5700 STEP TOP ACC WOOD BURNER INSTALLATION AND OPERATING INSTRUCTIONS
5700 STEP TOP ACC WOOD BURNER INSTALLATION AND OPERATING INSTRUCTIONS
IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these
instructions may result in a fi re hazard and will void the warranty.
•
Fig. 3,4 and Table 1 & 2 relate to installations with tested fl ue systems; as per AS/NZS 2918:2001 - Appen-
dix F, with a ceiling angle between 0° - 30° inclusive.
•
For installations with a ceiling angle greater than 30°, refer to Fig. 6 & 7 and AS/NZS 2918:2001 4.6.3(b)
•
Ceiling Plate may vary in size depending on ceiling angle. Please specify ceiling pitch prior to ordering the
ceiling plate.
•
Quadra-Fire 5700 Step Top ACC wood burner's are tested and approved to the N.Z. National Environmen-
tal Standards;
Page 1
57ST-ACC-AU
INSTALLATIONS TO COMPLY WITH AS/NZS2918:2001
AND WILL REQUIRE A BUILDING CONSENT
57ST-ACC-AU -5700 Step Top ACC Hardwood Certifi ed
Particulate Emissions = 1.5 g/kg Space Heating Effi ciency = 65%
Model:
7038-201D
October 12, 2015
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Quadra-Fire 57ST-ACC-AU
Summary of Contents for Quadra-Fire 57ST-ACC-AU
- Page 1 Ceiling Plate may vary in size depending on ceiling angle. Please specify ceiling pitch prior to ordering the ceiling plate. • Quadra-Fire 5700 Step Top ACC wood burner’s are tested and approved to the N.Z. National Environmen- tal Standards; 57ST-ACC-AU -5700 Step Top ACC Hardwood Certifi ed Particulate Emissions = 1.5 g/kg Space Heating Effi...
- Page 2 Hearth & Home Technologies welcomes you to our tradition our stoves, inserts and fi replaces. And yet we are old-fash- of excellence! In choosing a Quadra-Fire appliance, you ioned when it comes to craftsmanship. Each unit is meticu- have our assurance of commitment to quality, durability, and lously fabricated and surfaces are hand-fi...
- Page 3 5700 Step Top ACC Wood Burner Quadra-Fire 5700 STEP TOP ACC Wood Burner Dimensions Pedestal Model Fig. 1 822 mm 769 mm 686 mm 170 mm 535 mm 280 mm 379 mm 435 mm 945 mm 330 mm 489 mm...
-
Page 4: Floor Protector
5700 Step Top ACC Wood Burner FLOOR PROTECTOR Quadra-fi re 5700 Step Top ACC does not require a insulating Floor Protector, as they are tested and comply with the minimum Floor Protector requirements of AS/NZS 2918:2001. Note: ▪ The minimum Floor Protector sizes are specifi ed in the clearance chart, see Table 1 & 2. ▪... -
Page 5: Firebox Installation
5700 Step Top ACC Wood Burner CORNER POSITIONING (45°) CORNER POSITIONING (45°) Fig. 4 Drawing not to scale Table 2 DESCRIPTION Hawkwind Kit Shall be Fitted Min. clearance from fi rebox to corner walls 100mm Depth of fl oor protector 1210mm Min. -
Page 6: Air Controls
5700 Step Top ACC Wood Burner OPERATING INSTRUCTIONS Air Controls 1. Start-Up Air Control The Start-Up Air Control has two primary functions. The HIGH fi rst function is to activate the Automatic Combustion Control Burn Rate Air Control system (ACC). This function is performed by sliding the con- trol all the way back until it stops at the “HI”... -
Page 7: General Instructions For Flue System
5700 Step Top ACC Wood Burner GENERAL INSTRUCTIONS FOR FLUE SYSTEM ▪ Flue pipe installed crimp/narrow end down ▪ Outer casings installed crimped/narrow end up. (Critical when exposed above the roof) ▪ Inner casings - direction not critical ▪ Flue pipes - seal all joints including fi rebox spigot. - fi... - Page 8 Outer Casing Inner Casing Internal Swage 12.5 V ented Ceiling Plate Flue Pipe Quadra-fire 5700 Floor The flue crimp must be cut so the swage (half-moon bulge after the crimp) fits tightly into the spigot. Page 8 7038-201D October 12, 2015...
