HH Enable
The
button will allow Hot Hand
HH ENABLE
preset so it can be used on one preset and not on another.
Calibration
The
Pro has a calibration feature which is only used in Hot Hand
MWB
mode. However, calibration is not required before use. The calibration
feature allows you to set the
MAXIMUM
position of your hand. Depending on your playing style, you may find it
useful to try some different calibration positions. The default and most
common use of calibration is to have your hand pointing straight up as
the maximum point of the
sweep. Calibration can also be useful
DRIVE
if you are putting the sensor on a headband or other alternate locations.
Calibration mode can only be enabled when
tion settings are saved per preset.
To perform a calibration:
Select a preset by pressing a footswitch.
1.
Enable Hot Hand control by pressing the
2.
Press the
button to put the
CALIBRATE
3.
Put the Hot Hand sensor into the desired calibration position.
4.
Press the footswitch for the currently selected preset.
5.
The Calibrate
will blink to when the calibration is complete.
6.
LED
If you have trouble with calibration and need to get back to the default
setting, point the front of the sensor (the H logo) straight up towards the
ceiling and run the calibration procedure again.
20 | Use with Hot Hand
control for an individual
®
point of the
sweep for any
DRIVE
in
. Calibra-
HH ENABLE
ON
button.
HH ENABLE
Pro into Calibrate Mode.
MWB
BACKPAGE PARAMETERS
The
Pro has some additional controls that can only be edited
MWB
in a special mode called Backpage mode. Backpage mode is enabled
by pressing the
and
HH ENABLE
CALIBRATE
indicated on the main control panel. Backpage mode can be exited by
pressing the two buttons simultaneously again.
HH ENABLE
BACKPAGE
MODE
CALIBRATE
In Backpage mode, the
EQ
controls and the Effect knob take on different
functions and the displays will change to indicate the parameter values.
For the
display, there are two letter abbreviations above some of the
EQ
columns that indicate the parameter controlled in Backpage mode. Select
the parameter to be edited with the left and right band select buttons
and adjust the value with the knob.
(NG) (HG) (HS) (HA) (HR)
+12
0
-12
62 125 250 500 1K
<
-
Continued
buttons simultaneously, as
+12
0
-12
2K
4K
>
Backpage Parameters | 21
