner, propeller. -
Page 10: Flying Tips
14. 4. Never leave the charger in wet conditions. 5. The ME-163 is made from PA and polythene which are tinder. When it meets the heat, transfiguration can easily happen, so you must keep it away from heat.