- Page 9 5700 Step Top ACC Wood Burner FLUE PENETRATION 1.QF.1F Un-tested flue systems, as per AS/NZS 2918:2001, 4.6.3(b) ADD Cowl Fig. 6 AS/NZS2918:2001 Casing Cover Un-tested flue with sloped ceiling Spider Bracket penetration greater than 30° from horizontal A = 25mm Approved Flashing 4.6.3(b) Fig 4.6 = downward distance of...
-
Page 10: Minimum Height Of Flue System Exit
5700 Step Top ACC Wood Burner GENERAL INSTRUCTIONS FOR FLUE SYSTEM 1. Unpack the Flue Mounted Shield, detach the three brackets and familarize yourself with the illustra- tions. 2. Using a sharp knife or razor blade, carefully cut through the plastic fi lm on the “inside face” where it meets the outer shield (refer sketch). - Page 11 5700 Step Top ACC Wood Burner AS/NZS 2918:2001 General Notes WARNING: THE APPLIANCE AND FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH AS/NZS 2918 AND THE APPROPRIATE REQUIREMENTS OF THE RELEVANT BUILDING CODE OR CODES. WARNING: APPLIANCES INSTALLED IN ACCORDANCE WITH THIS STANDARD SHALL COMPLY WITH THE REQUIREMENTS OF AS/NZS 4013 WHERE REQUIRED BY THE REGULA- TORY AUTHORITY, I.E.
-
Page 12: Service And Maintenance Log
5700 Step Top ACC Wood Burner Service And Maintenance Log Date of Service Performed By Description of Service Page 12 7038-201D October 12, 2015... - Page 13 5700 Step Top ACC Wood Burner AUSTRALIAN WARRANTY INFORMATION Hearth & Home Technologies Inc (HHT) 1445 N. Highway | Colville, WA 99114 | (509-684-3745) HHT extends the following manufacturer’s warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer.
- Page 14 5700 Step Top ACC Wood Burner OTHER RIGHTS The HHT manufacturer’s warranty is in addition to other rights and remedies that you may have under Australian law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
-
Page 15: Service Parts
5700 Step Top ACC Wood Burner 57ST-ACC-AU Service Parts Beginning Manufacturing Date: Nov 2012 Step Top Wood Stove Ending Manufacturing Date: Active Advanced Combustion Control Part number list on following page. Page 15 October 12, 2015 7038-201D... - Page 16 5700 Step Top ACC Wood Burner 57ST-ACC-AU Service Parts Beginning Manufacturing Date: Nov 2012 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
- Page 17 5700 Step Top ACC Wood Burner 57ST-ACC-AU Service Parts Beginning Manufacturing Date: Nov 2012 Ending Manufacturing Date: Active #17 Brick Set 17.5 17.8 17.8 17.4 17.1 17.8 17.1 17.8 17.1 17.1 17.2 17.1 17.1 17.1 17.7 17.1 17.6 17.1 17.1 17.6...
- Page 18 5700 Step Top ACC Wood Burner 57ST-ACC-AU Service Parts Beginning Manufacturing Date: Nov 2012 Ending Manufacturing Date: Active #28 Pedestal Assembly #29 Legs Assembly #27 Burn Rate Control Assembly 27.9 28.1 27.8 27.1 29.1 27.7 27.6 27.2 27.5 28.3 27.4 29.4...
-
Page 19: Side View
5700 Step Top ACC Wood Burner 57ST-ACC-AU Service Parts Beginning Manufacturing Date: Nov 2012 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. - Page 20 Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer logo onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL Read, understand and Leave this manual with • Important operating and •...
