Symbols; Tool Specifi Cations; Operating Controls - Protool CHP 26 PLUS Original Instruction

Rotary/chiseling hammer
CHP 26 PLUS - original instruction
Table of contents
1 Symbols ................................... 12
2 Tool Specifi cations ...................... 12
3 Operating Controls ..................... 12
4 Notes on Safety Prevention ......... 13
4.1 General Safety Instructions ......... 13
4.2 Work area ................................. 13
4.3 Electrical safety ......................... 13
4.4 Personal safety .......................... 13
4.5 Additional Safety Rules ............... 14
4.6 Machine-specifi c Safety Warnings .. 14
4.7 Noise / Vibration Information ........ 15
5 Application ................................ 15
6 Activation ................................. 15
6.1 Additional handle ....................... 16
6.2 Depth stop ................................ 16
6.3 Switching on/off ........................ 16
6.4 Speed control ............................ 16
6.5 Rotational direction switching ...... 16
6.6 Selecting the modes of operation ... 16
7 Inserting / Removing tools ........... 17
7.1 Inserting tools ........................... 17
7.2 Removing tools .......................... 17
8 Accessories ............................... 17
8.1 Screw adapter assembly
(accessory) ............................... 17
8.2 Thread chuck ............................ 17
9 Practical tips .............................. 17
10 Maintenance .............................. 18
11 Environmental Protection /
Disposal.................................... 18
12 Warranty .................................. 18
13 Declaration of Conformity ............ 19
1

Symbols

Double insulation
Warning of general danger
Risk of electric shock
Use protective goggles!
Wear ear protection!
Wear a dust mask!
12
GB
Read the instructions
Not to be included in municipal refuse
Drilling / Stirring / Screwing
Impact drilling
Positioning the chisel
Chiselling
Advice or tip
►
2

Tool Specifi cations

Voltage
Frequency
Input power
No-load speed
Impact rate, max.
Impact energy
Right / Left rotation
Safety clutch
Clamping collar dia.
Tool holder
Drill dia., max.
Steel
Wood
Hammer drilling in conctrete
Weight
Protection class
3

Operating Controls

[1-1] Tool holder
[1-2] Protective anti-dust cover
[1-3] Unlocking sleeve
[1-4] Operation mode switch
[1-5] Revolution regulation switch
[1-6] Locking button
[1-7] Rotation direction switch
[1-8] Additional handle
[1-9] Depth stop
[1-10] Handle - insulated grip
[2-1] Operation mode switch
[3-1] Unlocking sleeve
[3-2] Screw adapter
[3-3] Tool holder
[3-4] Chuck
Not all of the accessories illustrated or de-
scribed are included as standard delivery.
220 - 230 V
50 / 60 Hz
800 W
0 - 1000 min
-1
4900 min
-1
2.8 J
•
•
43 mm
SDS-Plus
13 mm
40 mm
26 mm
2.9 kg
II /
