Summary of Contents for Dinstar UC100
- Page 1 UC100 User Manual v1.0 Dinstar Technologies Co., Ltd. Address: 9 Floor, Guoxing Building, Changxing Road, Nanshan District, Shenzhen, China Postal Code: 518052 Telephone: +86 755 61919966 Fax: +86 755 2645 6659 Emails: sales@dinstar.com, support@dinstar.com Website: www.dinstar.com, www.dinstar.cn Revision Records...
- Page 2 Document Name UC100 User Manual v1.0 Document version V1.0 Firmware version 2.53.0.24 Ivanka Y uan Revised by Date 2014.5.19 Table of Contents...
-
Page 3: Table Of Contents
1 Product Description......................1 1.1 Overview..........................1 1.2 Application Scenario ......................1 1.3 Product Appearance ......................2 1.3.1 Images of UC100................................2 1.3.2 Description of Ind icators ............................... 2 1.4 Features & Functions......................3 1.4.1 Key Features..................................3 1.4.2 So ftware Features ................................3 1.4.3 V o ice Capabilit ies ................................ - Page 4 4.1.2 Log in Web Interface..............................13 4.2 Configuration Wizard ......................14 4.2.1 UC100 regarded as Terminal and Registered to SIP Server .................. 14 4.2.2 FXS/ FXO Port Registered to SIP Server........................15 4.2.3 Other SIP Clients registered to UC100 ........................15 4.2.4 UC100 Connected to PBX through Trunking......................
- Page 5 4.6.4 Nu mber................................... 40 4.6.5 Time ....................................41 4.6.6 Manipulat ion ................................. 41 4.6.7 Dialplan ..................................42 4.7 Extension ..........................44 4.7.1 SIP Extension ................................44 4.7.2 FXS ....................................45 4.7.3 Ring Group ..................................46 4.8 Trunk ..........................47 4.8.1 SIP Trunk ..................................47 4.8.2 FXO Trunk..................................
-
Page 6: Product Description
WiFi and has high-speed data-handling capacity, allowing users to enjoy high-speed internet surfing through WiFi or the LAN port. With VPN transparent transfer function, UC100 is ideally suitable for personal use. Meanwhile, it is perfect for small and micro enterprises, providing high-speed internet access, good voice service as well as message service. -
Page 7: Product Appearance
1.3 Product Appearance 1.3.1 Images of UC100 Front View Back View 1.3.2 Description of Indicators Indicator Status Description Flash slowly The system is initialized successfully and is in normal running. On green The system is being initialized. On dull There is no power supply or power supply is abnormal. -
Page 8: Features & Functions
1.4.2 Software Features Ring Group Routing Groups Caller/Called Number Manipulation Routing Base on Time Period Routing Base on Caller/Called Prefixes Routing Base on Source Trunks Dial Rules UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 9: O Ice Capabilit Ies
Call Holding No Disturbing Hotline 1.4.5 Physical Interfaces FXO Port: 1 FXS Port: 1 SIM Slot: 1 Ethernet Interfaces：1WAN&1LAN 10/100 Base-T RJ45 WIFI：2.4GHz , 802.11n UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 10: Fxs
Power Consumption: 10W Operating Temperature. 0 ℃ ~ 45 ℃ Storage Temperature: -20 ℃ ~80 ℃ Humidity: 10%-90%, Non-Condensing Dimensions (W/D/H): 126× 75× 25mm Unit Weight: 0.7kg UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 11: Quick Installation
The precautions for installing UC100 include: The adapter of UC100 accepts AC input voltage of 110- 220 V and converts it to 12V DC； Please ensure stable and safe power supply; Network interface should be standard RJ45 with 10Mbps or 100Mbps;... -
Page 12: Network Connection
LAN port is a static IP address, namely 192.168.11.1. Note: The IP address of LAN port of UC100 and the IP address of PC are at the same network segment, while the IP address of WAN port is at a different network segment. - Page 13 Note: The IP address of PC and the IP address of WAN port of UC100 are at the same network segment. For more details about installation, please make reference to Quick Installation Guide. UC100 User M anual Copyright @ 2011-2015 Dinstar...
