DRIVE
The control adjusts the gain of the signal going into the distortion
DRIVE
section. The higher the , the more distorted the signal.
DRIVE
DRIVE
CLEAN MIX
The knob controls the amount of dry, unaffected signal going
CLEAN MIX
to the output. The clean signal used in this control does
applied. This control is especially useful for getting back some of the low
end frequencies that can be lost in the pure distorted signal.
0
CLEAN MIX
DISTORTION MIX
This adjusts the overall level of the distorted signal. Along with the
knob, it can be used to balance the levels of clean vs. distor-
CLEAN MIX
tion. Also, the overall output level can be increased by turning up both
clean and distortion mix levels.
0
DISTORTION MIX
10 | Controls: Knobs
CONTROLS: EQUALIZER
One of the key features of the
The Equalizer is post distortion. Each band can be adjusted up or down
in
play. The display shows
brightness. The equalizer section has three controls:
BAND SELECT LEFT and RIGHT
The two buttons on either side of the
to edit.
EQ KNOB
The equalizer knob changes the value of the selected band up or down in
have any
NOT EQ
1 dB
You can quickly and easily zero the equalizer by pressing both left and
right band select buttons at the same time. The equalizer display will
reset to a default "flat" setting.
Pro is the
MWB
steps from to and the setting is indicated by the dis-
1 dB -12 dB +12 dB
steps by lighting adjacent
1 dB
EQ
steps.
(NG) (HG) (HS) (HA) (HR)
+12
0
-12
62 125 250 500 1K
Band Select Left
<
EQ Knob
-band graphic equalizer.
7
s with varying
LED
knob select the frequency band
+12
0
-12
2K 4K
Band Select Right
>
Controls: Equalizer | 11
