CONNECTIONS
GUITAR IN
Connect your bass guitar or other instrument here using a standard
¼" cable.
MONO
GUITAR OUT
Connect this to your amp, pedal, or other audio device.
EXPRESSION IN (optional)
Connect a passive expression pedal that uses a
morphing of sounds between banks A and B.
SENSOR IN (optional)
Connect an optional Hot Hand sensor here, either wired or wireless.
SENSOR OUT (optional)
Use a Source Audio daisy-chain cable to connect this jack to the sensor
input of another pedal.
MIDI IN (optional)
program and continuous control input. Connect to a
MIDI
with a standard cable
MIDI
9V DC
Connect the included Volt power supply here. Use of a non-Source
9 DC
Audio power supply may cause damage and void the warranty.
MIDI IN
SENSOR
IN
GUITAR IN EXP IN
8 | Connections
TRS plug here. Allows
output
MIDI
SENSOR
OUT
9V DC
GUITAR OUT
CONTROLS: KNOBS
EFFECT (not labeled)
The effect knob selects which distortion type will be used. There are
effect positions ( through ) around the knob as well as a setting for
0 22
. In the
CLEAN BOOST/EQ CLEAN BOOST/EQ
bypassed but the output, mix, and equalizer still apply. For information
on the individual settings see the Effect Types section.
11
10
09
MULTI BAND
08
07
06
FOLDBACK
05
04
03
NORMAL 02
01
00
CLEAN BOOST / EQ
EQ AMOUNT
This is a master control for the equalizer. It changes the amount of the
equalizer curve that is applied to the signal. To utilize the full effect of
the , this knob should be turned fully clockwise to the
EQ
other settings for this control can be useful for morphing applications or
for tweaking the overall tone.
0
EQ AMOUNT
-
Continued
23
mode, the distortion effect is
OCTAVE
12
13
14
15
NORMAL
16
17
FOLDBACK
18
19 SINGLE BAND
20
21 OCTAVE
22
mark. The
FULL
FULL
Controls: Knobs | 9