-
Page 14: Basic Operation
(the transferring party will not hear any ringback). Example: A and B are in conversation and B wants to transfer the conversation to C (the extension of C is 8000). Operation instructions are as follows: UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 15: Attended Transfer
Dial *157*0 to set route mode; dial *157*1 to set bride mode *150* Dial *150*1 to set IP address as static IP address; dial *150*2 to set IP address as DHCP IP address *152* Dial *152*192*168*1*10# to set IPv4 address as 192.168.1.10 UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 16: Send Or Receive Fax
*153* Dial *153*255*255*0*0*# to set IPv4 netmask as 255.255.0.0 *111 Dial *111 to restart the UC100 device Dial *51 to enable the call waiting service Dial *50 to disable the call waiting service Example: Dial *18000, and you can blind transfer to the extension number 8000... -
Page 17: Restore Default Ip And Password
3.8 Restore Default Setting If you want to restore UC100 to default settings, you can press the RST button of UC100 for more than 6 seconds or you can configure it on the Web interface. Click System Backup/Restore/Upgrade on the Web of UC100, and select the parts (system, network or network) that need to be restored to defaults, click Reset, restart the UC100 device, and the selected parts will be restored to defaults. -
Page 18: Configurations On Web Interface
Switch 4.1.1 Preparations for Login Modify the IP address of the PC to make it at the same network segment with the UC100 device, since the default IP address of the UC100 device is 192.168.11.1. Check the connectivity between the PC and the UC100. Click Start Run of PC and enter cmd to execute ‘ping 192.168.11.1’... -
Page 19: Configuration Wizard
Detailed interface The detailed configuration interface or display interface 4.2 Configuration Wizard The following are the common ways to configure the UC100 device. 4.2.1 UC100 regarded as Terminal and Registered to SIP Server Add an SIP Trunk to SIP Server... -
Page 20: Fxs/Fxo Port Registered To Sip Server
4.2.3 Other SIP Clients registered to UC100 Under this mode, UC100 is regarded as an SIP Server. Create an extension account first on the Extension SIP interface of UC100, and configure listening port on the Profile SIP interface. Then, configure the UC IP address, extension account and listening port on SIP Clients. -
Page 21: Status
4.3 Status 4.3.1 Overview Log in the Web interface of UC100, click Status Overview, and the following interface will be displayed. On the interface, information about the system, performance, WAN network, LAN network, WiFi and DHCP server is shown. -
Page 22: Pstn
Click Status PSTN, and the following interface will be displayed. On the interface, information of FXS port, FXO port and GSM port is shown. Green color means available or registered, while red color means abnormal, unregistered or prohibited. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 23: Current Call
Click Status Current Call, and the following interface will be displayed. On the interface, the source, destination, calling number, called number, start time, answer time, state and duration of the current real- time call are shown. If there is no current call, no information will be shown. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 24: Cdrs
4.3.6 Service Click Status Service, and the service status of UC100 is displayed. The function is enabled by default. The Web, SSH and Telnet service can be disabled and their ports can be modified on the System Access Control interface. -
Page 25: About
Configurations for language, time zone, NTP, login password, access control, provision, operation log, service log, upgrade, backup, restore, automatch impedance, IVR upload and device reboot can be carried out in the System section. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 26: Setting
The name of the gateway. After it is configured, the name will be displayed on the left of the menu bar. Language Auto: the language of UC100 will be automatically adjusted into the language of the web browser. Auto is the default value. English: the language of UC100 is English. -
Page 27: User Manager
Click System User Manager, and you can modify the username name and password for logging in the UC100 device. Factory defaults for username name and password are both admin, so it is advised that you should modify them for security consideration. -
Page 28: Operation Log
The logs tracing the operations carried out on the Web can be queried on the System Operation Log interface. You are allowed to set query criteria to query the logs that you want and to export the logs through clicking the Export button at the top-right corner. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 29: Service Log
On the System Backup/Restore/Upgrade interface, you can back up or restore configuration data, and can upgrade UC100 to a new version. But you need to restart the device for the change to take effect after executing restore or upgrade. -
Page 30: Automatch Impedance
How to use automatch impedance: 1. Connect a telephone cable to the FXO port; 2. Click Detection, and the UC100 device will automatically detect the optimum impedance (It takes a period of time to carry out the detection). 3. Save the optimum impedance. -
Page 31: Reboot
4.5 Network UC100 works in two modes: route mode and bridge mode. When it is under the route mode, the IP of WAN must be different from the IP of LAN. But when it is under the bridge mode, the IP of WAN and the IP of LAN are the same. - Page 32 If you choose static IP address, you need to fill in the following information: IP Address: the IP address of the WAN port of the UC100 ; Netmask: the netmask of the router connected the UC100;...
