QUADRA-FIRE 3100 SERIES ACC WOOD BURNER INSTALLATION INSTRUCTIONS
Model:
31ST-ACC-AU
IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these
instructions may result in a fire hazard and will void the warranty.
• Fig. 3,4,5,6, 7 and Table 1,2,3,4 relate to installations with tested flue systems; as per AS/NZS 2918:2001 -
Appendix F, with a ceiling angle between 0° - 30° inclusive.
• For installations with a ceiling angle greater than 30°, refer to Fig. 7 & 8 and AS/NZS 2918:2001 4.6.3(b)
• Ceiling Plate may vary in size depending on ceiling angle. Please specify ceiling pitch prior to ordering the
ceiling plate.
• Quadra-Fire 3100 series ACC wood burner's are tested and approved to the N.Z. National Environmental
Standards;
Page 1
INSTALLATIONS TO COMPLY WITH AS/NZS2918:2001
AND WILL REQUIRE A BUILDING CONSENT
31M-ACC-AU 3100 Millenium ACC Hardwood Certified
31ST-ACC-AU 3100 Step Top ACC Hardwood Certified
Particulate Emissions = 1.4 g/kg Space Heating Efficiency = 71%
31M-ACC-AU
7033-308B
R
Model:
January 17, 2013
Advertisement
Related Manuals for Quadra-Fire 31ST-ACC-AU
Summary of Contents for Quadra-Fire 31ST-ACC-AU
- Page 1 QUADRA-FIRE 3100 SERIES ACC WOOD BURNER INSTALLATION INSTRUCTIONS Model: Model: 31M-ACC-AU 31ST-ACC-AU INSTALLATIONS TO COMPLY WITH AS/NZS2918:2001 AND WILL REQUIRE A BUILDING CONSENT IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these instructions may result in a fire hazard and will void the warranty.
- Page 2 Hearth & Home Technologies welcomes you to our tradition our stoves, inserts and fireplaces. And yet we are old-fash- of excellence! In choosing a Quadra-Fire appliance, you ioned when it comes to craftsmanship. Each unit is meticu- have our assurance of commitment to quality, durability, and lously fabricated and surfaces are hand-finished for lasting performance.
- Page 3 3100 Series ACC Wood Burner Quadra-Fire 3100 Millenium ACC Wood Burner Dimensions 635 mm 170 mm 581 mm 677 mm 616 mm 46 mm 90 mm 484 mm 397 mm 379 mm 273 mm 749 mm 254 mm 457 mm...
-
Page 4: Floor Protector
3100 Series ACC Wood Burner FLOOR PROTECTOR Quadra-fire 3100 Millenium ACC does not require a insulating Floor Protector, as they are tested and comply with the minimum Floor Protector requirements of AS/NZS 2918:2001. Note: ▪ The minimum Floor Protector sizes are specified in the clearance chart, see Table 1 & 2. -
Page 5: Firebox Installation
3100 Series ACC Wood Burner CORNER POSITIONING (45°) CORNER POSITIONING (45°) Fig. 4 FLOOR PROTECTOR Table 2 DESCRIPTION With Double Pioneer Double Flue Mounted Shield Universal Flue Shield Shall be Fitted Fitted Min. clearance from firebox corner to corner walls Min. - Page 6 3100 Series ACC Wood Burner Quadra-Fire 31 Step Top ACC Wood Burner Dimensions 678mm 635mm 618mm 318mm 237mm 391mm 870mm 457mm 406mm 292mm 527mm 170mm 89mm 194mm 841mm 264mm 606mm 537mm Page 6 7033-308B January 17, 2013...
- Page 7 3100 Series ACC Wood Burner FLOOR PROTECTOR Quadra-fire 3100 Step Top ACC does not require a insulating Floor Protector, as they are tested and comply with the minimum Floor Protector requirements of AS/NZS 2918:2001. Note: ▪ The minimum Floor Protector sizes are specified in the clearance chart, see Table 3 & 4.
- Page 8 3100 Series ACC Wood Burner CORNER POSITIONING (45°) CORNER POSITIONING (45°) Fig. 6 FLOOR PROTECTOR Table 4 DESCRIPTION With Double Pioneer Double Flue Mounted Shield Universal Flue Shield Shall be Fitted Fitted Min. clearance from firebox corner to corner walls Min.
-
Page 9: General Instructions For Flue System
3100 Series ACC Wood Burner GENERAL INSTRUCTIONS FOR FLUE SYSTEM ▪ Flue pipe installed crimp/narrow end down ▪ Outer casings installed crimped/narrow end up. (Critical when exposed above the roof) ▪ Inner casings - direction not critical ▪ Flue pipes - seal all joints including firebox spigot. - fix with a minimum of 3 stainless steel rivets ▪... - Page 10 Internal Swage 12.5 Vented Ceiling Plate Pioneer Double Flue Shield Flue Pipe Quadra-fire Millennium Floor Protector The flue crimp must be cut so the swage (half-moon bulge after the crimp) fits tightly into the spigot. Page 10 7033-308B January 17, 2013...
- Page 11 3100 Series ACC Wood Burner 1.QF.1F FLUE PENETRATION Un-tested flue systems, as per AS/NZS 2918:2001, 4.6.3(b) ADD Cowl Fig. 8 Fig. 6 AS/NZS2918:2001 Casing Cover Un-tested flue with sloped ceiling Spider Bracket penetration greater than 30°...
-
Page 12: Minimum Height Of Flue System Exit
3100 Series ACC Wood Burner GENERAL INSTRUCTIONS FOR FLUE SYSTEM 1. Unpack the Flue Mounted Shield, detach the three brackets and familarize yourself with the illustra- tions. 2. Using a sharp knife or razor blade, carefully cut through the plastic film on the “inside face” where it meets the outer shield (refer sketch). - Page 13 3100 Series ACC Wood Burner AS/NZS 2918:2001 General Notes WARNINGS: WARNING: THE APPLIANCE AND FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH AS/NZS 2918 AND THE APPROPRIATE REQUIREMENTS OF THE RELEVANT BUILDING CODE OR CODES. WARNING: APPLIANCES INSTALLED IN ACCORDANCE WITH THIS STANDARD SHALL COMPLY WITH THE REQUIREMENTS OF AS/NZS 4013 WHERE REQUIRED BY THE REGULA- TORY AUTHORITY, I.E.
- Page 14 3100 Series ACC Wood Burner Service And Maintenance Log Date of Service Performed By Description of Service Page 14 7033-308B January 17, 2013...
- Page 15 3100 Series ACC Wood Burner Service And Maintenance Log Date of Service Performed By Description of Service Page 15 January 17, 2013 7033-308B...
- Page 16 CONTACT INFORMATION: Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafire.com CAUTION DO NOT DISCARD THIS MANUAL Read, understand and Leave this manual with • Important operating and •...
