Quick Installation Guide
UC350
Thanks for Choosing Dinstar's VoIP Gateway!
Please read this guide carefully before installing the gateway. If you need any
technical support,
please contact us
.
Tel: +86 755 61919966
Email: support@dinstar.com
Website: www.dinstar.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC350 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dinstar UC350

  • Page 1 Quick Installation Guide UC350 Thanks for Choosing Dinstar’s VoIP Gateway! Please read this guide carefully before installing the gateway. If you need any technical support, please contact us Tel: +86 755 61919966 Email: support@dinstar.com Website: www.dinstar.com...
  • Page 2: Description Of Indicators

    Model and Interfaces Interface User board slots MCU Board (optional) Model UC350 2*100/1000M, Base-T, RJ45 FXS Board: 1* USB 2.0 2* RJ45 with 8 FXS 1* Console port FXO Board: 2* RJ45 with 8 FXO E1/T1 Board: 4* E1/T1 Ports...
  • Page 3 Indicators and Ports UC350 PORT 0 PORT 1 PORT 2 PORT 3 MCU 1 SLOT2 SLOT3 MCU 0 SLOT0 SLOT1 Main Control Board User Board Slot Expandable E1 / FXS / FXO ports Console Ports Power Indicator LAN Ports Reset Ports...
  • Page 4: Installation Instruction

    Installation Instruction Network connection Connect gateway with network via a switch PORT 0 PORT 1 PORT 2 PORT 3 MCU 1 SLOT2 SLOT3 MCU 0 SLOT0 SLOT1 192.168.12.1 192.168.11.1 Network Cable Network Cable Router/Switch Switch 192.168.11.XXX IP Network Connect the power cord to power jack Connect gateway with power input and ground point Welcome! Grounding Cable...
  • Page 5: Login Web Gui

    Login Web GUI Open the GUI in browser through IP HTTPS: XX.XX.XX.XX .The GE0 default is 192.168.12.1 and GE1 default is 192.168.11.1. The username is admin and password is admin@123#. Check Network Status Check GE0 and GE1 network status on the "Status → Overview" page.
  • Page 6 Modify Network Configuration Log into the device and click "Network → Settings" at the top menu bar to configure IP addresses of GE0 and GE1 ports. Click “Save” and "reset" to make the settings take effect.
  • Page 7 Create SIP Extensions Click "Extension→ SIP" to create the SIP extension: add/delete/disable/enable, etc. UC350 supports batch add or import account files. Note: when add the extension, the profile should choose the corresponding one. After setting, you need to click "apply" to make the settings take effect.
  • Page 8: Add Trunk

    Add Trunk SIP trunk SIP trunks are used to connect other SIP terminals or service providers. When add a SIP trunk, you should choose corresponding SIP profile based on your current network. The SIP trunk supports UDP/TCP/TLS. Also, SIP trunk status can be checked under Status → SIP page.
  • Page 9 You can also create Trunk/FXO. It is an alternative to support calls through or from PSTN.
  • Page 10 E1/T1 You can set up ISDN PRI/SS7/R2 connections via digital E1/T1 ports. Please be sure the E1/T1 physical connection is well connected, and PRI status is up and active before configuring the call routing.
  • Page 11: Basic Operation

    On the "Call Control → Route" interface, you can configure routes for incoming calls and outgoing calls. The UC350 supports max 300 routes, the rule with a lower index has a higher priority. The key configuration of route is at “condition” part. Here, you can configure the route based on the Caller/Called Number prefix and time.
  • Page 12: More Details

    Manual or ask for technical support. Frequently Asked Questions ⑴ Does UC350 support dual network ports to access different networks for interconnection and intercommunication to achieve business? UC350 can support GE0/GE1 interconnection services at the same time, which can make GE0 calls out of GE1. But the corresponding network port needs to be selected in the extension or trunk.