-
Page 33: Access Control
The access ports of Web, Telnet and SSH, as well as relevant on-off controls, can be configured on the Access Control interface. Web supports http and https, while SSH supports OAuth 2.0 protocol. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 34: Firewall
4.5.3 Firewall If the UC100 works under the route mode, you can choose to enable the firewall and set filter rules to accept or reject certain destination IP addresses. Configuration Procedures: 1. Select On in the drop-down box on the right of Filter Rules Control 2. - Page 35 4. Fill in relevant information in the following interface. Parameter Explanation LAN IP The IP address of LAN port that you want UC100 to accept or reject LAN Port The LAN port which the accepted or rejected IP address belongs to LAN Mac...
-
Page 36: Dhcp Server Setting
4.5.4 DHCP Server Setting If there is a need, you can choose to enable the built-in DHCP server of UC100 to assign IP addresses to PC or other clients that are in the same local-area network with UC100. Parameter Explanation... -
Page 37: Port Mapping
4.5.6 Port Mapping IF the UC100 works under the route mode, port mapping allows a client in the wide-area network to visit a client in the local-area network. Configuration Procedures: 1. Click Network Port Mapping, and the following interface will be shown. -
Page 38: Dmz Setting
4. Click the Save button. 4.5.7 DMZ Setting If the UC100 works under the route mode and the DMZ service is enabled, the clients in the wide-area network are allowed to have direct access to the clients in the DMZ (demilitarized zone). -
Page 39: Profile
On the Profile SIP interface, you can set SIP information such as listening port, which will be used in FXO/FXS, extension and SIP trunk. Multiple SIP profiles can be configured for one UC100 device, so you can choose different SIP profiles according to different needs. - Page 40 Provisional Response ACKnowledgement Session Timeout The validity period of current registration. It is 1800 seconds by default Inbound Codec To take the remote device or the local device as priority for inbound codec UC100 User M anual Copyright @ 2011-2015 Dinstar...
-
Page 41: Fxs/Fxo
G.723 and G.729 and G.723 is prior to G.729. 4.6.2 FXS/FXO On the Profile FXS/FXO interface, you can configure the driving parameters of FXS port and the FXO port. Profile FXS Interface: UC100 User M anual Copyright @ 2011-2015 Dinstar... - Page 42 If polarity reverse is off, you need to set the time to delay offhook and call tolls will be calculated starting from the preset time. Dialplan The rules for dialing UC100 User M anual Copyright @ 2011-2015 Dinstar...
- Page 43 Tone Group The state standard of dialing tone, busyness tone and ring tone; the default value is China Digit Timeout (s) The timeout value for dialing a digit of a telephone number UC100 User M anual Copyright @ 2011-2015 Dinstar...
