AIRCRAFT SPECIFICATIONS
Wing Span: 1121.5mm/44.15"
Wing Area: 30.12 Sq dm/ 466.9 Sq in
Length: 900mm/35.43in
Weight: 850g RTF less battery
RECOMMENDED EQUIPMENT
Motor: 2220/10
Radio: 3channels, 2 servos
Battery: 3S 2200mAh
ESC: 40A
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is
not familiar with this kind of electric powered precision model.
Operating this model without prior preparation may cause in juries.
Remember, safety is the most important thing. Always keep this
instruction manual at hand for quick reference.
：
：
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HobbyKing Mariposa Trainer
Summary of Contents for HobbyKing Mariposa Trainer
- Page 1 ： AIRCRAFT SPECIFICATIONS Wing Span: 1121.5mm/44.15" Wing Area: 30.12 Sq dm/ 466.9 Sq in Length: 900mm/35.43in Weight: 850g RTF less battery ： RECOMMENDED EQUIPMENT Motor: 2220/10 Radio: 3channels, 2 servos Battery: 3S 2200mAh ESC: 40A Warning! This model is not a toy. It is designed for maximum performance.
- Page 2 1.Stabilizer/Vertical/Tail Wheel Stabilizer/Vertical/Tail Wheel Cut covering for control horn slot Remove covering for vertical fin Cut covering at servo mount Glue the vertical fin with CA glue Glue control horn to rudder with CA glue...
- Page 3 Install rudder servo, secure with Attach rudder control rod with supplied screws hardware Assemble tail skid parts with CA glue Attach to stabilizer with supplied hardware Install elevator servo, secure with Glue control horn to elevator with CA glue screws...
-
Page 4: Wing Assembly
Attach elevator control rod with supplied hardware 2.Wing assembly Wing Parts Glue short fiberglass wing pins into center wing panel with CA glue Install plywood wing joiner with CA or Attach outer wing panels to center section Epoxy. Dry fit first to make sure spar fits using epoxy glue correctly... - Page 5 Insert wing dowels to fuselage, secure Attach wing to fuselage with rubber bands with CA glue 3. Main Landing Wheel Main Landing Gear Secure tires to landing gear with wheel collars. One inside, one outside Insert wire gear into fuselage. Hold in place with plywood spacer.
- Page 6 Check wing, and tail distances to make sure all parts are installed straight and even...
