INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
5700 STEP TOP WOOD APPLIANCE
SERIES
AUTOMATIC COMBUSTION CONTROL
MODEL:
57ST-ACC-C
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Owner's Manual
Operation & Care
(ACC)
If the information in these instructions is
not followed exactly, a fire could result
causing property damage, personal injury,
or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
•
Do not over-fire - If appliance or chimney connector
glows, you are over-firing. Over-firing will void your
warranty.
•
Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass and appliance will cause burns.
•
Do not touch glass until it is cooled
•
Use leather gloves when reloading fuel
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
appliance.
•
Alert children and adults to hazards of high
temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
Fire Risk.
For use with solid wood fuel only.
Other fuels may over-fire and generate
poisonous gases (i.e. carbon monoxide).
To obtain a French translation of this manual, please
contact your dealer or visit
Pour obtenir une traduction française de ce manuel, s'il
vous plaît contacter votre revendeur ou visitez
www.quadrafire.com
7038-227C
WARNING
WARNING
WARNING
NOTE
www.quadrafire.com
August 13, 2018
Advertisement
Table of Contents
Related Manuals for Quadra-Fire 57ST-ACC-C
Summary of Contents for Quadra-Fire 57ST-ACC-C
- Page 1 • Comply with all minimum clearances to combustibles MODEL: as specified. Failure to comply may cause house fire. 57ST-ACC-C WARNING HOT SURFACES! Glass and other surfaces are hot during operation AND cool down. Hot glass and appliance will cause burns.
-
Page 2: Sample Of Serial Number / Safety Label
57ST-ACC-C NOTE: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction A. Sample of Serial Number / Safety Label LOCATION: Back of appliance ITEM PART NUMBER PART NAME 7038-228 SERIAL RATING PLATE HOT WHILE IN OPERATION DO NOT TOUCH, KEEP CHILDREN AND CLOTHING AWAY. CONTACT MAY CAUSE SKIN BURNS. KEEP CAUTION FURNISHINGS AND OTHER COMBUSTIBLE MATERIAL FAR AWAY FROM THE APPLIANCE. -
Page 3: Table Of Contents
K. Clear Space......16 M. Frequently Asked Questions....17 Quadra-Fire is a registered trademark of Hearth & Home Technologies. August 13, 2018... -
Page 4: Warranty Policy
57ST-ACC-C B. Warranty Policy Hearth & Home Technologies LIMITED LIFETIME WARRANTY Hearth & Home Technologies, on behalf of its hearth brands (“HHT”), extends the following warranty for HHT gas, wood, pellet and electric hearth appliances that are purchased from an HHT authorized dealer. - Page 5 57ST-ACC-C WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • • This warranty is only valid in the country in which the HHT authorized dealer or distributor that sold the appliance resides.
- Page 6 57ST-ACC-C This warranty is void if: • • • There is any damage to the appliance or other components due to water or weather damage which is the result of, but not limited LIMITATIONS OF LIABILITY • have other rights, which vary from state to state. EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN.
-
Page 7: Quick Start Guide
57ST-ACC-C C. Quick Start Guide Note: These are generic drawings and may not represent your specific model. 10 Pieces of Newspaper, 10-20 Pieces of Dry Kindling ITEMS NEEDED FOR FIRST FIRE: and a Few Pieces of Dry Split Wood. OPEN AIR... -
Page 8: Listing And Code Approvals
(UM) 84-HUD and NPFA211 in the U.S.A. and the ULC S627-00 and CAN/CSA-B365 Installation Codes in Canada. NOT APPROVED FOR MOBILE HOME INSTALLATIONS IN CANADA! The Quadra-Fire 5700 Wood Appliance meets the U.S. ENVIRONMENTAL PROTECTION AGENCY Certified to comply with 2020 particulate emission standards using crib wood at 1.8 G/HR EPA Method 28 and 5G. -
Page 9: Glass Specifications
57ST-ACC-C C. Glass Specifications WARNING This appliance is equipped with 5mm ceramic glass. Replace glass only with 5mm ceramic glass. Please Fire Risk. contact your dealer for replacement glass. Hearth & Home Technologies disclaims any D. Mobile Home Approved (USA only) responsibility for, and the warranty will be voided •... -
Page 10: Operating Instructions
• Roaring, rumbling noises placed on the burning of wood for home heating. In order • Loud cracking or banging sounds to improve the situation, we at Quadra-Fire have developed • Metal warping cleaner-burning wood appliances that surpass the •... -
Page 11: Air Controls
57ST-ACC-C E. Using Burn Rate Air Control & ACC System 2. Second Stage The next stage of burning, the secondary stage, is the 1. Start up and Reloading Fuel period when the wood gives off flammable gases which Open both Burn Rate Air Control and ACC systems fully. To burn above the fuel with bright flames. -
Page 12: Burn Rates And Operating Efficiency
57ST-ACC-C F. Burn Rates and Operating Efficiency WARNING For maximum operating efficiency This wood appliance has a manufacturer-set minimum Risk of Fire. low burn rate that must not be altered. It is against federal When set on High Burn Rate and over-riding the... -
Page 13: Building A Fire
57ST-ACC-C G. Building A Fire NOTE: Before lighting your first fire in the appliance: • Build fire on brick firebox floor. NOTE: The special high temperature paint that your • Do NOT use grates, andirons or other methods to appliance is finished with will cure as your support fuel. -