-
Page 44: Codec
Detect caller ID after ringing or detect caller ID before ringing Dialplan The rules for dialing 4.6.3 Codec UC100 supports four codec modes, including G711A, G711u, G729 and G92. You can adjust the priority of these four modes according to you needs. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 45: Number
：4|6|7 The length of the calling number or called number. For example, Length means the calling number or called number must be 4 digits, 6 digits or 7 digits except the prefix. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 46: Time
Choose start and end time 4.6.6 Manipulation Number manipulation refers to the change of a called number or a caller number during calling process when the called number or the caller number matches the preset rules. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 47: Dialplan
Note: During number manipulation, deletion rules are carried out first, followed by adding rules. If ‘Replace by’ has been set, deletion rules and adding rules are invalid. 4.6.7 Dialplan Dialplan is used for the dialing of calls through FXS and FXO ports. Regex (Regular Expression) Syntax UC100 User M anual Copyright @ 2011-2015 Dinstar... - Page 48 One or more DTMF symbols enclosed in the [], but only one DTMF symbol can be selected. Range One or more expressions enclosed the (), but only one can be selected. Separator Separated expressions or DTMF symbols. UC100 User M anual Copyright @ 2011-2015 Dinstar...
-
Page 49: Extension
Matches the phone numbers with stating digits as 13, 15 or 18 and the left nine digits as any of 0 to 9. 4.7 Extension 4.7.1 SIP Extension On the Extension SIP interface, you can configure the SIP accounts registered in the UC100 by SIP clients. Parameter Explanation... -
Page 50: Fxs
If it is enabled, the SIP account can be registered; Otherwise the SIP account cannot be registered. 4.7.2 FXS On the Extension FXS interface, you can configure data for extensions of the FXS port. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 51: Ring Group
On the Ring Group interface, you can group FXS extension and SIP extension(s) together and set strategy for choosing the FXS extension and which SIP extension to ring under a ring group. The ring group function is widely used in call centers. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 52: Trunk
Note: If ring group function has been set, the call forwarding function is unavailable. 4.8 Trunk 4.8.1 SIP Trunk SIP trunk can realize the connection between UC100 and IPPBX or SIP servers. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 53: Fxo Trunk
If it is enabled, it means the SIP Trunk is available; otherwise, the SIP trunk is unavailable. Note: If UC100 is regarded as a terminal and registered to SIP server, and you want to register the UC100, you just need to register the corresponding SIP trunk. -
Page 54: Gsm Trunk
4.8.3 GSM Trunk GSM trunk interconnects the GSM wireless network with UC100. Calls from the GSM wireless network can come into UC100 and calls can go out from UC100 to search mobile numbers under the GSM wireless UC100 User M anual... -
Page 55: Call Control
Pin Code The Pin code of SIM card 4.9 Call Control This section is to configure the routes and trunks for incoming and outgoing calls through UC100, as well as IVR, SMS, fax and call-related security. UC100 User M anual... -
Page 56: Setting
RTP Start Port The start port of RTP packets RTP End Port The end port of RTP packets Local extension call If it is enabled, calls between local extensions do not need routes. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 57: Route Group
T38 or T30（Pass-through） Fax Mode Tone Detection by Local If it is enabled, UC100 will detect fax tones automatically during a call and the call will be switched into fax mode after a fax tone is detected. SDP Param ‘a=X-fax’... - Page 58 UC100 User M anual Copyright @ 2011-2015 Dinstar...
-
Page 59: Feature Code
If busy or timeout is selected, only the failed calls due to busyness or timeout will be processed. If both are not selected, all failed calls will be processed The code of other conditions; please separate codes with ‘,’ Other Condition Code 4.9.4 Feature Code UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 60: Ivr
Note: All feature codes are enabled by default. 4.9.5 IVR On the IVR interface, you can carry out specific configurations for the IVR which has been uploaded from the System Voice interface. UC100 User M anual Copyright @ 2011-2015 Dinstar... -
Page 61: Sms
Enter contents into the box on the left, and then input the number of recipient . Click Send in the last. Note: If there are mutilple recipients , use | to separate them, for example, 13151103146|18954405566. UC100 User M anual Copyright @ 2011-2015 Dinstar... - Page 62 Receive Message All SMS received by UC100 are displayed on the Receive List. Read Message Click on the Receive List to read SMS contents. Reply Message Click , and then enter SMS contents in the box on the left. Click Send in the last.