Page 14: Correct Baffle & Blanket Placement
57ST-ACC-C INCORRECT POSITIONS H. Correct Baffle & Blanket Placement WARNING Fire Risk. Firebox damage due to improper baffle placement is not covered by warranty. Operate the wood burning appliance with the baffle in the correct position only. Not doing so could result in: •... -
Page 15: Blower Operating Instructions
J. Opacity (Smoke) I. Blower Operating Instructions This is the measure of how cleanly your appliance is NOTE: If your Quadra-Fire wood appliance is equipped burning. Opacity is measured in percent; 100% opacity is with an optional blower, you should follow these... -
Page 16: Clear Space
57ST-ACC-C K. Clear Space • Do NOT place combustible objects within 4 ft (1.2 m) of WARNING the front of appliance (Figure 16.1). • Mantel - avoid placing candles and other heat-sensitive Asphyxiation Risk. objects on mantel or hearth. Heat may damage these •... -
Page 17: Frequently Asked Questions
57ST-ACC-C M. Frequently Asked Questions ISSUES SOLUTIONS When first operated, this appliance may release an odor for the first several hours. This is Odor from appliance caused by the curing of the paint and the burning off of any oils remaining from manufacturing. -
Page 18: Maintenance And Service
57ST-ACC-C Maintenance and Service A. Quick Reference Maintenance Guide CAUTION! Allow the appliance to completely cool down before performing any cleaning or maintenance. When properly maintained, your fireplace will give Start the first inspection after the first 2 months of use, you many years of trouble-free service. -
Page 19: Cleaning And Operating The Ash Removal System
57ST-ACC-C B. Cleaning and Operating the Ash Removal System WARNING Fire Risk. Make sure Ash Removal System door is sealed tight against the gasket. Air leakage may cause: • Over-fire condition • Flame and/or smoke spillage • Wood to burn too fast Figure 19.1... - Page 20 57ST-ACC-C Formation and Need For Removal: When wood is burned 3. Disposal of Ashes slowly, it produces tar and other organic vapors which • Frequency: When ash is within 1-3/4 in. (44mm) of combine with expelled moisture to form creosote.
-
Page 21: Troubleshooting Guide
57ST-ACC-C Troubleshooting Guide With proper installation, operation, and maintenance your wood appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist you or a qualified service person in the diagnosis of a problem and the corrective action to be taken. -
Page 22: Service Part Replacement
9. Replace the door on the appliance. 2. A magnet holds the bracket to the appliance. Pull the bracket down away from the appliance to expose the Quadra-Fire appliances are equipped with ceramic super snap disc. heat-resistant glass, which can only be broken by impact or 3. -
Page 23: Door Handle Assembly
57ST-ACC-C D. Door Handle Assembly 1. Slide door handle through door. 2. Install additional washer(s) as shown in Figure 23.1 3. Install key in groove. 4. Align groove in latch cam with key; slide latch cam over shaft 5. Install locknut but do not over tighten, the handle needs to rotate smoothly. -
Page 24: Tube Channel Assembly Replacement
57ST-ACC-C F. Tube Channel Assembly Replacement NOTE: Soak the bolts with penetrating oil for at least 15 minutes before trying to remove them. Removing Tube Channel Assembly 1. Remove the right side shield by removing 3 Phillips Replacing Tube Channel Assembly screws from back of appliance;... -
Page 25: Reference Materials
57ST-ACC-C Reference Materials A. Service & Maintenance Log Date of Service Performed By Description of Service August 13, 2018 7038-227C... - Page 26 57ST-ACC-C Date of Service Performed By Description of Service 7038-227C August 13, 2018...
- Page 27 57ST-ACC-C Date of Service Performed By Description of Service August 13, 2018 7038-227C...
-
Page 28: Exploded View
57ST-ACC-C B. Exploded View 57ST-ACC-C Service Parts Beginning Manufacturing Date: Sept 2017 Step Top Wood Stove Ending Manufacturing Date: Active Advanced Combustion Control Part number list on following page. 08/18 7038-227C August 13, 2018... -
Page 29: Service Parts
Logo, Quadra-Fire Pkg of 10 7000-694/10 Black & Gold 436-5350 Component Pack (Includes Nickel Spring Handles (1) 1/2” & Doors (2) 1/4”, (2) Nickel Hinge Pins, Quadra-Fire Logo) Nickel Doors 436-5360 Spring Handle 832-0540 Door Handle Assemblies Fiber Handle SRV7033-071... - Page 30 57ST-ACC-C 57ST-ACC-C Service Parts Beginning Manufacturing Date: Sept 2017 Ending Manufacturing Date: Active #18 Brick Set 18.3 18.5 18.2 18.5 18.1 18.1 18.5 18.1 18.5 18.2 18.1 18.1 18.1 18.4 18.1 18.6 18.1 18.1 18.6 18.1 18.4 18.1 18.6 18.1 18.6...
- Page 31 57ST-ACC-C 57ST-ACC-C Service Parts Beginning Manufacturing Date: Sept 2017 Ending Manufacturing Date: Active #25 Burn Rate Control #26 Pedestal Assembly Assembly 26.1 25.9 26.2 26.3 25.8 25.1 26.4 26.5 25.7 25.6 26.6 25.2 25.5 26.7 26.9 26.8 25.4 25.3 IMPORTANT: THIS IS DATED INFORMATION .
- Page 32 57ST-ACC-C 57ST-ACC-C Service Parts Beginning Manufacturing Date: Sept 2017 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.
-
Page 33: Accessories
57ST-ACC-C 57ST-ACC-C Service Parts Beginning Manufacturing Date: Sept 2017 Ending Manufacturing Date: Active D. Accessories IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. - Page 34 Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafire.com CAUTION DO NOT DISCARD THIS MANUAL...
